Hardened Tooth Surface Helical Gearbox with Hollow Output Shaft

HEBEI TILANG METALWARE SALES CO., LTD. / 2022-06-27

Hardened Tooth Surface Helical Gearbox with Hollow Output Shaft

  • Application:Machinery, Agricultural Machinery, Industrial Machinery
  • Hardness:Hardened Tooth Surface
  • Installation:Vertical or Horizotal Type
  • Layout:Parallel
  • Gear Shape:Involute
  • Step:Three-Step

=== Base Info ===

  • Model NO.:FA87-Y80N4-0.75-198.31-M1
  • Type:Helical Gear
  • Color:Blue, Grey, Customerized
  • Size:F37-157
  • Ratio:3.97-228.99
  • Output Torque:200-1800 Nm
  • Quality Guarantee:1 -5 Year
  • Quality System:ISO9001-2008
  • Transport Package:Wooden Case , Polywood Case , Carton
  • Specification:CE SGS, ISO
  • Trademark:Starshine Drive
  • Origin:China
  • HS Code:8483409000
  • Production Capacity:5000PCS,Month

=== Description ===

Basic Info.

Model NO. FA87-Y80N4-0.75-198.31-M1 Type Helical Gear Color Blue/ Grey/ Customerized Size F37-157 Ratio 3.97-228.99 Output Torque 200-1800 Nm Quality Guarantee 1 -5 Year Quality System ISO9001-2008 Transport Package Wooden Case / Polywood Case / Carton Specification CE SGS, ISO Trademark Starshine Drive Origin China HS Code 8483409000 Production Capacity 5000PCS/Month

Product Description

Starshine Drive F series Parallel Shaft-Helical Geared Motor
Features:
-High efficiency: 92%-94%;
-Parallel output, compact structure, large output torque, smooth operation, low noise and long service life.
-High precision: the gear is made of high-quality alloy steel forging, carbonitriding and hardening treatment, grinding process to ensure high precision and stable running.
-High interchangeability: highly modular, serial design, strong versatility and interchangeability.
Hardened Tooth Surface Helical Gearbox with Hollow Output Shaft
Technical parameters
Ratio3.77-276.77
Input power0.12-200KW
Output torque3.5-21700N.m
Output speed5-352rpm
Mounting typeFoot mounted, foot mounted with solid shaft, output flange mounted, hollow shaft mounted, B5 flange mounted with hollow shaft, foot mounted with hollow shaft, B14 flange mounted with hollow shaft, foot mounted with splined hole, foot mounted with shrink disk, hollow shaft mounted with anti-torque arm.
Input MethodFlange input(AM), shaft input(AD), inline AC motor input, or AQA servo motor
Brake ReleaseHF-manual release(lock in the brake release position), HR-manual release(autom-atic braking position)
ThermistorTF(Thermistor protection PTC thermisto)
TH(Thermistor protection Bimetal swotch)
Mounting PositionM1, M2, M3, M4, M5, M6
TypeF37-F157
Output shaft dis.25mm, 30mm, 35mm, 40mm, 50mm, 60mm, 70mm, 90mm, 110mm, 120mm
Housing materialHT200 high-strength cast iron from R37,47,57,67,77,87
Housing materialHT250 High strength cast iron from R97 107,137,147,
157,167,187
Heat treatment technologycarbonitriding and hardening treatment
Efficiency92%-94%
LubricantVG220
Protection ClassIP55, F class

About Starshine Drive
Hardened Tooth Surface Helical Gearbox with Hollow Output Shaft


Guangdong Starshine Drive Co.,Ltd(Starshine) have a strong technical force with over 350 employees at present, including over 30 engineering technicians, 30 quality inspectors, covering an area of 80000 square meters and kinds of advanced processing machines and testing equipments. We have a good foundation for the industry application development and service of high-end speed reducers & variators owning to the provincial engineering technology research center,the lab of gear speed reducers, and the base of modern R&D.

Our
 products are widely used in ceramic industry, glass industry, woodworking machinery , high voltage switch, food & beverage, packaging & printing, Storage & logistics, hoisting & transportation facilities…etc , and Starshine technically provide the professional product & service for the medium and high-end customers, and our gearboxes are best-selling in domestic, and even in abroad , such as in Europe, North America, South America, Middle East, South Asia, Southeast Asia, Africa…etc.


 In the future , Starshine will hold the creed of "serving customer, diligence & simplicity, self-criticism, innovation, honesty, teamwork", and the concept of "quality creates value" to focus on the customers' requirements and provide them the competitive transmission solution and create value for them constantly, and make a high-end equipment manufacturing industry and create a preferred brand of replacing import products and upgrading continuously for the end users.
