- Type：Engine Bearing
- Material：Stainless Steel
- Tolerance：P6
- Certification：ISO9001
- Clearance：C0
- ABS：Without ABS
=== Base Info ===
- Model NO.：NU302EC,P63HWS
- Brand：Tfn
- Car Make：BMW
- Rolling Body：Roller Bearings
- The Number of Rows：Single
- Outer Dimension：42mm
- Spherical：Non-Aligning Bearings
- Load Direction：Radial Bearing
- Separated：Unseparated
- Product Name：Single Row Cylindrical Roller Bearing Nu302ec,P63h
- Size：15*42*13mm
- Weight：0.0984kg
- Vibration：Zv1, Zv2, Zv3, or as Requested
- Transport Package：Single Box Packaging,OEM
- Specification：15*42*13mm
- Trademark：TFN,OEM
- Origin：China
- HS Code：8482500090
- Production Capacity：10000,Month
=== Description ===
Quality Control Process
1.Assembly | | 2.Windage test2.Windage test |
| 3.Cleaning |
| 4.Rotary test |
| 5.Greasing and gland |
| 6.Noise inspection |
| 7.Appearance inspection |
| 8.Rust prevention |
| 9.Product packaging |
| Application | low noise machine,automobile,motorcycle,and the general machinery and etc. |
Limiting speeds(rpm)Mass(Kg) | | | | d | D | B | rs min | rs1 min | Cr | Cor | Grease | Oil | (Approx.) |
| NU10 Series | NU1005 | 25 | 47 | 12 | 0.6 | 0.3 | 15.1 | 14.1 | 16,000 | 19,000 | 0.092 |
| | NU1006 | 30 | 55 | 13 | 1 | 0.6 | 19.7 | 19.6 | 14,000 | 16,000 | 0.13 |
| | NU1007 | 35 | 62 | 14 | 1 | 0.6 | 22.6 | 23.2 | 12,000 | 15,000 | 0.179 |
| | NU1008 | 40 | 68 | 15 | 1 | 0.6 | 27.3 | 29 | 11,000 | 13,000 | 0.22 |
| | NU1009 | 45 | 75 | 16 | 1 | 0.6 | 31 | 34 | 9,900 | 12,000 | 0.28 |
| | NU1010 | 50 | 80 | 16 | 1 | 0.6 | 32 | 36 | 8,900 | 11,000 | 0.295 |
| | NU1011 | 55 | 90 | 18 | 1.1 | 1 | 37.5 | 44 | 8,200 | 9,700 | 0.442 |
| | NU1012 | 60 | 95 | 18 | 1.1 | 1 | 40 | 48.5 | 7,500 | 8,800 | 0.474 |
| | NU1013 | 65 | 100 | 18 | 1.1 | 1 | 41 | 51 | 7,000 | 8,200 | 0.485 |
| | NU1014 | 70 | 110 | 20 | 1.1 | 1 | 58.5 | 70.5 | 6,500 | 7,600 | 0.699 |
| | NU1015 | 75 | 115 | 20 | 1.1 | 1 | 60 | 74.5 | 6,100 | 7,100 | 0.738 |
| | NU1016 | 80 | 125 | 22 | 1.1 | 1 | 72.5 | 90.5 | 5,700 | 6,700 | 0.98 |
| | NU1017 | 85 | 130 | 22 | 1.1 | 1 | 74.5 | 95.5 | 5,400 | 6,300 | 1.03 |
| | NU1018 | 90 | 140 | 24 | 1.5 | 1.1 | 88 | 114 | 5,100 | 5,900 | 1.33 |
