China Alloy Wheel Rim Repair Machine CNC in Lathe Awr28hchina Alloy Wheel Rim Repair Machine CNC in Lathe Awr28h

• CNC System：Syntec
• Repairing Alloy Wheel：Max 28"
• Max. Swig Over Bed：770mm
• Max. Swig Over Cross Slide：500mm
• Max.Turning Length：1000mm
• Size of The Three-Jaw Chuck：10′

=== Base Info ===

• Model NO.：AWR28H
• Range of Spindle Speed：20-1800rpm
• Spindle Bore：72mm
• Stations of Tool Carrier：4 Position
• Net Weight：2200kgs
• Transport Package：Standard Wood Packing
• Specification：CE
• Trademark：Crystal
• Origin：Taian City, Shandong Province, China
• HS Code：8458110090
• Production Capacity：30sets,Month

=== Description ===

ITEMSAWR28HMax. swig over bed (mm)(inch)Φ770 (30')Max. Size of alloy wheel (inch)            Φ720 (28')Adjustable stroke of carrier in X direction  100mmCross slide travel (mm)390Width of the rail (mm)300Length of the rail (mm)1300Size of the three-jaw chuck (inch)12'Range of spindle speed (RPM)50~2000Spindle speed controlAutomaticSpindle bore  (mm)Φ82Taper of spindle bore1:20(Φ90)Max. size of tool post25×25mmStations of tool carrier4 positionMin. setting unit of motor(Z) long    0.001mm,
(X) cross   0.001mmMoving speed of post(Z) long     8m/min,
(X) cross    6m/minMotor power7.5KWMchine base(cast iron base)Whole Machine size(L×W×H) (mm³)2140 ×1600×1860Package size2300×1750×2100Net weight2600kgs
