Helical Bevel Series High Power Gear Box

• Application：Motor, Machinery
• Function：Distribution Power, Change Drive Torque, Change Drive Direction, Speed Changing, Speed Reduction
• Layout：H, Hb
• Hardness：Hardened Tooth Surface
• Installation：Horizontal Type
• Step：Four-Step

=== Base Info ===

• Model NO.：H1~26, B1~26
• Type：Cylindrical Gear Box
• Accuracy Class：5 ~ 6
• Size：3-26
• Stages：1-4
• Ratio：1.25~450
• Manufacturing Method：Rolling Gear
• OEM/ODM Serivce：Available
• Transport Package：Fumigation Case or Plywood Case
• Trademark：PTT
• Origin：China
• HS Code：8483409000
• Production Capacity：10000pieces,Year

=== Description ===

Basic Info.

Model NO. H1~26, B1~26 Type Cylindrical Gear Box Accuracy Class 5 ~ 6 Size 3-26 Stages 1-4 Ratio 1.25~450 Manufacturing Method Rolling Gear OEM/ODM Serivce Available Transport Package Fumigation Case or Plywood Case Trademark PTT Origin China HS Code 8483409000 Production Capacity 10000pieces/Year

Product Description

Helical Bevel gearbox

H.B series gear units adopt currency layout and may transform into speral reducer according to customer's requirement.

The housing of one size can realize parallel shaft,right-angle shaft models and horizonal,vertical mounting modes.Variety of components is reducible,the number of reducer's mode is augmentable.

Sound-absorbable structure,large surface,big fan reduce temperature and noise,advanced grinding process of cylindrical gear and bevel gear improve stability and transmit power more efficeintly.

Input mode:motor connected flange,shaft input.

Output mode:solid shaft with flat key,hollow shaft with flat key,hollow shaft with shrink disk,hollow or solid shaft with involute splines,solid shaft with flange.

Mounting mode:Foot-mounted,glange-mounted,swing base-mounted,torque-arm-mounted.

H.B series include size 3~26,number of stages is 1~4,ratio is 1.25~450,combing with R series and K series,ratio will be higher.

High precision grade with Gleason and Hofler grinding machineBetter meshing of gearsTop brands bearings and oil sealLong work lifeLow noiseNo oil leakageCompact design, strong and solidBetter cooling propertyCustomized design avaialbeDiversified range catering for power.



RFQ
Q:Are you trading company or manufacturer?
A: We are manufacturer with over 20 years' experience.

Q: How long is your delivery time?
A: Generally it is within 10 days if the goods are in stock, for goods produced as per order, it is within 35 days after confirmation of order.

Q: How long should I wait for the feedback after I send the enquiry?
A: Normally within 12 hours.

Q: What information should I give you to confirm the product?
A: Model/Size, Transmission Ratio, Speed, Shaft directions & Order quantity etc.

Q: Hong long is your product warranty?
A: We offer 12 months warranty from departure date of the goods.

Q: What is your payment terms? T/T 100% in advance for amount less than USD10000.-, 30% T/T in advance , balance before shipment for amount above USD10000.