| | NU1019 | 95 | 145 | 24 | 1.5 | 1.1 | 90.5 | 120 | 4,800 | 5,600 | 1.4 |
| | NU1020 | 100 | 150 | 24 | 1.5 | 1.1 | 93 | 126 | 4,600 | 5,400 | 1.45 |
| | NU1021 | 105 | 160 | 26 | 2 | 1.1 | 105 | 142 | 4,300 | 5,100 | 1.84 |
| | NU1022 | 110 | 170 | 28 | 2 | 1.1 | 131 | 174 | 4,100 | 4,800 | 2.33 |
| | NU1024 | 120 | 180 | 28 | 2 | 1.1 | 139 | 191 | 3,800 | 4,400 | 2.44 |
| | NU1026 | 130 | 200 | 33 | 2 | 1.1 | 172 | 238 | 3,400 | 4,000 | 3.69 |
| | NU1028 | 140 | 210 | 33 | 2 | 1.1 | 176 | 250 | 3,200 | 3,800 | 4.05 |
| | NU1030 | 150 | 225 | 35 | 2.1 | 1.5 | 202 | 294 | 3,000 | 3,500 | 4.77 |
| | NU1080 | 400 | 600 | 90 | 5 | 5 | 1400 | 2310 | 780 | 920 | 88.4 |
| NU2 Series | NU204E | 20 | 47 | 14 | 1 | 0.6 | 25.7 | 22.6 | 15,000 | 18,000 | 0.122 |
| | NU205E | 25 | 52 | 15 | 1 | 0.6 | 29.3 | 27.7 | 13,000 | 15,000 | 0.151 |
| | NU206E | 30 | 62 | 16 | 1 | 0.6 | 39 | 37.5 | 11,000 | 13,000 | 0.226 |
| | NU207E | 35 | 72 | 17 | 1.1 | 0.6 | 50.5 | 50 | 9,500 | 11,000 | 0.327 |
| | NU208 | 40 | 80 | 18 | 1.1 | 1.1 | 43.5 | 43 | 9,400 | 11,000 | 0.378 |
| | NU208E | 40 | 80 | 18 | 1.1 | 1.1 | 55.5 | 55.5 | 8,500 | 10,000 | 0.426 |
| | NU209 | 45 | 85 | 19 | 1.1 | 1.1 | 46 | 47 | 8,400 | 9,900 | 0.432 |
| | NU209E | 45 | 85 | 19 | 1.1 | 1.1 | 63 | 66.5 | 7,600 | 9,000 | 0.495 |
| | NU210 | 50 | 90 | 20 | 1.1 | 1.1 | 48 | 51 | 7,600 | 9,000 | 0.47 |
| | NU210E | 50 | 90 | 20 | 1.1 | 1.1 | 66 | 72 | 6,900 | 8,100 | 0.54 |
| | NU211 | 55 | 100 | 21 | 1.5 | 1.1 | 58 | 62.5 | 6,900 | 8,200 | 0.638 |
| | NU211E | 55 | 100 | 21 | 1.5 | 1.1 | 82.5 | 93 | 6,300 | 7,400 | 0.718 |
| | NU212 | 60 | 110 | 22 | 1.5 | 1.5 | 68.5 | 75 | 6,400 | 7,600 | 0.818 |
| | NU212E | 60 | 110 | 22 | 1.5 | 1.5 | 97.5 | 107 | 5,800 | 6,800 | 0.923 |
| | NU213 | 65 | 120 | 23 | 1.5 | 1.5 | 84 | 94.5 | 5,900 | 7,000 | 1.02 |
| | NU213E | 65 | 120 | 23 | 1.5 | 1.5 | 108 | 119 | 5,400 | 6,300 | 1.21 |
| | NU214 | 70 | 125 | 24 | 1.5 | 1.5 | 83.5 | 95 | 5,500 | 6,500 | 1.12 |
| | NU214E | 70 | 125 | 24 | 1.5 | 1.5 | 119 | 137 | 5,000 | 5,900 | 1.3 |
| | NU215 | 75 | 130 | 25 | 1.5 | 1.5 | 96.5 | 111 | 5,100 | 6,000 | 1.23 |
| | NU215E | 75 | 130 | 25 | 1.5 | 1.5 | 130 | 156 | 4,700 | 5,500 | 1.41 |
