- Light Source:LED Lamp
- Lamp Body Material:Aluminum
- Light Type:Solar
- Color Temperature:Cool White, Warm White, Pure White
- Power:15W,24W,30W,42W,60W,70W,80W,100W,120W
- Technics:Painted Matte
=== Base Info ===
- Model NO.:BR SOLAR installation of solar street lights
- Illumination Time:8h
- Cell Type:Gelled or Lead-Acid
- Charging Time (H):8
- Usage:Garden, Street
- IP Rating:IP65
- Certification:CE, RoHS, CCC, UL, ISO, FCC, EMC, GS, Soncap, Pvoc, Saso
- Voltage:24V
- With Light Source:With Light Source
- Designing Points:Hanging Type Solar Street Lights with 80W LED
- IP Level:IP68, Against Big Rain or Flood
- Quality Warranty:2 Years, 3 Years, 5years
- Pole Height:6m, 8m, 9m, 10m Solar Street Lights
- Brand Name:Br Solar Installation of Solar Street Lights
- Transport Package:Carton, Pallet, Bubble
- Specification:80W Installation Of Solar Street Light
- Trademark:BRIGHT; AS SOLAR; BR SOLAR
- Origin:China
- HS Code:94054090
- Production Capacity:5000PC,Month
=== Description ===
LED Street Lamp Producing Power 9W-250W High Lumen:150-150LM/W;Lifespan:50000-100000Hrs | * Technical Descriptions |
* Lamp Body: High-Pressure Die-Casting Aluminum. Corrosion Resistant,IP65 or IP68 |
* Application with Polyester Substance in its Surface. |
* Reflector: High Purity Aluminum or Stainless Steel SS304,Mirror Polish. |
* LED Cooler: Aluminum Material, Producing By Module |
* Cover Glass: High Strength and High Transparent Toughened Glass |
* Fastener Bolt and Screws: Stainless Steel, Anti-theft screw. |
* Ambient Temp:-40~+50°C;Humidity:10%~95% |
* Arm Diameter: 48 or 60mm |
Solar Panel 18V/36V--Poly &Mono Silicon 5W-310W |
* Before Production -Control Of Raw Material Before Use -Data Recording Of Raw Material---Products Tracebility |
* During production -Control At Each Step Of Production -Validation Of Each Step By Quality Controllers |
* After production -Systematic Flash Test On Each PV Modules -Quality Control With IEC Compliance -Tests In Our Facility Testing -Optional: Third Party Inspection Before Shipment If Needing. |
* Limited Warranty -Workmanship for 5 years,90% of minimum power output over 12 years,80% over 20 years. -The Solar Panels Are Manufactured In According To The IEC61215 Standards.Lifespan:20-25 Years |
Solar Battery 24AH~250AH/12V |
* Gelled battery, Sealed Type. Deep Cycle. Maintenance Free. |
* Real Green Power |
* Low Internal Resistance |
* Low Self-discharging Rate |
* Long-life Design |
* Wider Temperature Range |
* Extremely good discharge recovery ability |
Solar Charge Controller,IP68 Rating |
* Intellectual Control Technology Based On MCU And Special Software. |
* Adopt Tandem PWM Charge Control Method, So That The Voltage Loss Of Electrical Circuit Is Only The Half Of Diode Charge, Charge Efficiency To Improve By 3% - 6%. |
* The Over Discharging Recovery Control And Automatically Floating Charge Control Can Prolong The Battery Service Life. |
* Battery Reverse Connection Protection, Over-voltage Protection And Under-voltage Protection. |
* Solar Module Reverse Connection Protection. |
* Automatically Recovery Output, Output Over Current Protection And Out Short Circuit Protection |
* Intelligent Time Control System, It Can Set Up 1-15 Hours Timing Or Delay Time ( Set Period To Resume Current Output, Two Period Can Be Set.) |
* Light Control, Time Control, Temperature Control |
* High-precision Voltage Control For The Battery Safety Work. |
* Waterproof Design. |
Steel Pole From 3M-12M For Street Lighting. 15M-50M For High Mast Pole |
* Material -Q345B/A572,Minimum Yield Strength>=345n/mm2 -Q235B/A36,Minimum Yield Strength>=235n/mm2 |
* Shape -Round, Multi-pyramidal, Column form, Polygonal Or Conical |
* Production Process Raw Material Test→Cutting→Molding Or Bending →Welding (Longitudinal ) →Dimension Verify→Flange Welding→Hole Drilling →Calibration →Debur →Galvanization Or Powder Coating, Painting→Recalibration→Thread→Packaging |
Advantage Of Solar Street Lighting Syatem
* Green Energy,Low Power Consumptiom,Save 60%~80% Than Others.
* Higher Power,Higher Brightness Intensity,Good Color Rendition.
* Save Electricity Cost,Save Electric Transformer And Cable Cost,Free Maintanenance.
* Environmental Impact---Eliminate Hazardous Disposal,Low Light Pollution,No Radiation.
* Longer Lifetime: Between 80000-100000 Hrs,If Lighting 12Hrs/Night Could Use At Least 12-22 Years.
* Less Heat Generated Compared To Other Sourses.
* Downward Orientation Of Light Could Adjust Lighting Angles And Lighting Range And Shape On The Ground To Meet The Road-rectangular,Other Lighting Source Just Could Give Common Round Shape And Small Lighting Range.
Payment & Delivery
Payment Terms | T/T(perfered) | EXW | 30% In Advance, 70% Balance Paid Before Delivery |
FOB |
CFR/C&F | 30% In Advance, 70% Against Copy Of B/L |
CIF |
L/C | Total Amount Above USD100,000, We Accept L/C At Sight |
West Union | Total Amount Less Than USD1,000 |
PayPal |
Delivery Time | 15-20 Working Days After Receiving Down Payment For One Container. |
