Dimmable Mini LED Neon Flex Strip

Foshan Baoshengyuan Packaging Factory / 2022-06-27

Dimmable Mini LED Neon Flex Strip

  • Certification:UL, EMC, RoHS, CE, IP68
  • Power:12W
  • Emitting Color:6000K,5000K, 4000K,3000K,2700K,2200K
  • Voltage:24V
  • IP Rating:IP68
  • Product Name:Mini LED Neon Flex

=== Base Info ===

  • Model NO.:F15 Mono color
  • Warranty:3 Years
  • Lamp Body Material:PVC
  • LED Type:SMD5050
  • LEDs Qty/M:60LEDs
  • CRI:>80
  • Max Length:20m
  • Cutting Length:10cm
  • Life Span:50000h
  • Working Temperature:-30°c to +45°c
  • Transport Package:Nutural Packing
  • Specification:11.5*20mm
  • Trademark:OLYMPIA
  • Origin:China
  • HS Code:9405409000
  • Production Capacity:50000m,Month

=== Description ===
Model: F15-24V-5050-72F15-24V-5050-60F15-24V-2835-72-CCF15-36V-5050-60F15-24V-3528-72F15-12V-3528-72Working Voltage: 24V DC24V DC24V DC36V DC24V DC12V DCPower per Meter: 15W12W/10W12W12W5W5WWorking Mode: CVCVCC IC built-inCVCVCVLED Type: SMD5050SMD5050SMD2835SMD5050SMD3528SMD3528LED Qty / meter: 72PCS60PCS72PCS60PCS72PCS72PCSAvailable CT: 2200-6500K2200-6500K2200-6500K2200-6500K2200-6500K2200-6500KAvailable Colors: G/B/LY/PG/B/LY/P/A/R/OG/B/LY/PG/B/LY/PG/B/P/R/A/OG/B/P/R/A/OMin. Cutting Unit: 6LEDs6LEDs/10LEDs6LEDs10LEDs12LEDs6LEDsMin. Cutting Length: 8.33cm10cm/16.67cm8.33cm16.67cm6.6"/16.67cm3.3"/8.33cmMax Length Single Feed: 26.24'/8m33'/10m49.2'/15m49.2'/15m49.2'/15m22.96'/7mMax Length Double Feed: 52.49'/16m65.62'/20m98.43'/30m98.43'/30m98.43'/30m45.93'/14mLumen Maintenance: 70, 000 Hours L70@ 25°C, 50, 000 Hours L70@ 50°CMaterial: Eco PVCProtection Rating: IP68Min. Bending: Dia 8cmBeam Angle: 120°Dimmable: YesBending Direction: HorizontallyInstallation Temp.: 0°C to +55°CAmbient Temp.: -25°C to +55°CWarranty: 3 or 5 Years
