Dental LED E-Generator Low Speed Handpiece Contra Angle Inner Spray

• Condition：New
• Certification：ISO, CE
• Material：Stainless Steel
• Light Way：With LED Light
• Water Way：Inner Channel
• Usage Times：Non-Disposable

=== Base Info ===

• Model NO.：Low speed handpiece
• Application：Adult, Child
• Loading Way：Gland Type
• Head Diameter：Middle Head
• Exhaust Way：Exhaust Outside
• Number of Holes：Non
• Connection：Without Quick Connector
• Rotating Speed：Low-Speed Handpiece
• Bur Applicable：Φ1.60mm&2.350mm
• Chuck Type：Push Button Type
• Transport Package：Standard Export Carton
• Specification：0.25kg
• Trademark：Topmed
• Origin：China
• HS Code：90184100
• Production Capacity：1000,Month

=== Description ===

Basic Info.

Model NO. Low speed handpiece Application Adult, Child Loading Way Gland Type Head Diameter Middle Head Exhaust Way Exhaust Outside Number of Holes Non Connection Without Quick Connector Rotating Speed Low-Speed Handpiece Bur Applicable Φ1.60mm&2.350mm Chuck Type Push Button Type Transport Package Standard Export Carton Specification 0.25kg Trademark Topmed Origin China HS Code 90184100 Production Capacity 1000/Month

Product Description

Product Description

Technicals

Brand	Topmed
Description	E-type contra-angle handpiece 1:1 Ratio, with Internal Cooling System
Air Pressure	245-392Kpa(2.5-4.0 kgf/cm²)
Water Pressure	198Kpa (2kg)
Rotation Speed	22,000-27,000 rpm
Chuck Type	Latch Type
Bur Applicable	Φ1.60mm & 2.355mm
Noise	≤70dB
Source of light	haloid bulb
Volt of bulb	3.0-3.2V



Features
                                                                                                                                                           1.
LED E-generator intergrated head
Be able to autocalved in 135ºC
Stainless steel bearing, long servive time.
Contra angle with push button and LED light inner water
Self-illuminated, natural LED light
Can be used with fiber optic system
Autoclavable
Inner water spray















Handpiece maintaince

There are two methods of cleaning dental handpieces. One is to use an automatic handpiece system, such as the QUATTRO care Plus, prior to sterilization. The other option is to manually maintain your handpieces. If you elect to manually maintain your handpieces, here are the steps to do so.


Step 1: Clean Handpiece
The first step in cleaning a dental handpiece is to lightly wash the handpiece under cool running water to remove excess debris.

Step 2: Handpiece Lubrication
Following external cleaning, connect the handpiece to the handpiece lubricant spray using the appropriate nozzle for the handpiece you are cleaning. For this air handpiece, we are using a multiflex nozzle.  Spray for approximately 2 seconds. We recommend using a cloth or paper towel wrapped around the handpiece to contain the spray. It is ok if some excess lubrication remains in the handpiece.

Step 3: Purge Handpiece
After lubrication, you'll want to purge your handpiece. Simply connect the handpiece to your multiflex connection, step on the foot petal and purge for 30-40 seconds. The handpiece is now ready for sterilization.
