- Item Type:LED Hydraulic Telescopic Vertical Mobile Light
- Input Voltage(V):AC85~265V DC48V
- Luminous Flux:67200*4lm
- Life:50000h
- IP Rating:IP68
- Transport Package:Pearl Wool, Bubble Pack,Wrapping Film- Iron Frame
=== Base Info ===
- Model NO.:RPLT-6800led
- Specification:4500*1350*1700mm
- Trademark:RobustPower
- Origin:China
- HS Code:94054090
- Production Capacity:300 Sets Per Month
=== Description ===
Technical specifications
GENERATOR | |
Engine | Kubota D1105-BG Diesel |
Engine Type | 3 cylinders,in line,water cooled |
Prime Power | 6.7kW / 50Hz 8.4kW/60Hz |
Engine Aspiration | Natural |
Alternator | Stamford PI044F/4pole,Brushless,excitation |
Voltage | 120,220,230,240V |
Insulation | H |
Fuel Tank Capicity(L) | 100 L |
Fuel Consumption | 2.0 L/h |
Maximum Working Hours | 50 |
Control system | GU3303 Digital controller |
Engine Shutdown Protection | Low oil press,over speed,over current,high temperature |
| detection,low fuel level |
Ayxiliary Sockets | 2 |
Lighting | |
Total Power Of Lamps | 4x480W |
Type Of Lamp | led flood light |
Housing Materials | aluminium |
Lumen | 4*67200lm |
Lifetime Of Lamp | 50000 hours |
Working Temperature | ≤85°C |
led ip | IP68 |
Mast | |
Type | 6~7-Sections Telescoping mast 8~9M |
Total Height | Top 9M |
Rotation | 360 degrees |
Operate For Elevation | Hydraulic |
Trailer | |
Tow Hitch | Ring/ball hitch |
Stabilier Supports | 4*Manual 4*Hydraulic |
Tire Size | 13 inch |
Brakes | Manual |
DIMENSION & WEIGHT |
Dry/Net Weight | 930/890 kg |
Extended Dimension(LxWxH) | 4500*1350*1700mm |
Shipping Package | Iron Pallet 2100*1300*2400mm |
| Carton 520*520*400mm |
Container Load(20GP/40HQ) | 6/12 sets |
Color | White/Yellow/Optional |
