China Supplier SKF NSK Spherical Roller Bearing 22317 Bearings

• Rolling Body：Roller Bearings
• The Number of Rows：Double
• Outer Dimension：Medium and Large(120-190mm)
• Material：Bearing Steel
• Spherical：Aligning Bearings
• Load Direction：Radial Bearing

=== Base Info ===

• Model NO.：22317
• Separated：Unseparated
• Inner：85mm
• Outer：180mm
• Thickness：60mm
• Weight：7.5kg
• Clearance：C0 C2 C3 C4 C5 C9
• Hardness：58-64 HRC
• Vibration：Z1V1 Z2V2 Z3V3
• Lubrication：Oil
• Shipment：by Sea,by Air,by Express
• Race Way Super Finishing：Yes
• Race Super Finishing：Yes
• Transport Package：Single Box, Plastic Barrel, Carton, Tray
• Specification：CE, ISO9001
• Trademark：SKF,NSK ,OEM
• Origin：China
• HS Code：8482200000
• Production Capacity：100000PCS,Year

=== Description ===
Seals Types2RS,OPENVibration LevelZ1V1,Z2V2,Z3V3ClearanceC2,C0,C3,C4,C5Tolerance CodesABEC-1,ABEC-3,ABEC-5MaterralGCr15-China/AISI52100-USA/Din100Cr6-GermanyMOQ1Set at leastDelivery Time15-45 days after contractPayment TermsTT/PAPAL/WESTERN UNIONPackageTube package+outer carton+pallets;
Single box+outer carton+pallets;
Tube pavkge+middle box+outer carton+pallets;
According to your requirement
NO 5. Spherical Roller Bearing Models And Size
Designation
Principal  Dimension(kN)
Basic Load Ratings(r/min)
Speed ratings
MassdDBr
min
Dynamic
Static
Grease
Oilkg23032160240602.13767301500190013.524032CA160240802.163611641100150012.924132CA1602701092.11010170070090025.42638190280672.55429781200150013.723038K190290752.162611001200150020.523038CA190290752.17657351300170016.924038CA1902901002.19801000950130022.823144CA220370120415701520900120054.723144K220370120413301330900120054.822244220400108412002100850120057.62324422040014441800282067085094.622344/W3322046014551700309067085012923948CA240320602.16357101300170014.9230482403609238201800900120037.623048K/W332403609238201800900120037.42314824040012841200256076099077.224148/W3324040016041200330043054081.6

Bearings NO.	d	D	B	C	C0	Weight
	mm	mm	mm	kN	kN	kg

21317 EK	85	180	41	325	375	5.15
22317 E	85	180	60	550	620	7.65
22317 E/VA405	85	180	60	550	620	7.65
22317 EK	85	180	60	550	620	7.5
22218 E	90	160	40	325	375	3.4
22218 EK	90	160	40	325	375	3.35
21318 E	90	190	43	380	450	6.1
21318 EK	90	190	43	380	450	6
22318 E	90	190	64	610	695	9.05
22318 E/VA405	90	190	64	610	695	9.05
22318 EK	90	190	64	610	695	8.85
22219 E	95	170	43	380	450	4.15
22219 EK	95	170	43	380	450	4.05
21319 E	95	200	45	425	490	7.05
21319 EK	95	200	45	425	490	6.95
22319 E	95	200	67	670	765	10.5
22319 E/VA405	95	200	67	670	765	10.5
22319 EK	95	200	67	670	765	10.5
22220 E	100	180	46	425	490	4.9
22220 EK	100	180	46	425	490	4.8
21320 E	100	215	47	425	490	8.6

We can accept customized bearing service,besides,we can supply bearing with brand SKF, ZKL, NTN, NSK, KOYO, TIMKEN,NACHI, LYC, HCH, ZWZ
