P6 High Brightness Outdoor Large Stage Display Screen/LED Sign/LED Board

Shenzhen Liked Development Co., Ltd / 2022-06-27

P6 High Brightness Outdoor Large Stage Display Screen/LED Sign/LED Board

  • Tube Chip Color:Full Color
  • IP Rating:Windows XP , Windows 7 , Windows 8 ,8.1 , Windows
  • Pixel Pitch:27777dots,Sqm
  • Pixel Configuration:1R, 1G, 1B
  • Display Function:Video Display, Image & Text Display, Text Display, Market Display
  • Average Power Consumption:350W , m²

=== Base Info ===

  • Model NO.:Outdoor P6-8scan
  • Pixel Density:27777dots,M2
  • Scanning Mode:1,8scan
  • Display Type:LED Video Display
  • Application:Advertising
  • Certification:CE, RoHS, CCC, ISO9001 ISO14001 FCC001 ISO14001 FCC
  • Product Name:P6-8s
  • Driver IC:Mbi5124
  • Bightness CD/Sqm:1600
  • Grey Scale:65536 Degree
  • Life Time:More 100, 000 Hours (80%)
  • Mtbf:More 50, 000 Hours
  • Operating Temperature:-30~-60t
  • Humidity:10%-95%
  • Color Temperature:6500K-9500K
  • Warranty:3 Years
  • Transport Package:Wooden Case, Flight Case, and Carton
  • Specification:320*160mm or 192*192mm
  • Trademark:hongking
  • Origin:China
  • HS Code:8528591090
  • Production Capacity:5000 Sqm,Year

=== Description ===
NO.:Product nameP6 high definition rental led display1Pixel Pitch(mm)6mm2Pixel configuration1R1G1B/SMD2121 Black lamp3Pixel density27776dots/sqm4Brightness ≥7000cd/sqm5Module size(W*H)320mm×160mm or 192mm×192mm6Module Resolution (W*H)32 dots x 16dots7Module weight400g8Cabinet size (W*H)768mm×768mm or 512mm×512mm9Drive ICMBI512410Drive mode1/8scan11Viewing Angle(V/H)140  ºC12Grey Scale65536 degree13Life time>100,000 Hours (80%)14MTBF>50,000 Hours15Operating VoltageAC110V/220V±10%17Screen Power ConsumptionMax: 800w/sqm; Average:270w/sqm18Input Power Frequency50/60Hz19Operating temperature -30--60ºC20Humidity10%-95%21Refresh Rate≥1920HZ22Control MethodSynchronized with computer monitor23Color Temperature6500K-9500K  24LED control systemLINSN,Nova-star,Colorlight is selectable25Control Distance100 m (no repeating); Optical fiber transmission: 500m- 15km26Accepting signal with video processorPAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI27Systems Operating PlatformWindows Xp / Windows 7 / windows 8 /8.1 / windows 10
P6 High Brightness Outdoor Large Stage Display Screen/LED Sign/LED Board

P6 High Brightness Outdoor Large Stage Display Screen/LED Sign/LED Board

P6 High Brightness Outdoor Large Stage Display Screen/LED Sign/LED Board

P6 High Brightness Outdoor Large Stage Display Screen/LED Sign/LED Board


P6 High Brightness Outdoor Large Stage Display Screen/LED Sign/LED Board
P6 High Brightness Outdoor Large Stage Display Screen/LED Sign/LED Board

Professional production:
Full Color LED Display,Indoor LED Display,Outdoor LED Display,Rental LED Display,Outdoor SMD LED Display,Outdoor DIP LED Display,Full Color LED Display Module,Single Color LED Display Module,Transparent LED Display,Advertising LED Screen

Company descripition:
HONGKINGLED is a publicly listed LED display manufacturer. Our facilities cover an area of 1000 square meters. Our company strives to deliver stunning LED solutions that can satisfy all customer requirements. Standardization and flexible production allow us to offer competitive prices for a wide range of high quality products. Our valued clients can enjoy the benefits of attentive service and prompt delivery. For the past 6 years, we have made steady progress.

Ingenuity and perseverance have firmly established us as pioneers in the LED display industry. Our company is dedicated to the research and development of LED related technologies. HONGKINGLED products are approved by CE, CCC, EMC and FC. We are fully certified by ISO standards.


FRQ :

1,Is your LED Display located Indoor, Semi-Outdoor or Outdoor, Mobile or Trailer (required)
 ()Indoor  ()Semi-Outdoor  ()Outdoor  ()Mobile  ()Trailer

2,What is the Length of your LED Display requirement  (required)
(  )Metres


3,What is the Height of your LED display  requirement? (required)
(  )Metres

4,What is the Optimal distance viewing to the LED Display? (required)
(  )Metres


5,What will be displayed on the LED display? (required)
()Text  ()Pictures  ()Videos  ()TV/Camera


6,I will usually program the LED display with the following frequency:
 ()Daily/Weekly & Disconnect  ()Stream Content Continually Online

7,I would like to connect to the LED display using: (required)
 ()Computer Connection control
 ()WiFi Connection control
 ()3G Connection control
