P5 Outdoor Large Size LED Advertising Billboard and Signs

• Tube Chip Color：Full Color
• IP Rating：IP65
• Pixel Pitch：5mm
• Pixel Configuration：1R, 1G, 1B
• Display Function：Video Display, Image & Text Display, Text Display, Market Display
• Average Power Consumption：260W,Sqm

=== Base Info ===

• Model NO.：5mm
• Pixel Density：40000dots,Sqm
• Scanning Mode：1,8scan
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, RoHS, UL, CCC, ETL
• Brightness：6000nits
• Module Size：320X160mm
• Maintenance：Rear Service
• Contrast Ratio：5000:1
• Warranty：2years
• Protection Grade：IP65
• Max.Power Consumption：750W,Sqm
• Cabinet Size：960X960mm
• Cabinet Material：Steel Iron
• Input Power：100-240V,50-60Hz
• Refresh Rate：4800Hz
• Viewing Angle：160°,140°
• Operating Temperature：-30~+70°
• Operating Humidity：10-95%Rh
• Liftspan：100,000hr
• Transport Package：Wooden Case Package
• Specification：5mm
• Trademark：CKGLED
• Origin：China
• HS Code：8528591090
• Production Capacity：6000sqm,Month

=== Description ===
ScreenDrive Mode:1/8 Constant Current Drive/Horizontal Viewing Angle160DegVertical Viewing Angle140DegBrightness6000cd//sqmGrey Scale:16bitsRefresh Rate≥4800HzColor>16.7MInput VoltageAC 110V~220V+/-10%VRefresh Frame Frequency60HzProtection Level:IP65/Working Environment:Outdoor/Working Temperature-30- +70ºCOperation humidity10%-95%RHCertificates:CCC, CE, ETL ,RoHS, FCC/



PRODUCT PHOTOS:
