Helical Compound Gear with High-Density Is Used for Industry Equipment

• Application：Electric Cars, Motorcycle, Machinery, Marine, Agricultural Machinery, Industry
• Hardness：75rb to 95rb
• Gear Position：Customized
• Manufacturing Method：Sintered Gear
• Toothed Portion Shape：Compund Gear
• Material：Powder Metallurgy

=== Base Info ===

• Model NO.：GR-009
• Type：Circular Gear
• Agma 2000：Pinion 10 Tooth, Gear 31 Tooth
• Manipulate Way：Robotics
• Changes Way：Sintered
• Transport Package：Caron or According to Client′s Request
• Specification：according to client′s drawing or samples
• Trademark：hengfeng
• Origin：Zhejiang, China
• HS Code：87089900
• Production Capacity：80, 000, 000PCS

=== Description ===

Basic Info.

Model NO. GR-009 Type Circular Gear Agma 2000 Pinion 10 Tooth, Gear 31 Tooth Manipulate Way Robotics Changes Way Sintered Transport Package Caron or According to Client′s Request Specification according to client′s drawing or samples Trademark hengfeng Origin Zhejiang, China HS Code 87089900 Production Capacity 80, 000, 000PCS

Product Description

1. Our products passed TS16949 ISO-9001: 2000 quality management system verification
2. We own exquisite and advanced equipment, professional technical designer and rich producing experience
3. We can produce different size and shapes base on your drawing and samples.
4. Best quality, competitive price, shortest delivery time and good service.
5. Products are widely used at automotive part, textile machine, sewing machine, gasoline generator, power tools, oil pump rotor, clutch, oilless bearing, cu base products, stainless steels and so on.
6. If you are interested in our products and our company, please kindly let us know what you need, please donot hesitate to contact with us.

Gear data	pinion	gear
tooth form	AGMA 2000	AGMA2000
diameteral pitch	48	48
no. of teeth	10	31
pitch dia ref	2083	6458
pressure angle	20 degree	20 degree
O.D +.000/-.0003	1042	3229
agma class	8	8
T.T.C	.0010	.0010
T.C.V	.0020	.0020

Density:6.8 to 7.2 GM/CC
Tensile:70,000 to 90,000PSI
Key Specifications/Special Features:
Materials: steel, copper, bronze and alloy
Process: mixing, compacting, sintering, resizing, cleaning,vacuum oiling and packing
High density and precision
Nice abrasion resistance and hardness
Excellent transmission gear
Widely used in automobiles, motorcycles and many other fieldslike transmission gears, spur gears, bevel gears, helical gears,copper sleeves, sleeve bearing, bushing, bush, pulley, timingpulley, structural parts, powder metallurgy parts, nut, auto parts,rotor and stator
Customized drawings or requirements are accepted
