P6.25 Stadium Sport Perimeter Cube LED Display Screen for Arena Studio

Hangzhou Awesome Imp&Exp. Co., Ltd. / 2022-06-27

P6.25 Stadium Sport Perimeter Cube LED Display Screen for Arena Studio

  • Tube Chip Color:Full Color
  • IP Rating:IP65
  • Pixel Pitch:10mm
  • Pixel Configuration:1R, 1G, 1B
  • Display Function:Video Display, Image & Text Display, Text Display, Market Display
  • Average Power Consumption:600W , m²

=== Base Info ===

  • Model NO.:P6.25 P10mm P12.5mm P16mm
  • Pixel Density:10000 dot , m²
  • Scanning Mode:1,2 Scan
  • Display Type:LED Video Display
  • Application:Advertising
  • Certification:CE, RoHS, UL, CCC, ETL
  • Brightness:>6500nits
  • LED Lamps:Epistar
  • Driver IC:Mbi
  • PSU:MW
  • Cabinet:Alu,Steel
  • Refresh Rate:>1920Hz
  • Contrast Rate:3000:1
  • System:Nova
  • Voltage:AC110-240V
  • IP Rate:IP65
  • Transport Package:Plywood Cases
  • Specification:1280x800mm
  • Trademark:LEDventure
  • Origin:China
  • Production Capacity:2000sqm,Month

=== Description ===

Item

P10 P12.5 P16 P20 full color Indoor outdoor stadium sport perimeter led display screen

Model Number

P10 to P20

Pixel Pitch

10mm-20mm

Pixel Density(pixels/M2)

2500 -10000 pixels

Pixel Configuration

SMD 3 IN 1

LED Type

NS, SMD

Module size(mm)

320x160mm

Module Resolution(pixels)

32*16

Min.Viewing Distance(m)

10-20

Brightness(nits)

>6500

Viewing Angle(degree)

≤140°

Average Power Consumption(W/M2)

400

Scan Mode

Constant current

Protection Level

IP65/IP54

Cabinet Size(mm)

1280x800mm, 1200x900mm, 1280x896mm



Color Temperature

The brightness of R.G.B. is adjustable according to software 100level; Color temperature is adjustable in terms of detailed requirements

Input Voltage

AC110-240V, 50HZ|60hz

Refresh Rate

> 1920hz

Color

65535 Levels

Horizontal/Vertical viewing angle

<140°

Gray Scale

16 bits

Effective Communication Distance(without relay)

<100 meters

Lifespan

≥100,000 hours

Environment Temperature

Storage: -40°C~+85°C  , Operation: -20 °C~+45°C

Blind Spot Rate

<0.0001(led display industry standard is less than 0.0003)

Control Mode

Video frequency synchronization



Part 5: Installation methods, P10 P12.5 P16 P20 full color Indoor outdoor stadium sport perimeter led display screen fixed on the wall, on pillars, standing etc all available, and system hardware included sending cards sending box, processor, receiving cards etc.
P6.25 Stadium Sport Perimeter Cube LED Display Screen for Arena Studio
P6.25 Stadium Sport Perimeter Cube LED Display Screen for Arena Studio



Part6: Packing information by plywood cases, packing well and easy to load,
P6.25 Stadium Sport Perimeter Cube LED Display Screen for Arena Studio

Part7: Certificates.

ALL of our Product passed CE, EMC FCC, UL and other security tests, to ensure to meet most market laws and standard requires, and make sure the quality is top level and stable for many years use.
P6.25 Stadium Sport Perimeter Cube LED Display Screen for Arena Studio

Part8: About LEDventure.

P6.25 Stadium Sport Perimeter Cube LED Display Screen for Arena Studio





Part9 : LED display screen installation cases.

Most of our led display exported to Europe with high standards, and small percent to USA and Asia,
P6.25 Stadium Sport Perimeter Cube LED Display Screen for Arena Studio
P6.25 Stadium Sport Perimeter Cube LED Display Screen for Arena Studio
