• Tube Chip Color：Full Color
• IP Rating：IP65
• Pixel Pitch：4mm
• Pixel Configuration：1R, 1G, 1B
• Display Function：Video Display, Image & Text Display, Text Display, Market Display
• Average Power Consumption：250W,Sqm

=== Base Info ===

• Model NO.：JC-FSO-PH4MM
• Pixel Density：62500pixels,Sqm
• Scanning Mode：1,8 Scan
• Display Type：LED Video Display
• Application：Advertising
• Certification：CE, RoHS, CCC, ETL
• IP Rate：IP65
• LED Module Size：256X128mm
• Warranty：2years
• Power Supply：300W
• Brightness：5500nits
• Scan Method：1,8scan
• Transport Package：Wooden Case Package
• Specification：Customized
• Trademark：JC
• Origin：Shenzhen, China
• HS Code：8531200000
• Production Capacity：50000PCS Per Month

=== Description ===

NO

Item

parameter

module

1

LED encapsulation mode

SMD1921 surface mounted

2

Horizontal axis

140°

3

Vertical axis

140°

4

Pixel composition

1R1G1B

5

Pixel pitch

4mm

6

Scan method

1/8

7

Drive method

Constant current

8

Module resolution

64×32dots

9

Module size

256mm×128mm

10

Module type

Integration of lamp and drive board

11

Module working voltage

+5V

12

Module average consumption

40W

13

module maximum consumption

10W

14

module shell material

PC

15

module mask material

PC

cabinet

1

Module layout

2×4 pieces

2

Resolution

128×128 dots

3

Cabinet maximum consumption

200W

4

Cabinet average consumption

50W

5

Cabinet dimension

512mm×512mm

6

Cabinet material

Die-cast aluminum

7

Cabinet color

black/grey/yellow/red/blue

8

 Cabinet weight

 8.5kg

screen

1

Application environment

Outdoor

2

brightness

>6500cd /m²

3

White balance

X=0.29,Y=0.31

4

contrast

64000:1

5

Color Temperature

8000K

6

density

62500(dot/m²)

7

Average power consumption

217 (W/M²)

8

Maximum power consumption

868 (W/M²)

9

Power supply mode

AC220V/50HZ~AC110V/60HZ

10

Operating temperature

-20°C to +50°C

11

Operating humidity

10%~90%

12

Storage temperature

-30°C to +70°C

13

Maintenance type

Rear service

14

Refresh rate

3840Hz

15

Viewing distance

4-100m

16

Grey level/color

16.7M

17

Brightness adjustment mode

Software 100level/ automatic 100level

18

Control manner

Synchronous with the computer display

19

Distance of signal transmission

Net cable 100m

20

Computer operating system

WINDOWS(98,2000,XP,Vista,7)

21

Video signal

VGA,DVI,RF,S-Video,RGB,RGBHV,

YUV,YC,COMPOSITION etc

22

MTBF

≥10000hours

23

longevity

≥100000hours

24

certificate

UL/CE/CCC

P4 indoor 512x512mm led Cabinet

Product specifications are for reference only and subject to change without prior notice;

Please contact sales for details

At the same time, we can design according to customer requirements and production.

Company information:

JINGCAN led factory's main products areconsist of rental led display, advertising led screen,
football stadiumperimeter, stage background video wall, traffic guiding display, special-shapeddisplay
like curve and round, led moving light, led Par light, led modules andlaser light, etc.

The outstanding features of our led products areenvironmental-friendly, energy-saving and long life-span.
All of our LEDproducts have approved by CCC, CE, ROHS, FCC, ISO9001 quality certificatesauthorities.
Furthermore, our LED products were exported to more than 90countries till now such as Sweden, USA,
Brazil, France, Japan, Thailand, Italy,Australia, Spain and etc. Those LED products were widely used in
both indoorand outdoor places like hall, hotel, exhibition room, public square, symbols,building and
TV stage background and etc.

JINGCAN LED FACTORY Main LED Display Product Lines - Automatical Machines


Qualification Honor:


Product Project:


Packing and Shipping:





FAQ:
Q1. Can I have a sample order for led Screen?

A: Yes, we welcome sample order to test and check quality. Both for LED moduel or
a whole screen.

Q2. What about the lead time?

A:About 7~10 working days.

Q3. Do you have any MOQ limit for led light order?

A: Low MOQ, 1 square meter or a moudle checking is available

Q4. How do you ship the goods and how long does it take to arrive?

A: We mostly accectp FOB train term, but we can help you order and arrange shipping agent.
It usually take 20 30 day on sea. a few days for customer clearance

Q5. How to proceed an order for led Screen?

A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the design document  and places deposit for formal order.
Fourthly We arrange the production.

Q6: Do you offer guarantee for the products?

A: Yes, we offer 2 years warranty to our products.

Q7: How to deal with the faulty?

A: Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
