Professioanl Custom Tire Changer Machine China Factory

• Warranty：14 Months
• Structure：Vertical

=== Base Info ===

• Model NO.：C9551
• Power Source：Pneumatic
• Type：Simple Disassembly
• Automatic：Semi-Automatic
• Standard：Standard
• Certification：CE
• Condition：New
• Product Name：Professioanl Tire Changer Machine China Factory
• Working Pressure：8-10bar,117-145psi
• Outside Clamping：10-22"
• Inside Clamping：13-24"
• Max. Wheel Width：3-15"
• Max. Wheel Diameter：1040mm (41")
• Bead Breaker Force：2500kg
• Color：Customized Color Acceptable
• Machine Weight：N.W:245kg G.W:270kg
• Optional Specifications 1：Optional Different Kinds of Front Cover
• Optional Specifications 2：Optional Different Kinds of Pneumatic Locking
• Optional Specifications 3：Optional Different Kinds of Inflation Gun
• Optional Extra Accessory1：Motorcycle Adaptor
• Optional Extra Accessory2：Bead Blaster Function
• Optional Extra Accessory3：Leverless System
• Transport Package：Plywood
• Specification：1160*900*1050mm
• Trademark：YuanMech
• Origin：Yingkou, Liaoning, China
• HS Code：8479899990
• Production Capacity：3000PCS,Month

=== Description ===
 C958C958   24"        C9582   24"     Two Point Pressure Right Helper   C9583   24"      Three Point Pressure Right Helper  C9582S   24"Leverless    Two Point Pressure Right Helper   C9583S   24"Leverless     Three Point Pressure Right Helper

1. What are regular maintenance need to be done on tire changer in order to have a long service life?
Periodically drain the water in FRL, add oil in FRL so it can protect pneumatic components. Regularly tighten the bolts and screws on working table. Also check mechanical play or clearance on demounting head, hex bar... Check the belt tension.
(Please contact us if you have more questions on this topic)
2. When working table doesn't turn, how to determine if the problem comes from gearbox, motor or switch?
Disconnect belt and see if the motor can run properly. If not, test the motor itself to see clockwise rotation and anti-clockwise rotation. If motor running properly then the problem is the switch.
We have trouble shooting in details, please contact us for more information.
3. Why is filter-regulator (FRL) so important?
It dry the air so there is no moisture inside pneumatic components. It lubricates the rubber seals to extend its service life. In general FRL is important to maintain long service life of the machine.