| | NU216 | 80 | 140 | 26 | 2 | 2 | 106 | 122 | 4,800 | 5,700 | 1.5 |
| | NU216E | 80 | 140 | 26 | 2 | 2 | 139 | 167 | 4,400 | 5,100 | 1.67 |
| | NU217 | 85 | 150 | 28 | 2 | 2 | 120 | 140 | 4,500 | 5,300 | 1.87 |
| | NU217E | 85 | 150 | 28 | 2 | 2 | 167 | 199 | 4,100 | 4,800 | 2.11 |
| | NU218 | 90 | 160 | 30 | 2 | 2 | 152 | 178 | 4,300 | 5,000 | 2.3 |
| | NU218E | 90 | 160 | 30 | 2 | 2 | 182 | 217 | 3,900 | 4,600 | 2.44 |
| | NU219 | 95 | 170 | 32 | 2.1 | 2.1 | 166 | 195 | 4,000 | 4,700 | 2.78 |
| | NU219E | 95 | 170 | 32 | 2.1 | 2.1 | 220 | 265 | 3,600 | 4,300 | 3.02 |
| | NU220 | 100 | 180 | 34 | 2.1 | 2.1 | 183 | 217 | 3,800 | 4,500 | 3.33 |
| | NU220E | 100 | 180 | 34 | 2.1 | 2.1 | 249 | 305 | 3,500 | 4,100 | 3.66 |
| | NU221 | 105 | 190 | 36 | 2.1 | 2.1 | 201 | 241 | 3,600 | 4,300 | 3.95 |
| | NU222 | 110 | 200 | 38 | 2.1 | 2.1 | 240 | 290 | 3,400 | 4,000 | 4.63 |
| | NU224 | 120 | 215 | 40 | 2.1 | 2.1 | 260 | 320 | 3,200 | 3,700 | 5.57 |
| | NU224E | 120 | 215 | 40 | 2.1 | 2.1 | 335 | 420 | 2,900 | 3,400 | 5.97 |
| | NU226 | 130 | 230 | 40 | 3 | 3 | 270 | 340 | 2,900 | 3,400 | 6.3 |
| | NU226E | 130 | 230 | 40 | 3 | 3 | 365 | 455 | 2,600 | 3,100 | 6.9 |
| | NU228 | 140 | 250 | 42 | 3 | 3 | 310 | 400 | 2,700 | 3,100 | 7.88 |
| | NU228E | 140 | 250 | 42 | 3 | 3 | 395 | 515 | 2,400 | 2,800 | 8.73 |
| | NU230 | 150 | 270 | 45 | 3 | 3 | 345 | 435 | 2,500 | 2,900 | 9.92 |
| | NU230E | 150 | 270 | 45 | 3 | 3 | 450 | 595 | 2,200 | 2,600 | 11 |
| NU22 Series | NU2204E | 20 | 47 | 18 | 1 | 0.6 | 30.5 | 28.3 | 14,000 | 16,000 | 0.158 |
| | NU2205E | 25 | 52 | 18 | 1 | 0.6 | 35 | 34.5 | 11,000 | 13,000 | 0.186 |
| | NU2206E | 30 | 62 | 20 | 1 | 0.6 | 49 | 50 | 9,700 | 11,000 | 0.297 |
| | NU2207E | 35 | 72 | 23 | 1.1 | 0.6 | 61.5 | 65.5 | 8,500 | 10,000 | 0.455 |
| | NU2208 | 40 | 80 | 23 | 1.1 | 1.1 | 58 | 62 | 8,500 | 10,000 | 0.49 |
| | NU2208E | 40 | 80 | 23 | 1.1 | 1.1 | 72.5 | 77.5 | 7,600 | 8,900 | 0.552 |
| | NU2209 | 45 | 85 | 23 | 1.1 | 1.1 | 61.5 | 68 | 7,600 | 9,000 | 0.53 |
| | NU2209E | 45 | 85 | 23 | 1.1 | 1.1 | 76 | 84.5 | 6,800 | 8,000 | 0.6 |
| | NU2210 | 50 | 90 | 23 | 1.1 | 1.1 | 64 | 73.5 | 6,900 | 8,100 | 0.571 |
| | NU2210E | 50 | 90 | 23 | 1.1 | 1.1 | 79.5 | 91.5 | 6,200 | 7,300 | 0.652 |
