60W Solar Panel Integrated All in One Solar LED Street Light

• Light Source：LED Lamp
• Lamp Body Material：Aluminum Alloy
• Light Type：Solar
• Color Temperature：Cool White
• Power：≥30W
• Technics：Electroplating

=== Base Info ===

• Model NO.：NSP60
• Illumination Time：3days-4days
• Cell Type：Lithum-Ion LiFePO4
• Charging Time (H)：6
• Usage：Garden, Street
• IP Rating：IP65
• Certification：CE, RoHS
• Voltage：12,24V
• With Light Source：With Light Source
• LED Chip：Bridgelux, USA
• Lumen(Lm)：7800lm
• LED Light Life Time：50, 000 Hours
• Solar panel Max Power：12V 90W
• Solar Cell：Mono
• Battery Capacity：42ah, Lithium Battery
• battery Life Time：5years
• Material：Aluminium Alloy
• Warranty Time：5years
• Product Size：1190*520*220
• Transport Package：Carton for Export
• Specification：CE ROHS
• Trademark：NEWSKY POWER
• Origin：Guangdong Shenzhen
• HS Code：94055000
• Production Capacity：10000 Per Month

=== Description ===

 Model

NSP20W-APP

NSP25W-APP

NSP30W-APP

NSP40W-APP

Rated power

20W

25W

30W

40W

Lumens

2600LM

3250LM

3900LM

5200LM

Solar panel

40W/18V

50W/18V

60W/18V

60W/18V

Lithium battery

18AH

20AH

24AH

26AH

Install height

5-6M

5-6M

6-7M

6-7M

Spacing

18-20M

18-20M

20-25M

20-25M

Color temp.

6500K

Sensing distance

12M

Work temp.

-20ºC ~ +60ºC

Pole diameter

70-100mm

Water proof

IP65

CRI

>70

Charge time

6-8H

Lighting time

Light on at dusk, Light off at dawn atuo.

12 hours lighting time per day, brightness and on&off time can be adjusted by mobilephone APP. Max 10 rainy days backup.

 Model

NSP50W-APP

NSP60W-APP

NSP80W-APP

Rated power

50W

60W

80W

Lumens

6500LM

7800LM

10400LM

Solar panel

80W/18V

90W/18V

100W/18V

Lithium battery

36AH

42AH

60AH

Install height

8-9M

8-9M

8-10M

Spacing

25-30M

25-30M

30-35M

Color temp.

6500K

Sensing distance

12M

Work temp.

-20ºC ~ +60ºC

Pole diameter

70-100mm

Water proof

IP65

CRI

>70

Charge time

6-8H

Lighting time

Light on at dusk, Light off at dawn atuo.

12 hours lighting time per day, brightness and on&off time can be adjusted by mobilephone APP. Max 10 rainy days backup.

 Model

NSP100W-APP

NSP120W-APP

Rated power

100W

120W

Lumens

13000LM

15600LM

Solar panel

130W/18V

150W/18V

Lithium battery

82AH

90AH

Install height

9-11M

9-12M

Spacing

35-40M

35-40M

Color temp.

6500K

Work temp.

-20ºC ~ +60ºC

Pole diameter

70-80mm

Water proof

IP65

CRI

>70

Charge time

6-8H

Lighting time

Light on at dusk, Light off at dawn atuo.

12 hours lighting time per day, brightness and on&off time can be adjusted by mobilephone APP. Max 10 rainy days backup.
