Outdoor Full Color 960X960mm Cabinet LED Advertising Billboard P10 Pixel Pitch

• Tube Chip Color：Full Color
• IP Rating：IP67
• Pixel Pitch：10mm
• Pixel Configuration：1r1g1b, SMD 3535
• Display Function：Video Display, Image & Text Display, Text Display, Market Display
• Average Power Consumption：180W , m²

=== Base Info ===

• Model NO.：Outdoor P10 display
• Pixel Density：10000dots,M2
• Scanning Mode：1,4 Scan
• Display Type：LED Video Display
• Application：Stage Performance
• Certification：CE, RoHS, CCC
• Product Name：Outdoor LED Display P10
• Driver IC：Mbi5124 or Icn 2038s
• Bightness CD/Sqm：4000CD,M2
• Grey Scale：65536 Degree
• Life Time：More 100,000 Hours (80%)
• Mtbf：More 50,000 Hours
• Operating Temperature：-30~-60t
• Humidity：10%-95%
• Color Temperature：6500-9500K
• Transport Package：The Factory Packaging
• Specification：320*160mm
• Trademark：hongking
• Origin：China
• HS Code：8528591090
• Production Capacity：5000 Sqm,Year

=== Description ===
Technical  SpecificationsNOProduct nameoutdoor P10 SMD led display1Pixel Pitch(mm)10mm2Pixel configuration1R1G1B/  SMD 35353Pixel density10000dots/m24Brightness 5000cd/m25Module size(W*H)320*160mm6Module Resolution (W*H)32 dots x 16dots7Module weight450g8Cabinet size (W*H)960mm×960mm9Drive ICMBI512410Drive mode1/4scan11Viewing Angle(V/H)110ºC12Grey Scale65536 degree13Life time>100,000 Hours (50%)14MTBF>50,000 Hours15Operating VoltageAC110V/220V±10%17Screen Power ConsumptionMax: 680w/m2; Average:220w/m218Input Power Frequency50/60Hz19Operating temperature -30--60ºC20Humidity10%-95%21Refresh Rate≥1200HZ22Control MethodSynchronized with computer monitor23Color Temperature6500K-9500K24LED control systemLINSN,Nova-star,Colorlight is selectable
certification  :



Product Application Cases:






company workshop :

Company descripition:
HONGKINGLED is a publicly listed LED display manufacturer. Our facilities cover an area of 1000 square meters. Our company strives to deliver stunning LED solutions that can satisfy all customer requirements. Standardization and flexible production allow us to offer competitive prices for a wide range of high quality products. Our valued clients can enjoy the benefits of attentive service and prompt delivery. For the past 6 years, we have made steady progress. Ingenuity and perseverance have firmly established us as pioneers in the LED display industry. Our company is dedicated to the research and development of LED related technologies. HONGKINGLED products are approved by CE, CCC, EMC and FC.


package:




Payment term: T/T , usually 30~50% down payment before production,balance to be paid before delivery

Delivery time:Production lead time less 20 sqm is about 8-12 working days, more than 50 sqm. is about 15 working days

Free sample or not: Sample is available,but need to pay the material cost and freight cost

Shipping port: Shenzhen, Mainland China

MOQ: 2 sqm for led screen,and10pcs for led module

Guarantee:Two years quality guarantee,after two years,we will ask for material cost only,customer pay freight cost

Package and fast shipping
Anti-shaking wooden case
Carton box
Flight case
The transportation can be support by air ,by sea ,or by express as request

hongking  always provide high quality products to our customers,and good after-sale service,obtained a good reputation,we produce our products based on international standards FCC,CE,RoHs,and with a strict quality control system,and confirm 2 to 3 years warranty,during this period,we will repair the default parts with free of charges,after the period,and during the lifetime,we only ask for material costs.
