High Definition Outdoor P3 LED Advertising Billboard Full Color Display Panel

Hangzhou Awesome Imp&Exp. Co., Ltd. / 2022-06-27

High Definition Outdoor P3 LED Advertising Billboard Full Color Display Panel

  • Tube Chip Color:Full Color
  • IP Rating:IP65
  • Pixel Pitch:3mm
  • Pixel Configuration:1R, 1G, 1B
  • Display Function:Video Display, Image & Text Display, Text Display, Market Display
  • Average Power Consumption:600W , m²

=== Base Info ===

  • Model NO.:OF-P3
  • Pixel Density:111111 Pixels,M2
  • Scanning Mode:1,8 Scan
  • Display Type:LED Video Display
  • Application:Advertising
  • Certification:CE, RoHS, UL, CCC, ETL
  • Cabinet:Alu,Steel
  • Weight:35kg,50kg
  • Brightness:>6500nits
  • Refresh Rate:>3840Hz
  • Contrast Rate:3000:1
  • LED Lamps:SMD 3 in 1
  • Driver IC:Constent Current
  • PSU:5V 60A
  • System:Nova
  • Voltage:AC110-240V
  • Transport Package:Plywood Cases
  • Specification:576x768mm
  • Trademark:LEDventure
  • Origin:China
  • HS Code:8528591090
  • Production Capacity:2000sqm,Month

=== Description ===
Overview Product Description

Detailed Photos


High Definition Outdoor P3 LED Advertising Billboard Full Color Display Panel

High Definition Outdoor P3 LED Advertising Billboard Full Color Display Panel

High Definition Outdoor P3 LED Advertising Billboard Full Color Display Panel

Material Quality Level

All of our Product materials we choose all top quality levels, including the SMD, IC components, also the PCB, screws, PSU brands etc, so that during the led screen using, it helps to cut down after sale serive costs, to make sure led display screen stable and less aftersale services.

High Definition Outdoor P3 LED Advertising Billboard Full Color Display Panel
High Definition Outdoor P3 LED Advertising Billboard Full Color Display Panel


Technical Specification



Item

High Definition Outdoor P3 LED Advertising Billboard Full Color Display Panel

Pixel Pitch

3 mm

Pixel Density

111111 pixels/M2

Pixel Configuration

SMD 3 IN 1

Module Size

192x192 mm

Module Resolution

64*64 pixels

Min.Viewing Distance

3 meters

Brightness

>6500nits

Viewing Angle(degree)

≤140°

Average Power Consumption

400W/M2

Scan Mode

1/8 Scan

Protection Level

IP65/IP54

Cabinet Size

576x768mm



Color Temperature

The brightness of R.G.B. is adjustable according to software 100level; Color temperature is adjustable in terms of detailed requirements

Input Voltage

AC110-240V, 50HZ/60HZ

Refresh Rate

> 1920hz

Color

65535 Levels

Horizontal/Vertical Viewing Angle

<140°

Gray Scale

16 bits

Effective Communication Distance(without relay)

<100 meters

Lifespan

≥100,000 hours

Environment Temperature

Storage: -40°C~+85°C  , Operation: -20 °C~+45°C

Blind Spot Rate

<0.0001(led display industry standard is less than 0.0003)

Control Mode

Video frequency synchronization



Installation Methods

Outdoor front service back service LED Display screen fixed on the wall, on pillars, standing etc all available, and system hardware included sending cards sending box, processor, receiving cards etc.

High Definition Outdoor P3 LED Advertising Billboard Full Color Display Panel
High Definition Outdoor P3 LED Advertising Billboard Full Color Display Panel






Packing Information

By plywood cases, packing well and easy to load.

High Definition Outdoor P3 LED Advertising Billboard Full Color Display Panel




Certificates

ALL of our Product passed CE, EMC FCC, UL and other security tests, to ensure to meet most market laws and standard requires, and make sure the quality is top level and stable for many years use.

High Definition Outdoor P3 LED Advertising Billboard Full Color Display Panel

About LEDventure



High Definition Outdoor P3 LED Advertising Billboard Full Color Display Panel

High Definition Outdoor P3 LED Advertising Billboard Full Color Display Panel