| | NU2211 | 55 | 100 | 25 | 1.5 | 1.1 | 75.5 | 87 | 6,300 | 7,400 | 0.773 |
| | NU2211E | 55 | 100 | 25 | 1.5 | 1.1 | 97 | 114 | 5,600 | 6,600 | 0.968 |
| | NU2212 | 60 | 110 | 28 | 1.5 | 1.5 | 96 | 116 | 5,800 | 6,800 | 1.06 |
| | NU2212E | 60 | 110 | 28 | 1.5 | 1.5 | 131 | 157 | 5,200 | 6,100 | 1.21 |
| | NU2213 | 65 | 120 | 31 | 1.5 | 1.5 | 120 | 149 | 5,400 | 6,300 | 1.4 |
| | NU2213E | 65 | 120 | 31 | 1.5 | 1.5 | 149 | 181 | 4,800 | 5,600 | 1.6 |
| | NU2214 | 70 | 125 | 31 | 1.5 | 1.5 | 119 | 151 | 5,000 | 5,900 | 1.47 |
| | NU2214E | 70 | 125 | 31 | 1.5 | 1.5 | 156 | 194 | 4,500 | 5,200 | 1.7 |
| | NU2215 | 75 | 130 | 31 | 1.5 | 1.5 | 130 | 162 | 4,700 | 5,500 | 1.55 |
| | NU2215E | 75 | 130 | 31 | 1.5 | 1.5 | 162 | 207 | 4,200 | 4,900 | 1.79 |
| | NU2216 | 80 | 140 | 33 | 2 | 2 | 147 | 186 | 4,400 | 5,100 | 1.93 |
| | NU2216E | 80 | 140 | 33 | 2 | 2 | 186 | 243 | 3,900 | 4,600 | 2.12 |
| | NU2217 | 85 | 150 | 36 | 2 | 2 | 170 | 218 | 4,100 | 4,800 | 2.44 |
| | NU2217E | 85 | 150 | 36 | 2 | 2 | 217 | 279 | 3,700 | 4,300 | 2.68 |
| | NU2218 | 90 | 160 | 40 | 2 | 2 | 197 | 248 | 3,900 | 4,600 | 3.1 |
| | NU2218E | 90 | 160 | 40 | 2 | 2 | 242 | 315 | 3,500 | 4,100 | 3.33 |
| | NU2219 | 95 | 170 | 43 | 2.1 | 2.1 | 230 | 298 | 3,600 | 4,300 | 3.79 |
| | NU2219E | 95 | 170 | 43 | 2.1 | 2.1 | 286 | 370 | 3,300 | 3,800 | 4.14 |
| | NU2220 | 100 | 180 | 46 | 2.1 | 2.1 | 258 | 340 | 3,500 | 4,100 | 4.57 |
| | NU2220E | 100 | 180 | 46 | 2.1 | 2.1 | 335 | 445 | 3,100 | 3,600 | 5.01 |
| | NU2222 | 110 | 200 | 53 | 2.1 | 2.1 | 320 | 415 | 3,100 | 3,700 | 6.56 |
| | NU2222E | 110 | 200 | 53 | 2.1 | 2.1 | 385 | 515 | 2,800 | 3,300 | 7.4 |
| | NU2224 | 120 | 215 | 58 | 2.1 | 2.1 | 350 | 460 | 2,900 | 3,400 | 8.19 |
| | NU2224E | 120 | 215 | 58 | 2.1 | 2.1 | 450 | 620 | 2,600 | 3,000 | 9.18 |
| | NU2226 | 130 | 230 | 64 | 3 | 3 | 380 | 530 | 2,600 | 3,100 | 10.2 |
| | NU2226E | 130 | 230 | 64 | 3 | 3 | 530 | 735 | 2,300 | 2,700 | 11.8 |
| | NU2228 | 140 | 250 | 68 | 3 | 3 | 445 | 635 | 2,400 | 2,800 | 12.9 |
| | NU2228E | 140 | 250 | 68 | 3 | 3 | 575 | 835 | 2,100 | 2,500 | 15.8 |
| | NU222E | 110 | 200 | 38 | 2.1 | 2.1 | 293 | 365 | 3,100 | 3,700 | 4.27 |
