Luxury Type Automotive Paint Spray Booth with Ce

Yumyth Electronic Tech Co., Limited / 2022-06-23

Luxury Type Automotive Paint Spray Booth with Ce

  • After-sales Service:Available
  • Warranty:12months
  • Type:Auto Paint Spray Booth
  • Certification:CCC, CE, CSA, GS, UL, SGS, ISO
  • Substrate:Steel
  • Brand:Hongyuan

=== Base Info ===

  • Model NO.:HY-CB40B
  • Coating:Painting
  • Airflow Direction:Lateral Undershot-type
  • Heating Mode:Diesel
  • Paint Mist Treatment:Dry-type
  • Condition:New
  • Color:Red, Blue, White
  • Panel:50,75mm EPS Foam Panel
  • Grate:5rows
  • Ramp:2pieces
  • Heating System:Gas, Diesel, Oil, Used Oil, Electric
  • Filter System:4-Stage Filtration System
  • Upper Light:Available
  • Side Light:Optional
  • Control Box:English Panel
  • Standard Voltage:380V,3f&220V,1f@50Hz
  • Control:Automatic
  • Drawing:Available
  • User Manual:Available
  • Related Product 1:Large Truck Paint Spray Booth
  • Related Product 2:Folding Retractable Paint Spray Booth
  • Transport Package:Proper Packing Suitable for Sea Shipment
  • Specification:25cbm for a 20ft container loading.
  • Trademark:Hongyuan
  • Origin:Shandong, China
  • Production Capacity:100 Set Per Month

=== Description ===

Basic Info.

Model NO. HY-CB40B Coating Painting Airflow Direction Lateral Undershot-type Heating Mode Diesel Paint Mist Treatment Dry-type Condition New Color Red, Blue, White Panel 50/75mm EPS Foam Panel Grate 5rows Ramp 2pieces Heating System Gas, Diesel, Oil, Used Oil, Electric Filter System 4-Stage Filtration System Upper Light Available Side Light Optional Control Box English Panel Standard Voltage 380V/3f&220V/1f@50Hz Control Automatic Drawing Available User Manual Available Related Product 1 Large Truck Paint Spray Booth Related Product 2 Folding Retractable Paint Spray Booth Transport Package Proper Packing Suitable for Sea Shipment Specification 25cbm for a 20ft container loading. Trademark Hongyuan Origin Shandong, China Production Capacity 100 Set Per Month

Product Description

Introduction of the Luxury Type Automotive Paint Spray Booth with Ce
1. full-down draft paint booth:
2. semi-down draft paint booth:
3. side-down draft paint booth:
4. cross-draft paint booth:

Quick Specification of the Luxury Type Automotive Paint Spray Booth with Ce
ModelHY-CB40B
Outside Size(mm)7000(L)*4000(W)*3400(H)
Inside Size(mm)6900(L)*3900(W)*2700(H)
Front Door(mm)3000*2600(W*H)
Side Door(mm)700*2000(W*H)
Total power<17kW
Voltage status380V/3ph&220V/1ph@50Hz
Wall Panel50mm EPS foam panel
Ceiling panelGalvanized steel
Basement&floorRaised metal-base (300mm high) with complete grating floor.
Intaketwo set of fan, motor: 4kW.
Exhaust One set of fan, motor: 4kW.
By-passPneumatic damper from spraying to baking cycle
Heating System(Oil)Italy Riello one-stage oil burner.
Filter System4 stages of filters: Pre-filter, ceiling filter, floor paint-stop filter, extract paint-stop filter
Lighting Upper lights, 8units, 4*36W each.
Control System1set.

Picture of the Luxury Type Automotive Paint Spray Booth with Ce
Luxury Type Automotive Paint Spray Booth with Ce

details show of Luxury Type Automotive Paint Spray Booth with Ce
Luxury Type Automotive Paint Spray Booth with Ce


parts show of Luxury Type Automotive Paint Spray Booth with Ce
Luxury Type Automotive Paint Spray Booth with Ce

Luxury Type Automotive Paint Spray Booth with Ce
Luxury Type Automotive Paint Spray Booth with Ce



Production area and equipment for Luxury Type Automotive Paint Spray Booth with Ce
Luxury Type Automotive Paint Spray Booth with Ce

Package Show of Luxury Type Automotive Paint Spray Booth with Ce
Luxury Type Automotive Paint Spray Booth with Ce



Project case for paint booth
Luxury Type Automotive Paint Spray Booth with Ce
Luxury Type Automotive Paint Spray Booth with Ce

Certificate of our product and company

Luxury Type Automotive Paint Spray Booth with Ce
Our Team is serving you at any time
Luxury Type Automotive Paint Spray Booth with Ce

Send us inquiry about Luxury Type Automotive Paint Spray Booth with Ce
Luxury Type Automotive Paint Spray Booth with Ce
