P16 Outdoor LED Module Display for LED Video Wall

• Tube Chip Color：Full Color
• IP Rating：IP65,IP54
• Pixel Pitch：16mm
• Pixel Configuration：DIP346
• Display Function：Video Display, Image & Text Display, Text Display, Market Display
• Average Power Consumption：500W,M2

=== Base Info ===

• Model NO.：p16 outdoor led display
• Pixel Density：3906DOT,M2
• Scanning Mode：Static Scan
• Display Type：LED Video Display
• Application：Cultural Square,Shopping Mall,Park
• Certification：CE, RoHS, UL, CCC, FCC
• Product Name：P16 Outdoor LED Display
• LED Lamp：Nationstar,Kinglight,Epistar
• IC：Mbi5124,Mbi5153
• Refresh Rate：960Hz-3840Hz
• Display Contrast：2500:1
• Frame Rate：60Hz,S
• Service Life：100000h
• Use Voltage：AC 90-240V
• Operating Voltage：DC5V
• Maximum Power Consumption：1000W,M2
• Transport Package：Carton,Case
• Specification：256mmX128mm
• Trademark：Honghui
• Origin：Shenzhen, China
• HS Code：8528591090
• Production Capacity：350000

=== Description ===
Product nameP16 DIP346
 outdoor led displayP16 DIP346
outdoor led displayBrightness≥7000cd/m2≥7000cd/m2Pixel compositionDIP346DIP346Half-bright angle (horizontal / vertical)120°/ 60°120°/ 60°Viewing angle (horizontal / vertical)160°/ 140°160°/ 140°Number of colors16bit16bitDiscrete control point≤0.1‰≤0.1‰Control methodsynchronize with the
video sourcesynchronize
with the video sourceWorking temperature-20~50ºC-20~50ºCWorking environment humidity10%~90%10%~90%Cell plate resolution (L * H)16*816*16Unit plate size256mmX128mm256mmX256mmCell plate current4.5A8AModule weight370g930gTransfer boardhub40hub75
2.Product Details:




3.Functions and Advantages
1. High refresh rate: With NOVA STAR  control system, no scanning line when photographed
2. High gray level: 256 RGB  each ,display 16.7M colors ,vivid and perfect video effect
3.High resolution: The most apparent features of the new generation of LED display
4.Good color uniformity: With brand Lamp  Nationstar and high refresh MBI5124 IC.
5. High Brightness: 6000-8000 cd/m2 ,brightness automatically adjusted
6. High Quality: CE, RoHs, FCC, UL, IP65, ISO9001 passed + 96 Hours serious testing  time
7. Long life span: over100,000hours, warranty from 2 to 5 years.
8. You need = We design : Provide Personal- Customized led offer .



4.Application:




5.Our Factory and Our Service :
A96 Hours Serious Testing Time B72 Hours Display Testing TimeC24 Hours Module Testing Time D24 Hours After-sales online Service E12 Hours  LED Inquiry Response TimeF8 years Professional LED display factory G5 years Excellent Domestic Big Government LED Designer H3 years Expanding International  Trade Experience

6.CERTIFICATE :



7.FAQ :