| | NU2230 | 150 | 270 | 73 | 3 | 3 | 500 | 710 | 2,200 | 2,600 | 16.3 |
| | NU2230E | 150 | 270 | 73 | 3 | 3 | 660 | 980 | 2,000 | 2,400 | 19.7 |
| NU3 Series | NU304E | 20 | 52 | 15 | 1.1 | 0.6 | 31.5 | 26.9 | 13,000 | 15,000 | 0.176 |
| | NU305E | 25 | 62 | 17 | 1.1 | 1.1 | 41.5 | 37.5 | 11,000 | 13,000 | 0.275 |
| | NU306E | 30 | 72 | 19 | 1.1 | 1.1 | 53 | 50 | 9,300 | 11,000 | 0.398 |
| | NU307E | 35 | 80 | 21 | 1.5 | 1.1 | 71 | 71 | 8,100 | 9,600 | 0.545 |
| | NU308 | 40 | 90 | 23 | 1.5 | 1.5 | 58.5 | 57 | 8,000 | 9,400 | 0.658 |
| | NU308E | 40 | 90 | 23 | 1.5 | 1.5 | 83 | 81.5 | 7,200 | 8,500 | 0.754 |
| | NU309 | 45 | 100 | 25 | 1.5 | 1.5 | 74 | 71 | 7,200 | 8,400 | 0.877 |
| | NU309E | 45 | 100 | 25 | 1.5 | 1.5 | 97.5 | 98.5 | 6,500 | 7,600 | 0.996 |
| | NU310 | 50 | 110 | 27 | 2 | 2 | 87 | 86 | 6,500 | 7,700 | 1.14 |
| | NU310E | 50 | 110 | 27 | 2 | 2 | 110 | 113 | 5,900 | 6,900 | 1.3 |
| | NU311 | 55 | 120 | 29 | 2 | 2 | 111 | 111 | 5,900 | 7,000 | 1.45 |
| | NU311E | 55 | 120 | 29 | 2 | 2 | 137 | 143 | 5,300 | 6,300 | 1.65 |
| | NU312 | 60 | 130 | 31 | 2.1 | 2.1 | 124 | 126 | 5,500 | 6,500 | 1.8 |
| | NU312E | 60 | 130 | 31 | 2.1 | 2.1 | 150 | 157 | 4,900 | 5,800 | 2.05 |
| | NU313 | 65 | 140 | 33 | 2.1 | 2.1 | 135 | 139 | 5,100 | 6,000 | 2.23 |
| | NU313E | 65 | 140 | 33 | 2.1 | 2.1 | 181 | 191 | 4,600 | 5,400 | 2.54 |
| | NU314 | 70 | 150 | 35 | 2.1 | 2.1 | 158 | 168 | 4,700 | 5,500 | 2.71 |
| | NU314E | 70 | 150 | 35 | 2.1 | 2.1 | 205 | 222 | 4,200 | 5,000 | 3.1 |
| | NU315 | 75 | 160 | 37 | 2.1 | 2.1 | 190 | 205 | 4,400 | 5,200 | 3.28 |
| | NU315E | 75 | 160 | 37 | 2.1 | 2.1 | 240 | 263 | 4,000 | 4,700 | 3.74 |
| | NU316 | 80 | 170 | 39 | 2.1 | 2.1 | 190 | 207 | 4,100 | 4,800 | 3.86 |
| | NU316E | 80 | 170 | 39 | 2.1 | 2.1 | 256 | 282 | 3,700 | 4,400 | 4.22 |
| | NU317 | 85 | 180 | 41 | 3 | 3 | 212 | 228 | 3,900 | 4,600 | 4.54 |
| | NU317E | 85 | 180 | 41 | 3 | 3 | 291 | 330 | 3,500 | 4,100 | 4.81 |
| | NU318 | 90 | 190 | 43 | 3 | 3 | 240 | 265 | 3,700 | 4,300 | 5.3 |
| | NU318E | 90 | 190 | 43 | 3 | 3 | 315 | 355 | 3,300 | 3,900 | 5.72 |
| | NU319 | 95 | 200 | 45 | 3 | 3 | 259 | 285 | 3,400 | 4,000 | 6.13 |
