- Application:Machinery
- Hardness:Hardened Tooth Surface
- Gear Position:External Gear
- Manufacturing Method:Rolling Gear
- Toothed Portion Shape:Spur Gear
- Material:S45c
=== Base Info ===
- Model NO.:HFPG000052
- Type:Circular Gear
- Module Number:M1-8
- Transport Package:with Plastic Bag,with Pearl-Cotton Package.
- Specification:standard
- Trademark:HF
- Origin:Shenzhen China( Mainland)
- HS Code:84839000
- Production Capacity:500000 PCS, Year
=== Description ===
Overview
Product Description
Number | Number of Teeth | Shaft Bore Dia. AH7 (1mm Increment) | Twisting Direction | B | C | D | E | F | G |
Type | Module | Straight Bore Straight Bore+Tap | Keyway+Tap |
Straight Bore
Straight Bore+Tap
Keyway+Tap | 1.0 | 20 | 6 | 8 | L(Left)
R(Right) | 17 | 20 | 22 | 8 | 10 | 18 |
22~ 28 | 8 | 8~13 | 18~20 | 22~28 | 24~30 |
30~48 | 10 | 10~17 | 25~30 | 30~48 | 32~50 |
50~70 | 12 | 12~17 | 35~40 | 50~70 | 52~72 |
80~100 | 15 | 15~30 | 50 | 80~100 | 82~102 |
1.5 | 20~26 | 12 | 12~17 | 24~32 | 30~39 | 33~42 | 12 | 12 | 24 |
28~44 | 15 | 15~30 | 36~50 | 42~67.5 | 45~70.5 |
45~52 | 18 | 18~40 | 50~60 | 72~78 | 75~81 |
60~100 | 20 | 20-50 | 60~70 | 90~150 | 93·153 |
2.0 | 15~18 | 12 | 12~17 | 24~30 | 30~36 | 34~40 | 16 | 13 | 29 |
20~28 | 15 | 15·22 | 32~45 | 40~56 | 44~60 |
30~36 | 18 | 18~40 | 50 | 60~72 | 64~76 |
40~48 | 20 | 20~44 | 60 | 80~96 | 84~100 |
50~100 | 25 | 25~60 | 60~100 | 100~200 | 104~204 |
2.5 | 15~18 | 15 | 15~30 | 30~38 | 37.5~45 | 42.5~50 | 20 | 14 | 34 |
20~24 | 18 | 18~40 | 40~48 | 50~60 | 55~65 |
25~36 | 20 | 20~50 | 50~70 | 62.5~90 | 67.5~95 |
40~60 | 25 | 25~70 | 70~80 | 90~150 | 95~155 |
3.0 | 15~18 | 18 | 18~22 | 36~40 | 45~54 | 51~60 | 25 | 16 | 4 |
Production process:
Molding Cutting, Gear Hobbing, Gear Milling, Gear Shaping, Gear Broaching,Gear Shaving, Gear Grinding and Gear Lapping.
Company ProfileShenzhen Hefa Gear Machinery Co.,LTD established in 2009, is a professional manufacture engaged in development, production, sales and service of timing pulley, precise spur gears, helical gears, bevel gear, worm& worm gear and so on. We located in Shenzhen with convenient transposition excite. Hefa Gear Machinery dedicated to strict quality control and thoughtful customer service. Our experienced staffs are always available to discuss your requirements, and fulfill your satisfaction.
Inspection:
Hefa Gear Machinery dedicated to strict quality control." Focus and Professional on the Development of Conveyor Field" this is Hefa Gear Machinery target. Work step by step, Hefa always provide success solution in precise conveyor field. Offering best price, super service and regular delivery are always our priorities.
Packaging & ShippingFAQHow to order?
* You send us drawing or sample | * We carry through project assessment |
* We give you our design for your confirmation |
* We make the sample and send it to you after you confirmed our design |
* You confirm the sample then place an order and pay us 30% deposit |
* We start producing |
* When the goods is done, you pay us the balance after you confirmed pictures or tracking numbers. |
* Trade is done, thank you!! |
If you are interested in our products, please tell us which materials, type, width, length u want.
