Videos for How Does a Compact and Lightweight Gearbox Work? Corrosion Resistant Aluminum Alloy Bevel Gearboxes Videos for Customers Orders

• Application：Motor, Machinery, Agricultural Machinery, Car, Metrology and Test Engineering
• Function：Distribution Power, Change Drive Direction, Speed Changing, Speed Reduction, Speed Increase, Transmission
• Layout：Right Angle Drive
• Hardness：Hardened Tooth Surface
• Installation：Universal Mounting
• Step：Single-Step

=== Base Info ===

• Model NO.：JTA10-JTA24
• Type：Bevel Gear Box
• Components：Gearbox, Bevel Gear Units, Input and Output Shafts
• Features：Ultra Compact Bevel Gearbox Design
• Advantages：Inspect Reports, E-Catalog, Catalog Book
• Input & Output Types：Solid Shaft, Hollow Shafts, Motor Adapter Design
• Configurations：2-Way, 3-Way, 4-Way
• Gear Ratios：1:1, 2:1
• Transmission Efficiency：94%-98%
• Input & Output Speed：Maximum 1500 Rpm.
• Shafts Rotation Directions：Cw, Ccw
• Design Drawing Files：2D Dwg Dxf Pdf, 3D CAD Step STP Model
• Transport Package：Standard Exporting Plywood Cases
• Specification：Custom-made
• Trademark：JACTON
• Origin：Guangdong, China
• HS Code：8483409000
• Production Capacity：3060PCS,Month

=== Description ===

Basic Info.

Model NO. JTA10-JTA24 Type Bevel Gear Box Components Gearbox, Bevel Gear Units, Input and Output Shafts Features Ultra Compact Bevel Gearbox Design Advantages Inspect Reports, E-Catalog, Catalog Book Input & Output Types Solid Shaft, Hollow Shafts, Motor Adapter Design Configurations 2-Way, 3-Way, 4-Way Gear Ratios 1:1, 2:1 Transmission Efficiency 94%-98% Input & Output Speed Maximum 1500 Rpm. Shafts Rotation Directions Cw, Ccw Design Drawing Files 2D Dwg Dxf Pdf, 3D CAD Step STP Model Transport Package Standard Exporting Plywood Cases Specification Custom-made Trademark JACTON Origin Guangdong, China HS Code 8483409000 Production Capacity 3060PCS/Month

Product Description

Corrosion resistant aluminum alloy bevel gear box Features: * Light weight and durable: The case is manufactured from a corrosion resistant aluminum alloy with a baked finish for superior durability combined with light weight. * Flexible installation direction: It is possible to install the unit in any direction and installation is easy. * Low noise and high efficiency: A spiral bevel gear is used that is heat-treated before lapping to produce smooth operation. * Maintenance free design: Long-term use is possible because the unit is filled with high-grade grease. * Usable with special products: When an application requires corrosion resistance, we can also use stainless steel for the shaft.






How Does A Compact and Lightweight Gearbox Work?Corrosion Resistant Aluminum Alloy Bevel Gearboxes Videos For Customers Orders
* Thailand Customers top quality JTA10 miniature gearboxes 1:1 ratio 3 way input CW output CW Video:
https://screw-jacks.en.made-in-china.com
* Indonesia customer Lightweight aluminum housing Small-sized Mini right angle drive 1:1 gearboxes Video:
https://screw-jacks.en.made-in-china.com
* Canada clients miniature right angle bevel gearboxes 1:1 ratio/small right angle gear drives Video:
https://screw-jacks.en.made-in-china.com
* Lithuania client 1:1 ratio JTA15 lightweight small aluminium miniature right angle gearbox Video:
https://screw-jacks.en.made-in-china.com
* Colombia client light duty aluminum bevel gear box 1 to 1 ratio,aluminum body gearbox 3 shafts Video:
https://screw-jacks.en.made-in-china.com
* Belgium client lightweight aluminum alloy right 90 spiral bevel gear drives gearbox 1:1 ratio Video:
https://screw-jacks.en.made-in-china.com
* Israel customer 3 shaft gearboxes 1:1 ratio three way bevel gear boxes 20mm shafts 90 deg gearbox Video:
https://screw-jacks.en.made-in-china.com
* 100% safety packages & 100% standard exporting plywood cases materials videos:
https://screw-jacks.en.made-in-china.com

Shipment and Packing Pictures
Shipping:
1. Ocean freight: seaport to seaport, price terms CIF, FOB, EXW, CFR etc.
2. Air freight: airport to airport, price terms EXW, CRF etc.
3. Air courier: DHL, FEDEX, UPS, TNT door to door shipment, price terms DDU, CPT etc.
Packing:
100% standard exporting plywood cases.
Note: International Exporting Standard Wooden Material with Free Fumigation.


JACTON Advantages
1. International standard materials for All JACTON brand products. We insist on choosing brand suppliers to supply the high quality raw materials to control the producing process. Optimization constantly the production processes, inspecting in each link and managing production site.
2. 100% quality assured with double quality inspections. The quality inspection by quality inspectors from processing to finished products as the first time. Before packing, the corresponding sales engineers must inspect the orders following the paper drawings, order quantities and special markings in the invoice or sales contracts as the second time. After that, fill in the inspection report with signature and company stamp.
3. 100% safety transportation. Packing with strong standard export plywood cases materials (free fumigation), inner packing with epe foams to prevent products swaying and outer packing with iron sheets and fasteners to fasten the packages.
4. Internationl sales engineers have professional knowledge and skills on our standard products and service. They have enough ability to solve the basic technical problem immediately whatever by phone, online chat, face to face communications.
5. All the standard products with 2D CAD Drawings (PDF, DWG and DXF formats), and 3D CAD Models (STEP, STP, MODEL, IGS, PRT and CATParT formats).
6. Custom design available, OEM service available, Free engineering advice, Free quotes available and Customer label available.
7. Inspection equipments include motor with inverter drive system, height adjustmemt motorized lifting system, coordinate measuring machines, outside micrometers, inside micrometers, depth calipers, vernier calipers, digital calipers, hardness testers, digital noise meters, industrial infrared thermometers, digital speed measuring instruments, digital multimeters, and high precision clamp digital ammeter etc.
8. Processing with modern advanced machines such as CNC gear hobbing machines, CNC flank grinding machines, CNC cylindrical grinding machines, multi-axis CNC milling machines, CNC lathes and others equipments.