| | NU319E | 95 | 200 | 45 | 3 | 3 | 335 | 385 | 3,100 | 3,600 | 6.62 |
| | NU320 | 100 | 215 | 47 | 3 | 3 | 299 | 335 | 3,300 | 3,800 | 7.49 |
| | NU320E | 100 | 215 | 47 | 3 | 3 | 380 | 425 | 2,900 | 3,500 | 8.57 |
| | NU321 | 105 | 225 | 49 | 3 | 3 | 320 | 360 | 3,100 | 3,700 | 8.53 |
| | NU322 | 110 | 240 | 50 | 3 | 3 | 360 | 400 | 3,000 | 3,500 | 10 |
| | NU322E | 110 | 240 | 50 | 3 | 3 | 450 | 525 | 2,700 | 3,100 | 11.1 |
| | NU324 | 120 | 260 | 55 | 3 | 3 | 450 | 510 | 2,700 | 3,200 | 12.8 |
| | NU324E | 120 | 260 | 55 | 3 | 3 | 530 | 610 | 2,400 | 2,800 | 13.9 |
| | NU326 | 130 | 280 | 58 | 4 | 4 | 560 | 665 | 2,500 | 2,900 | 17.4 |
| | NU326E | 130 | 280 | 58 | 4 | 4 | 615 | 735 | 2,200 | 2,600 | 19.4 |
| | NU328 | 140 | 300 | 62 | 4 | 4 | 615 | 745 | 2,300 | 2,700 | 21.2 |
| | NU328E | 140 | 300 | 62 | 4 | 4 | 665 | 795 | 2,100 | 2,400 | 23.2 |
| | NU330 | 150 | 320 | 65 | 4 | 4 | 665 | 805 | 2,100 | 2,500 | 25.3 |
| | NU330E | 150 | 320 | 65 | 4 | 4 | 760 | 920 | 1,900 | 2,300 | 28.4 |
| NU23 Series | NU2304E | 20 | 52 | 21 | 1.1 | 0.6 | 42 | 39 | 12,000 | 14,000 | 0.242 |
| | NU2305E | 25 | 62 | 24 | 1.1 | 1.1 | 57 | 56 | 9,700 | 11,000 | 0.386 |
| | NU2306E | 30 | 72 | 27 | 1.1 | 1.1 | 74.5 | 77.5 | 8,300 | 9,700 | 0.58 |
| | NU2307E | 35 | 80 | 31 | 1.5 | 1.1 | 99 | 109 | 7,200 | 8,500 | 0.78 |
| | NU2308 | 40 | 90 | 33 | 1.5 | 1.5 | 82.5 | 88 | 7,000 | 8,200 | 0.951 |
| | NU2308E | 40 | 90 | 33 | 1.5 | 1.5 | 114 | 122 | 6,400 | 7,500 | 1.06 |
| | NU2309 | 45 | 100 | 36 | 1.5 | 1.5 | 99 | 104 | 6,300 | 7,400 | 1.27 |
| | NU2309E | 45 | 100 | 36 | 1.5 | 1.5 | 137 | 153 | 5,700 | 6,800 | 1.41 |
| | NU2310 | 50 | 110 | 40 | 2 | 2 | 121 | 131 | 5,700 | 6,700 | 1.7 |
| | NU2310E | 50 | 110 | 40 | 2 | 2 | 163 | 187 | 5,200 | 6,100 | 1.9 |
| | NU2311 | 55 | 120 | 43 | 2 | 2 | 148 | 162 | 5,200 | 6,100 | 2.17 |
| | NU2311E | 55 | 120 | 43 | 2 | 2 | 201 | 233 | 4,700 | 5,600 | 2.37 |
| | NU2312 | 60 | 130 | 46 | 2.1 | 2.1 | 169 | 188 | 4,800 | 5,700 | 2.71 |
| | NU2312E | 60 | 130 | 46 | 2.1 | 2.1 | 222 | 262 | 4,400 | 5,200 | 2.96 |
| | NU2313 | 65 | 140 | 48 | 2.1 | 2.1 | 188 | 212 | 4,400 | 5,200 | 3.27 |
| | NU2313E | 65 | 140 | 48 | 2.1 | 2.1 | 248 | 287 | 4,100 | 4,800 | 3.48 |
