Car Preparation Station for Paiting

• Type：Spray Booth
• Certification：CE
• Substrate：Steel
• Brand：Captain
• Coating：Painting
• Airflow Direction：Fully Undershot-type

=== Base Info ===

• Model NO.：Captain-2
• Heating Mode：Diesel
• Paint Mist Treatment：Dry-type
• Condition：New
• Basement & Floor：Without Basement ,Cement Floor
• Ceiling System：Not Configure
• Generator Setting：Back Exhaust Air
• Intake & Exhaust Air System：3450X1100X1800 Mm (Lxwxh)
• Fan：5.5kw
• Filtering System：Pre-Filter Pocket,Floor Filter(Fibreglass).
• Lighting System：Not Configure
• Voltage Frequency：as Request
• Total Power：6kw
• Transport Package：Export Container ,Pallet ,Disassembly with Carto
• Specification：CE, SGS, ISO
• Trademark：OEM,Captain
• Origin：Jiangsu, China.
• Production Capacity：660sets,Month

=== Description ===

Basic Info.

Model NO. Captain-2 Heating Mode Diesel Paint Mist Treatment Dry-type Condition New Basement & Floor Without Basement ,Cement Floor Ceiling System Not Configure Generator Setting Back Exhaust Air Intake & Exhaust Air System 3450X1100X1800 Mm (Lxwxh) Fan 5.5kw Filtering System Pre-Filter Pocket,Floor Filter(Fibreglass). Lighting System Not Configure Voltage Frequency as Request Total Power 6kw Transport Package Export Container /Pallet /Disassembly with Carto Specification CE, SGS, ISO Trademark OEM/Captain Origin Jiangsu, China. Production Capacity 660sets/Month

Product Description

Basement & Floor	Without basement ,cement floor
Ceiling System	Not Configure
Generator Setting	Back exhaust air,quadrate steel frame,blue coated steel,
Intake & Exhaust air system	Generator dimension: 3450×1100×1800 mm (L×W×H);with 1set 5.5KW fan for exhaust air,belt-drive motor set outside;Air capacity is 16000m³/h, with electric damper to control exhaust air capacity.
Sealed Type	Not Configure
Filtering System	Pre-filter pocket,Floor filter(fibreglass).
Lighting System	Not Configure
Control System	Control the operation of damper working and electric damper
Voltage frequency	As request
Total Power	6KW

A. Prep stations make it possible for users to prep and perform minor paint work in one area without moving the vehicle.
B. Prep stations speed up the drying process and improve the overall quality of your finished product.
C. Two airflow choice, above ground exhaust box and pit style downdraft, allow easy integration into new or existing body shop layouts.
D. Optional heat units are available for high production needs.




Standard Prep Stations optional

L Semi-Downdraft or Pit-Style Downdraft or Full Downdraft

L With or without overhead plenum

L With or without heater & intake system

L Free-standing with structural steel support or suspended from the shop ceiling

Optional

L Cupboards in the rear of Prep Stations to store painting materials and equipments

L Roll-Up Curtains(motorized controls/manual operation)

Other features

L Overspray and dust control by 95% filter efficiency

L PHILIPS lamps, BELIMO damper and RIELLO burner

L Main electric components are CE listed

L All hardware, fasteners, sealants

L 24 months warranty

L Delivery time of standard prep station can reach 10 business days

L Bubble film packaging for sea transportation in bulk, special steel tray packages are accepted
