500mm*500mm 112896 Dots / M^2 Hight Quality Screen LED Module

• Tube Chip Color：Full Color
• IP Rating：IP65
• Pixel Pitch：2.9mm
• Pixel Configuration：1R, 1G, 1B
• Display Function：Video Display, Image & Text Display, Text Display, Market Display
• Pixel Density：112896 Dots , M^2

=== Base Info ===

• Model NO.：P2.9
• Scanning Mode：1,28scan
• Display Type：LED Video Display
• Application：Stage Performance
• Certification：CE, RoHS, UL, CCC, ETL
• Warranty Period：2 Years
• Deliver Time：15-20days
• Brightness：>4500
• Modle Size：250mm*250mm
• Life Span：50,000h
• Scaning Type：1,28 Scan
• Color Display：Full Color
• Best Viewing Distance：3m-30m
• Refresh Rate：>1920Hz
• Usage：Outdoor
• Maintenance：Rear Service
• Cabinet Material：Die-Casting Aluminum
• Transport Package：Cardboard and Wooden Carton
• Specification：500mm*500mm
• Trademark：FWS
• Origin：Shenzhen
• HS Code：8528591090
• Production Capacity：250000 PCS ,Month

=== Description ===
Product Description· Corner protect design
· P2.9mm with screwed marks for better consistency and protection.
· High refresh rate with high grey scale.
· Two locks on cabinet left & right.
· One man installation with revolutionized locking system.
· 500mm*500mm and 500mm*1000mm cabinet for option.
 Detail Photos



Product Parameters NO.ParameterSpecifications1Pixel Pitch(mm)2.92LEDSMD14153Screen Resolution(Pixel/m²)1482254Drive Method(Scan)1/285Cabinet Size(mm)500*5006Cabinet Weight(KG)7.57Viewing Angle140°/140°8Grey Scale14bit9Refresh Rate(Hz)>192010Module Size(mm)250*25011Brightness(cdm)>450012Working Voltage(V)AC 100-240V13Average Power Consumption(W/m²)30014Maxium Power Consumption(W/m²)78015IP RatingIP6516Controller NovaStar17Working Humidity10~95%RH18Storage Humidity10~90%RH19Working Temperature-30ºC~60ºC20ComplianceCE, RoHS, UL, CCC, ETl Certifications
Packaging & Shipping

 FAQ

1. Q: Are you a trading company or manufacturer?
    A: We are an OEM/ODM factory.

2. Q: How long is your delivery time?
    A: Generally it takes 15-20 days.

3. Q: What payment methods your company accepts?
    A: We accept T/T. 50% as deposit, 50% must be paid before the goods are shipped.

4. Q: How long is the warranty for your products?
    A: We officially promised warranty time is 2 years after delivery at best.

5. Q: Could we print our own logo on LED screen?
    A: Of course. Please let us konw all the details soon before production.

6. Q: Whether to provide technical training(installation training and use training)?
    A: Yes, we offer full service, including pre-sales, sales, after-sales service, you can reply on me.
