P4 Indoor Waterproof Full Color LED Advertising Display

• Tube Chip Color：Full Color
• Display Function：Video Display, Image & Text Display, Text Display, Market Display
• Pixel Pitch：4mm
• Pixel Configuration：1R,1G,1B
• Pixel Density：62500 Pixels,M2
• Scanning Mode：1,32

=== Base Info ===

• Model NO.：P4
• System Operating Platform：Windows
• Display Type：LED Video Display
• Application：Stage Performance, Advertising, Shopping Guide
• IP Rating：IP31
• Certification：CE, RoHS, UL, CCC, ETL
• Cabinet Material：Nano Plastic
• Weight：7kg,PCS
• Service Solution：Front Service
• Viewing Distance：4meters
• Brightness：800nits
• Refresh Rate：>1920Hz
• Contrast Rate：3000:1
• Voltage：AC110-240V
• LED Lamps：Epistar
• PSU：MW
• Installation：Back Bolted Hanging
• Software OS：Windows
• System：Nova
• Transport Package：Plywood Cases
• Specification：576x576mm
• Trademark：LEDventure
• Origin：China
• HS Code：8528591090
• Production Capacity：2000sqm,Month

=== Description ===

Item

Model Number

Pixel Pitch

4mm

Pixel Density(pixels/M2)

62500 pixels

LED Type

Epistar, SMD 3 in 1, 1R 1G 1B

Module size(mm)

256x128mm

Module Resolution(pixels)

64*32 pixels

Min.Viewing Distance(m)

4 meters

Brightness(nits)

800

Viewing Angle(degree)

≤140°

Average Power Consumption(W/M2)

300

Scan Mode

1/32 Scan

Protection Level

IP31

Cabinet Size(mm)

512x512mm, 480x480mm, 576x576mm

Color Temperature

The brightness of R.G.B. is adjustable according to software 100level; Color temperature is adjustable in terms of detailed requirements

Input Voltage

AC110-240V, 50Hz/60Hz

Refresh Rate

>1920hz

Color

65535 Levels

Horizontal/Vertical viewing angle

<140°

Gray Scale

16 bits

Effective Communication Distance(without relay)

Lifespan

≥100,000 hours

Environment Temperature

Storage: -40°C~+85°C  , Operation: -20 °C~+45°C

Blind Spot Rate

<0.0001(led display industry standard is less than 0.0003)

Control Mode

Video frequency synchronization

Part 5: Installation Methods

Indoor led video wall available fixed on the wall, on pillars, standing etc all available, and system hardware included sending cards sending box, processor, receiving cards etc.



Part 6: Packing Information

Packing by plywood cases, packing well and easy to load

Part 7: Certificates.

ALL of our Product passed CE, EMC FCC, UL and other security tests, to ensure to meet most market laws and standard requires, and make sure the quality is top level and stable for many years use.

Part 8: About LEDventure.

Part 9: LED Display Screen Installation Cases.

Most of our led display exported to Europe with high standards, and also exported to USA, South America and Asia