Finished Projects
1. Theatrical solutions stage and orchestra platform lifts projects. Customers are from France, Australia, Netherlands, United Kingdom, Spain and Canada.
2. Hydroelectric power station projects and water conservancy projects. Customers are from Vietnam, Australia, Malaysia, Russian Federation, Nepal, Pakistan, Belgium, United States and United Kingdom.
3. Aircraft maintenance platforms and docking systems projects. Customers are from Pakistan, Singapore and United Arab Emirates.
4. Solar panel tracking system projects. Customers are from Spain, India and Canada.
5. Bolted steel storage tanks and silos lifting solutions. Customers are from South Africa, United States, Mexico, Russian Federation, Brazil and Vietnam.
6. Dish antenna elevation and azimuth positioning projects. Customers are from Singapore, Malaysia and United States.
7. Railway wagon projects. Customers are from South Africa.
8. Beverage can production lines. Customers are from Netherlands, United States, Thailand and Indonesia.
9. Steel factories production lines. Customers are from Iran, United States and Turkey.
10. Continuous PU sandwich panel production lines. Customers are from Thailand and United Kingdom.


JACTON Customers Areas(Countries)
1. American Countries: United States, Mexico, Canada, Chile, Bolivia, Brazil, Colombia, Dominican Republic, Honduras, Costa Rica, Panama, Puerto Rico, Jamaica, Trinidad and Tobago, Aruba, Argentina, Peru, Venezuela.
2. European Countries: Russia, Germany, Turkey, France, United Kingdom, Italy, Spain, Ukraine, Poland, Romania, Netherlands, Belgium, Greece, Czech Republic, Portugal, Sweden, Hungary, Belarus, Austria, Switzerland, Bulgaria, Denmark, Finland, Slovakia, Norway, Ireland, Croatia, Georgia, Armenia, Lithuania, Slovenia, Estonia, Cyprus, Luxembourg, Iceland.
3. Asian Countries: Malaysia, Indonesia, Singapore, Pakistan, Philippines, Vietnam, United Arab Emirates, Thailand, Saudi Arabia, Iran, Turkey, India, Nepal, Yemen, Taiwan, Sri Lanka, Israel, Jordan, Kuwait, Qatar.
4. Oceanian Countries: Australia, New Zealand, Fiji.
5. African Countries: South Africa, Egypt, Ethiopia, Nigeria, Kenya, Tanzania.


JACTON Products List
1. Manual Screw Jacks, Electric Screw Jacks.
2. Screw Jacks Series: JT series acme screw jacks, JTC series cubic screw jacks, JTW series machine screw jacks, JTM series worm screw jacks, JTB series ball screw jacks, JTD series cubic ball screw jacks, JSS series stainless steel screw jacks, JTS series bevel gear screw jacks, Non-standard series screw jacks.
3. Bevel Gearboxes Series: JT series bevel gearboxes, JTP series cubic bevel gearboxes, JTA series aluminum bevel gearboxes, JTH series hollow shaft bevel gearboxes, BSS series stainless steel bevel gearboxes.
4. Lifting Systems and Systems Accessories: two-jacks systems, three-jacks systems, four-jacks systems, six-jacks systems, eight-jacks systems. Accessories cover couplings, universal joints, cardan shafts, connecting shafts, electric motors, geared motors and reducers, hand wheel with crank handles, pillow block bearings, flange block bearings, rod end bearings, stop nuts, limit switches, safety nut, travel nuts, linear shafts and bearings, linear guides and bearings, telescopic spring covers, bellows boot, protective tube, trunnion adapter plates, trunnion mounting brackets, motor flanges, rotary encoders, potentiometers, frequency inverters and position indicators etc.
5. Electric Linear Actuators Series: Parallel heavy duty linear actuators, In-line heavy duty linear actuators.
6. Geared Motors and Speed Reducers Series: helical gearmotors R series, helical bevel gearmotors K series, parallel shaft helical gearmotors F series, helical worm gearmotors S series, small AC gear motor series and worm gear motor reducer series.


Contact Information
JACTON Industry Co.,Ltd (VAT No.: 9144190007026567X3, registered Capital 500000CNY) is a leading manufacturer and supplier of Screw Jacks (Mechanical Actuators), Bevel Gearboxes, Lifting Systems, Electric Linear Actuators, Gearmotors and Speed Reducers, and Others Linear Motion and Power Transmission Products in China. We are Alibaba, Made-In-China and SGS (Serial NO.: QIP-ASI192186) audited manufacturer and supplier. We also have a strict quality system, with senior engineers, experienced skilled workers and practiced sales teams, we consistently provide the high quality equipments to meet the customers electro-mechanical actuation, lifting and positioning needs. JACTON Industry guarantees quality, reliability, performance and value for today's demanding industrial applications.
