8m Mast Smartgen Control System Single Axel Versatility Mobile Light Tower

• Hydraulic Mast Extension：8m
• Engine：Kubota
• Lighting Longevity：3 Years
• Rotation：340 Degrees
• Wheel Chocks：2
• Fuel Consumption：0.8h,R

=== Base Info ===

• Model NO.：RPLT-6900
• Transport Package：Plywood Pallet,Plwood Case,Cartons
• Specification：1850*1660*2620
• Trademark：Robust Power
• Origin：China
• HS Code：9405409000
• Production Capacity：200set,Month

=== Description ===

Basic Info.

Model NO. RPLT-6900 Transport Package Plywood Pallet/Plwood Case/Cartons Specification 1850*1660*2620 Trademark Robust Power Origin China HS Code 9405409000 Production Capacity 200set/Month

Product Description

Features
1.360 mast rotation
2.fault protection
3.fully bunded
4.heavy duty, weather-protective enclosure
5.120L fuel tank


Technical Data:

Light
Housing Material	Aluminium die cast
Type of lights	LED Lamp
Power of lights	4*480W SAA certified Robust Power LED lamps
Lumen Output	4*67,200lm ( total )
Voltage	DC 48V
Longevity	3 years
Waterproof grade	IP65
Color temperature	2100K-5700K
Mast
Material of mast	Galvanized iron
Mast lifting type	Hydraulic mast
Mast section	6-section telescopic
Mast rotation system	340° manual operation
Max. height of mast	8.6meters
Engine
Engine model	Kubota Z482 2 cylinder, vertical, liquid cooled
Start system	Electric (Battery start)
Alternator	Sinocox
Engine speed	2200rmp
Rated power	4kW continuous
Insulation	H
Fuel tank capacity	110L
Fuel consumption	0.8L/hr
Maximum Working Hours	50H
Controller system	Digital control panel
Waterproof grade	IP54
Engine shutdown protection	Low oil pressure, over speed, over current, high-temperature detection, low fuel level
Trailer
Stabiliser Supports	Optional 4*Hydraulic
Tow Hitch	Ring/ball hitch
Tire Size	16 inch
Brakes	Manual
Packing
Net weight	930/890 kg
Dimension	4500X1350X1700 MM

Robust Power Models:

No.	Model	Mast	Power of Lamps	Engine Model
1	RPLT1600	4.8M Manual	4*400W Metal Halide Lamp	RP186FA
2	RPLT1600	4.8M Manual	4*160W LED	RP186FA
3	RPLT1600	4.8M Manual	2*1000W Metal Halide Lamp	RP186FA
4	RPLT6000	9M Manual	4*1000W Metal Halide Lamp	Kubota D1105 (Japan)
5	RPLT6000	9M Manual	4*240W LED	Kubota D905 (Japan)
6	RPLT6800	8.6M Hydraulic	4*1000W Metal Halide Lamp	Kubota D1105 (Japan)
7	RPLT6800	8.6M Hydraulic	4*1500W Metal Halide Lamp	Kubota D1105 (Japan)
8	RPLT6800	8.6M Hydraulic	4*480W LED	Kubota D905 (Japan)
9	RPLT3800	7M Hydraulic	4*480W LED	Kubota Z482 (Japan)
10	RPLT6900	8.5M Hydraulic	4*480W LED	Kubota D1105 (Japan)
11	RPLT7200	10M Hydraulic	6*480W LED	Kubota D1105 (Japan)
12	RPLT7200	10M Hydraulic	4*720W LED	Kubota D1105 (Japan)
13	RPLT7600	9M Hydraulic	6*480W LED	Kubota D1105 (Japan)
14	RPLT7600	9M Hydraulic	4*720W LED	Kubota D1105 (Japan)
