P3.91 Outdoor LED Advertising Display Screen with High Brightness and Waterproof

  • Tube Chip Color:Full Color
  • IP Rating:IP65
  • Pixel Pitch:3.91mm
  • Pixel Configuration:1R, 1G, 1B
  • Display Function:Video Display, Image & Text Display, Text Display, Market Display
  • Average Power Consumption:350W , m²

=== Base Info ===

  • Model NO.:OX-P3.91S
  • Pixel Density:65536pixels,M2
  • Scanning Mode:1,16 Scan
  • Display Type:LED Video Display
  • Application:Advertising
  • Certification:CE, RoHS, UL, CCC, ETL
  • Cabinet:Alu,Steel
  • Weight:30kg,50kg
  • LED Type:SMD3 in 1
  • Brightness:>6000nits
  • Refresh Rate:>1920Hz
  • IP Rate:IP65
  • Driver IC:Constent Current
  • PSU:5V 60A
  • Contrast Rate:3000:1
  • System:Nova
  • Voltage:AC110-240V
  • Transport Package:Plywood Cases
  • Specification:1000x1000mm
  • Trademark:LEDventure
  • Origin:China
  • HS Code:8528591090
  • Production Capacity:2000sqm,Month

=== Description ===
Overview Product Description

P3.91 Full Color Outdoor Front Service LED Advertising Display Screen Billboard is very hot sale for outdoor media solution series, it is very cost effective, and high refresh rate more than 1920hz , also light weight design cabinet for options, image quality is top, running stable, resolution is high density, plus simple installation to make this series more and more popular in indoor outdoor media screens.

Detailed Photos

P3.91Full Color Outdoor Front Service LED Advertising Display Screen Billboard Product detail images.

P3.91 Outdoor LED Advertising Display Screen with High Brightness and Waterproof

Material Quality Level

All of our Product materials we choose all top quality levels, including the SMD, IC components, also the PCB, screws, PSU brands etc, so that during the led screen using, it helps to cut down after sale serive costs, to make sure led display screen stable and less aftersale services.

P3.91 Outdoor LED Advertising Display Screen with High Brightness and Waterproof
P3.91 Outdoor LED Advertising Display Screen with High Brightness and Waterproof


Technical Specification



Item

P3.91 Outdoor LED Advertising Display Screen with High Brightness and Waterproof

Pixel Pitch

3.91mm

Pixel Density

65536 pixels/M2

Pixel Configuration

SMD 3 IN 1

Module Size

 250x250mm

Module Resolution

 64x64 pixels

Min.Viewing Distance

4 m

Brightness

>6000 nits

Viewing Angle(degree)

≤140°

Average Power Consumption

350 W/M2

Scan Mode

1/16 Scan

Protection Level

IP65

Cabinet Size

 1000x1000mm

Color Temperature

The brightness of R.G.B. is adjustable according to software 100level; Color temperature is adjustable in terms of detailed requirements

Input Voltage

AC110-240V, 50HZ/60HZ

Refresh Rate

> 1920hz

Color

65535 Levels

Horizontal/Vertical Viewing Angle

<140°

Gray Scale

16 bits

Effective Communication Distance(without relay)

<100 meters

Lifespan

≥100,000 hours

Environment Temperature

Storage: -40°C~+85°C  , Operation: -20 °C~+45°C

Blind Spot Rate

<0.0001(led display industry standard is less than 0.0003)

Control Mode

Video frequency synchronization



Installation Methods

Outdoor front service back service LED Display screen fixed on the wall, on pillars, standing etc all available, and system hardware included sending cards sending box, processor, receiving cards etc.

P3.91 Outdoor LED Advertising Display Screen with High Brightness and Waterproof
P3.91 Outdoor LED Advertising Display Screen with High Brightness and Waterproof






Packing Information

By plywood cases, packing well and easy to load.

P3.91 Outdoor LED Advertising Display Screen with High Brightness and Waterproof




Certificates

ALL of our Product passed CE, EMC FCC, UL and other security tests, to ensure to meet most market laws and standard requires, and make sure the quality is top level and stable for many years use.

P3.91 Outdoor LED Advertising Display Screen with High Brightness and Waterproof

About LEDventure



P3.91 Outdoor LED Advertising Display Screen with High Brightness and Waterproof

P3.91 Outdoor LED Advertising Display Screen with High Brightness and Waterproof
P3.91 Outdoor LED Advertising Display Screen with High Brightness and Waterproof.
