- Light Source:LED Lamp
- Lamp Body Material:Aluminum Alloy
- Light Type:Solar
- Color Temperature:Pure White
- Power:≥30W
- Illumination Time:8h
=== Base Info ===
- Model NO.:SNSTY-250
- Cell Type:Lithium Battery
- Charging Time (H):8
- Usage:Garden, Street
- IP Rating:IP65
- Certification:CE, RoHS
- Voltage:12,24V
- With Light Source:With Light Source
- Keyword:50W LED Integrated All in One Solar Street Light (
- Model No.:Snsty-250
- LED Power:50W
- Solar PV Power:85W
- Lithium Battery:44ah
- Lumen:5000-5500lm
- Mounting Height:7-8m
- Mounting Distance:30-35m
- CCT:3000-6000K
- Product Size/Weight:1210*340*45mm,16.0 Kg
- Transport Package:Strong Carton
- Specification:50W LED 85W Solar Panel
- Trademark:SINOLTECH
- Origin:China
- HS Code:9405500000
- Production Capacity:China
=== Description ===
Basic Info.
Model NO.
SNSTY-250
Cell Type
Lithium Battery
Charging Time (H)
8
Usage
Garden, Street
IP Rating
IP65
Certification
CE, RoHS
Voltage
12/24V
With Light Source
With Light Source
Keyword
50W LED Integrated All in One Solar Street Light (
Model No.
Snsty-250
LED Power
50W
Solar PV Power
85W
Lithium Battery
44ah
Lumen
5000-5500lm
Mounting Height
7-8m
Mounting Distance
30-35m
CCT
3000-6000K
Product Size/Weight
1210*340*45mm/16.0 Kg
Transport Package
Strong Carton
Specification
50W LED 85W Solar Panel
Trademark
SINOLTECH
Origin
China
HS Code
9405500000
Production Capacity
China
Product Description
50W LED Integrated All in One Solar Street Light (SNSTY-250)
Our integrated solar street light which integrates the green-energy parts solarpanel, LED lamp and the Li-Fe battery into a single product, is with human intelligence induction system to gain the solution of low-energy, long-time, high-luminance and free maintenance. And the same time, it's convenient in the shipment and installation.
---Purpose:
To be installed in the garden, residential area, courtyard, road, mine area or Parking area or provide the light in roads where it's necessary, the battery provide The energy for lighting, and the solar panel charge for the battery.
Product parts:
The product is made up with the integrated parts (solar panel, Li-Fe battery, LED, MPPT controller and human intelligence induction system) and the light pole.
Working characters:
The solar panel converts sunlight into electricity and stored in Li-Fe battery via Controller, the LED light will work in night automatically by light sensor control,
And provide light for the darkness area, the human intelligence induction system can save the energy when the lighting is not necessary.
---Advantage:
1) Integrity design, no calbing, easy to install
Suitable for any kinds of pole material, such as iron, wood, bamboo, plastic, etc, reducing construction cost.
2) Adopting solar panel as power source, LED lamp as light source, perfect combination for energy saving.
3) Adopting lithium iron phosphate battery as power back-up, with high capacity, long service life over 5 years,
Excellent high temperature peformance.
4) Waterproof design
5) Adopting aluminum alloy as main body material, with feaures of rust-proof, corrosion-proof.
6) Motion sensor design, segmented power control function, during late half night, brightness reduce in order to save Energy and increase practicality.
---General specification:
Our integrated solar street light which integrates the green-energy parts solarpanel, LED lamp and the Li-Fe battery into a single product, is with human intelligence induction system to gain the solution of low-energy, long-time, high-luminance and free maintenance. And the same time, it's convenient in the shipment and installation.
---Purpose:
To be installed in the garden, residential area, courtyard, road, mine area or Parking area or provide the light in roads where it's necessary, the battery provide The energy for lighting, and the solar panel charge for the battery.
Product parts:
The product is made up with the integrated parts (solar panel, Li-Fe battery, LED, MPPT controller and human intelligence induction system) and the light pole.
Working characters:
The solar panel converts sunlight into electricity and stored in Li-Fe battery via Controller, the LED light will work in night automatically by light sensor control,
And provide light for the darkness area, the human intelligence induction system can save the energy when the lighting is not necessary.
---Advantage:
1) Integrity design, no calbing, easy to install
Suitable for any kinds of pole material, such as iron, wood, bamboo, plastic, etc, reducing construction cost.
2) Adopting solar panel as power source, LED lamp as light source, perfect combination for energy saving.
3) Adopting lithium iron phosphate battery as power back-up, with high capacity, long service life over 5 years,
Excellent high temperature peformance.
4) Waterproof design
5) Adopting aluminum alloy as main body material, with feaures of rust-proof, corrosion-proof.
6) Motion sensor design, segmented power control function, during late half night, brightness reduce in order to save Energy and increase practicality.
---General specification:Solar Panel | Max Power | 18V85W(High efficiency monocrystalline silicon) |
| Life time | 25 years |
Battery | Type | Lithium battery 44AH |
| Life time | 5 years |
LED Lamp | Max power | 12V 50W |
(With sensor) | Led chip brand | Bridgelux from USA with high brightness |
| Lumen(LM) | 5000-5500LM |
| Life time | 50000hours |
| Viewing angle | 120 degree |
Charge time | By sun | 7 hours |
Discharge time | Saving power | more than 24 hours |
| Full power | more than 10 hours |
Working temp. | range(C) | -20C~+60C |
Color temp. | range(k) | 6500k-7000k |
Mounting height | range(m) | 7-8m |
Space between light | range(m) | 25-30m |
Main lamp materials | | Aluminum alloy |
Certificate | | CE/ROHS/IP65 |
Warranty period | | 3 years |
