Factory Outlet Gear Boxed Gearbox Speed Reducer with Modular Design

Shinylink (Shanghai) Industrial Inc. / 2022-06-27

Factory Outlet Gear Boxed Gearbox Speed Reducer with Modular Design

  • Application:Machinery
  • Function:Change Drive Torque, Speed Changing, Speed Reduction
  • Layout:Helical
  • Hardness:Hardened Tooth Surface
  • Installation:Horizontal Type
  • Step:Double-Step

=== Base Info ===

  • Model NO.:H,B
  • Gear Housing:Casting Iron or Steel-Plate Welding Case
  • Installation Form:Horizontal or Vertical
  • Gear Arrangement:Helical Hardened Gearbox
  • Color:Red,Blue or Others
  • Quality Garantee:Europe CE Certification
  • Material:Cast Iron
  • Manufacturing Method:Forging, Grinding
  • Toothed Portion Shape:Helical Gear
  • Lubricant:Oil-Bath and Splash Lubrication
  • Warranty:1 Year
  • Input Speed:1500,1000,750rpm
  • Ratio:1.25~450
  • Gearing Arrangement:Helical
  • Output Torque:up to 900,000nm
  • Output Speed:1.7~1200rpm
  • Transport Package:Polywood Case
  • Specification:ISO
  • Trademark:AOKMAN DRIVE
  • Origin:China
  • HS Code:8483409000
  • Production Capacity:5000PCS,Year

=== Description ===
Overview Product Description

Factory Outlet Gear Boxed Gearbox Speed Reducer with Modular Design
1. Model Number

Types: H1,H2,H3,H4 Parallel Shaft Gearbox
Sizes: 1,2,3,4,5,24,25,26

2. Product Characteristics
(1)Large torque range, capable of horizontal mounting and vertical mounting.
(2)High-efficiency and long life-span, high permissible axial and radial loads.
(3)Low noise, high reliability and compact structure and so on.
(4)Output shafts type: solid shaft, hollow shaft and hollow shaft with shrink disk.
(5)Low noise, high reliability and compact structure.

DimensionsCustomization according to the application.

Rated Power:4KW~3015KW
Rated Torque:0.79N.m~900KN.m
Gear Arrangement:Helical Hardened Gearbox
Input Speed:1500r/min,1000r/min,750r/min
Housing:Casting iron or Steel-plate welding case
Factory Outlet Gear Boxed Gearbox Speed Reducer with Modular Design

Detailed Photos


3. DimensionsCustomization according to the application.

B Series Orthogonal Axis(Shaft) Gearbox (Bevel Helical Gears)
1.Model Number
Types: B2,B3,B4 Orthogonal Shaft Gearbox
Sizes: 1,2,3,4,5,24,25,26
2.Product Characteristics
B Series Industrial Gearbox is a brand-new model of rigid tooth flank gear reducers which has the features as follows:
(1) B series industrial gearboxes have heavy load, large torque range, high-efficiency and long lifespan, high permissible axial and radial loads.
(2) B series orthogonal shaft gearbox has the features of low noise, high reliability and compact structure.
(3) Output shafts: Solid shaft or hollow shaft, and the hollow shaft can be attached with the shrink disk.
(4) Mounting type: horizontal, vertical.
3. Technical Data
Factory Outlet Gear Boxed Gearbox Speed Reducer with Modular Design

Product Parameters


4. Technical Data



Packaging & Shipping

Factory Outlet Gear Boxed Gearbox Speed Reducer with Modular Design

Company Profile

Factory Outlet Gear Boxed Gearbox Speed Reducer with Modular Design

Our Advantages


Factory Outlet Gear Boxed Gearbox Speed Reducer with Modular Design

FAQ

1.Q:What kinds of gearbox can you produce for us?

A:Main products of our company: UDL series speed variator,RV series worm gear reducer, ATA series shaft mounted gearbox, X,B series gear reducer,
P series planetary gearbox and R, S, K, and F series helical-tooth reducer, more
than one hundred models and thousands of specifications
2.Q:Can you make as per custom drawing?
A: Yes, we offer customized service for customers.
3.Q:What is your terms of payment ?
A: 30% Advance payment by T/T after signing the contract.70% before delivery
4.Q:What is your MOQ?
A: 1 Set
If you have any demand for our products please feel free to contact me.