| | NU2314 | 70 | 150 | 51 | 2.1 | 2.1 | 223 | 262 | 4,100 | 4,800 | 3.98 |
| | NU2314E | 70 | 150 | 51 | 2.1 | 2.1 | 274 | 325 | 3,800 | 4,400 | 4.25 |
| | NU2315 | 75 | 160 | 55 | 2.1 | 2.1 | 258 | 300 | 3,800 | 4,500 | 4.87 |
| | NU2315E | 75 | 160 | 55 | 2.1 | 2.1 | 330 | 395 | 3,500 | 4,100 | 5.25 |
| | NU2316 | 80 | 170 | 58 | 2.1 | 2.1 | 274 | 330 | 3,600 | 4,200 | 5.79 |
| | NU2316E | 80 | 170 | 58 | 2.1 | 2.1 | 355 | 430 | 3,300 | 3,900 | 6.25 |
| | NU2317 | 85 | 180 | 60 | 3 | 3 | 315 | 380 | 3,400 | 4,000 | 6.7 |
| | NU2317E | 85 | 180 | 60 | 3 | 3 | 395 | 485 | 3,100 | 3,700 | 7.16 |
| | NU2318 | 90 | 190 | 64 | 3 | 3 | 325 | 395 | 3,200 | 3,800 | 7.95 |
| | NU2318E | 90 | 190 | 64 | 3 | 3 | 435 | 535 | 2,900 | 3,400 | 8.56 |
| | NU2319 | 95 | 200 | 67 | 3 | 3 | 370 | 460 | 3,000 | 3,500 | 9.2 |
| | NU2319E | 95 | 200 | 67 | 3 | 3 | 460 | 585 | 2,700 | 3,200 | 9.8 |
| | NU2320 | 100 | 215 | 73 | 3 | 3 | 410 | 505 | 2,900 | 3,400 | 11.7 |
| | NU2320E | 100 | 215 | 73 | 3 | 3 | 570 | 715 | 2,600 | 3,100 | 12.8 |
| | NU2322 | 110 | 240 | 80 | 3 | 3 | 605 | 790 | 2,600 | 3,100 | 17.1 |
| | NU2322E | 110 | 240 | 80 | 3 | 3 | 675 | 880 | 2,400 | 2,800 | 19.4 |
| | NU2324 | 120 | 260 | 86 | 3 | 3 | 710 | 920 | 2,400 | 2,800 | 21.5 |
| | NU2324E | 120 | 260 | 86 | 3 | 3 | 795 | 1030 | 2,200 | 2,500 | 26.1 |
| | NU2326 | 130 | 280 | 93 | 4 | 4 | 840 | 1130 | 2,200 | 2,600 | 26.9 |
| | NU2326E | 130 | 280 | 93 | 4 | 4 | 920 | 1230 | 2,000 | 2,300 | 30.9 |
| | NU2328 | 140 | 300 | 102 | 4 | 4 | 920 | 1250 | 2,000 | 2,300 | 33.8 |
| | NU2328E | 140 | 300 | 102 | 4 | 4 | 1020 | 1380 | 1,800 | 2,100 | 38.7 |
| | NU2330 | 150 | 320 | 108 | 4 | 4 | 1020 | 1400 | 1,900 | 2,200 | 40.6 |
| | NU2330E | 150 | 320 | 108 | 4 | 4 | 1160 | 1600 | 1,700 | 2,000 | 47.2 |
| NU10M Series | NU1004M | 20 | 42 | 12 | - | - | 9.2 | 10.5 | 13,000 | 17,000 | 0.079 |
| | NU1005M | 25 | 47 | 12 | 0.6 | 0.3 | 16.7 | 12.9 | 13,100 | 28,000 | 0.0105 |
| | NU1006M | 30 | 55 | 13 | 1 | 0.6 | 22.9 | 19.3 | 11,000 | 24,000 | 0.139 |
| | NU1008M | 40 | 68 | 15 | 1 | 0.6 | 25.1 | 26 | 12,000 | 18,000 | 0.22 |
| | NU1010M | 50 | 80 | 16 | 1 | 0.6 | 30.8 | 34.5 | 10,000 | 15,000 | 0.31 |
