P10 Indoor Sports Stadium Billboard Advertising Perimeter LED Display

• Tube Chip Color：Full Color
• Display Function：Video Display, Image & Text Display, Text Display, Market Display
• Pixel Pitch：10mm
• Pixel Configuration：1R,1G,1B
• Pixel Density：10,000 dots , m²
• Scanning Mode：1,2 Scan

=== Base Info ===

• Model NO.：SP-P10
• System Operating Platform：Windows
• Display Type：LED Video Display
• IP Rating：IP31
• Certification：CE, RoHS, UL, CCC, ETL
• Cabinet：Alu,Steel
• Weight：50kg
• Brightness：2000nits
• Refresh Rate：>1920Hz
• Contrast Rate：3000:1
• LED Lamps：SMD 3 in 1
• Driver IC：Constent Current
• PSU：5V 60A
• System：Nova
• Voltage：AC110-240V
• Transport Package：Plywood Cases
• Specification：1280x960mm
• Trademark：LEDventure
• Origin：China
• HS Code：8528591090
• Production Capacity：2000sqm,Month

=== Description ===
Overview Product Description

Detailed Photos

All of our Product materials we choose all top quality levels, including the SMD, IC components, also the PCB, screws, PSU brands etc, so that during the led screen using, it helps to cut down after sale serive costs, to make sure led display screen stable and less aftersale services.





Item

Pixel Pitch

P10

Pixel Density

10000 pixels/M2

Pixel Configuration

SMD 3 IN 1

Module Size

320x160 mm

Module Resolution

32*16 pixels

Min.Viewing Distance

10 m

Brightness

2000nits

Viewing Angle(degree)

≤140°

Average Power Consumption

220W/M2

Scan Mode

1/2 Scan

Protection Level

IP31

Cabinet Size

1280x960 mm

Color Temperature

The brightness of R.G.B. is adjustable according to software 100level; Color temperature is adjustable in terms of detailed requirements

Input Voltage

AC110-240V, 50HZ/60HZ

Refresh Rate

>1920hz

Color

65535 Levels

Horizontal/Vertical Viewing Angle

<140°

Gray Scale

16 bits

Effective Communication Distance(without relay)

Lifespan

≥100,000 hours

Environment Temperature

Storage: -40°C~+85°C  , Operation: -20 °C~+45°C

Blind Spot Rate

<0.0001(led display industry standard is less than 0.0003)

Control Mode

Video frequency synchronization

By plywood cases, packing well and easy to load




ALL of our Product passed CE, EMC FCC, UL and other security tests, to ensure to meet most market laws and standard requires, and make sure the quality is top level and stable for many years use.
