Accuair Vu4 4corner Air Ride Suspension Valve Manifold

Yuyao Yazi Packaging Products Factory / 2022-06-24

Accuair Vu4 4corner Air Ride Suspension Valve Manifold

  • Material:Brass
  • Certification:ISO10012, BSCI, GMP, GSV, ISO13485, OHSAS18001, ISO14001, ISO,TS16949, ISO9001
  • Car Make:Volkswagen, WuLing, Benz, BMW, Hyundai, Honda, Toyota, Jeep, Nissan, Ford, Buick, Chery, Chevrolet, Cadillac, Geely, Roewe, Audi, Peugeot, Lexus, Volvo, Mazda, Kia
  • Position:Front
  • OEM:Yes
  • Type:Suspension Spring

=== Base Info ===

  • Model NO.:VU4
  • Max Working Pressure:200psi
  • Port Size:NPT3,8 NPT1,4 G3,8 G1,4
  • Orifice:3mm
  • Voltage:DC12V
  • Quality Warranty:12months
  • Customized:Size,Color,Logo
  • Transport Package:Inner Box, Outer Carton...Pallet
  • Specification:2kg
  • Trademark:VPC Pneumatic
  • Origin:China
  • HS Code:8481804090
  • Production Capacity:500000PCS,Month

=== Description ===
Compatiable Suspension Type4-Corner Full Air SuspensionVoltage Requirements  10.5-16 VoltsCurrent Requirements 1.1 Amps (for each of the (8) Valves)Connectors IP67 certified (immersion up to 3 ft)Fitting Size 3/8" D.O.T. / P.T.C (x 8), 1/2" NPT (x 4)No. of Inlet Ports 2No. of Exhaust Ports2Max Operating Pressure 200PsiCv Flow Factor 0.33Average Adjustment Time 2.2 Seconds (from 10% to 50% of travel)

1. wiring harness for easy installation

2. 3/8" press-fit D.O.T Fittings eliminate pipe threads for 100% leak free operation

3. High Pressure Rated for operation up to 200psi

4. Anodized Aluminum Manifold to prevent corrosion

5. 100% weather resistant for harsh under vehicle environments

6. For use with any brand of controller or switches
Standard or Nonstandard:Standard
Structure:Control
Pressure:High Pressure
Power:Solenoid
Material:Alloy
Temperature of Media:High Temperature
Media:Air
Port Size:1/4" 3/8" 1/2"
Place of Origin:China (Mainland)
Model Number:VVU-3L-4F
Brand Name:VPC
Application:Air Suspension, Air Suspension