| | NU1011M | 55 | 90 | 18 | 1.1 | 1 | 41.5 | 50 | 6,900 | 14,000 | 0.45 |
| | NU1012M | 60 | 95 | 26 | 1.1 | 1 | 44 | 55 | 6,400 | 13,000 | 0.48 |
| | NU1013M | 65 | 100 | 18 | 1.1 | 1 | 45 | 58.5 | 5,900 | 12,000 | 0.52 |
| | NU1014M | 70 | 110 | 20 | 1.1 | 1 | 64 | 81.5 | 5,500 | 11,000 | 0.718 |
| | NU1018M | 90 | 140 | 24 | 1.5 | 1.1 | 93 | 125 | 4,550 | 8,500 | 1.42 |
| | NU1021M | 105 | 160 | 26 | 2 | 1.1 | 101 | 137 | 4,800 | 4,800 | 1.85 |
| | NU1022M | 110 | 170 | 28 | 2 | 1.1 | 143 | 194 | 3,800 | 4,500 | 2.3 |
| | NU1024M | 120 | 180 | 28 | 2 | 1.1 | 146 | 205 | 3,400 | 4,000 | 3.86 |
| | NU1026M | 130 | 200 | 33 | 2 | 1.1 | 150 | 220 | 3,000 | 3,600 | 4.52 |
| | NU1028M | 140 | 210 | 33 | 2 | 1.1 | 170 | 263 | 2,800 | 3,200 | 4.62 |
| | NU1030M | 150 | 225 | 35 | 2.1 | 1.5 | 193 | 310 | 2,600 | 3,200 | 4.8 |
| | NU1032M | 160 | 240 | 38 | 2.1 | 1.5 | 235 | 380 | 2,400 | 3,000 | 5.86 |
| | NU1034M | 170 | 260 | 42 | 2.1 | 2.1 | 260 | 410 | 2,000 | 2,600 | 8.2 |
| | NU1036M | 180 | 280 | 46 | 2.1 | 2.1 | 391 | 505 | 2,100 | 2,600 | 10.5 |
| | NU1038M | 190 | 290 | 46 | 2.1 | 2.1 | 413 | 640 | 2,000 | 2,600 | 11 |
| | NU1040M | 200 | 310 | 51 | 2.1 | 2.1 | 468 | 705 | 1,900 | 2,400 | 14.3 |
| | NU1048M | 240 | 360 | 56 | 3 | 3 | 512 | 775 | 1,700 | 2,000 | 20.4 |
| | NU1052M | 260 | 400 | 65 | 4 | 4 | 690 | 1090 | 1,500 | 1,800 | 29.4 |
| | NU1056M | 280 | 420 | 65 | 4 | 4 | 680 | 1100 | 1,550 | 2,800 | 33.4 |
| | NU1060M | 300 | 460 | 74 | 4 | 4 | 900 | 1430 | 1,390 | 2,400 | 44.4 |
| | NU1064M | 320 | 480 | 74 | 4 | 4 | 915 | 1500 | 1,300 | 2,400 | 47 |
deep groove ball bearing packaging
FAQ of deep groove ball bearing1.Q:Are you a factory or trading company?
A:SEMRI Bearing is specialized in manufacturing and exporting bearings.
SEMRI Bearing have own factory and warehouse.
2.Q:Can I get some samples and do you offer the sample free?
A:Yes, sure, SEMRI Bearing are honored to offer you samples.Can you buy a ticket ?3.Q:What is the payment?
A: 30% T/T In Advance, 70% T/T Against Copy Of B/L
B: 100% L/C At Sight
4.Q:What is the MOQ for bearing?
A: SEMRI Bearing MOQ is 1 pc.
5.Q:What kind of service you can offer?
A:Technology support;Installation guidance;OE
