23124 120*200*62mm Requiring Maintenance Self-aligning Spherical Roller Bearing For Virious Reducers
Hefei Pacesetter for New Material., Ltd / 2022-06-08
- Rolling Body：Roller Bearings
- The Number of Rows：Single
- Outer Dimension：165-500mm
- Material：Bearing Steel
- Spherical：Aligning Bearings
- Load Direction：Radial Bearing
=== Base Info ===
- Model NO.：23124 K , 23124 W33
- Separated：Unseparated
- Structure Type：Spherical Roller Bearing
- Clearance：Normal C2 C3
- Precision Rating：P0 P6 P5 P4 P2
- Vibration：Z1V1 Z2V2 Z3V3
- Cage Type：CA CC E MB
- Hardness：HRC59-60
- Lubrication：Oil Lubrication
- Retainer：CA,CC,CAK,E,MB,K30
- Application：Automotive
- Certification：ISO9001:2008
- Transport Package：Neutral Packing,as Client′s Requirement
- Specification：8.01 Kg
- Trademark：HENGLI, LZ
- Origin：China
- HS Code：8482800000
- Production Capacity：500000 Pieces,Year
=== Description === HENGLI Machinery Company is a well-established Chinese bearing supplier. We design, manufacture and wholesale bearings. A - Manufacturer - Do it only with the Best; -Your Choice make different. Q2 - Our Products A - Spherical Roller Bearing, Cylindrical Roller Bearing, Needle Roller Bearing, Cam Followers, Thrust Bearing - Spherical Plain Bearing, Rod End, Ball Joint, Wheel Hub, Tapered Roller Bearing Q3 - Process of our production A - Heat Treatment - Grinding - Parts Inspection - Assembly - Final Inspection - Packing Q4 - How to customize bearing(non-standard) from your company? A -We offer OEM,Customized(Non-standard) service and you need to provide drawing and detailed Technical Data. Q5 - What should I care before installation? A - Normally, the preservative with which new bearings are coated before leaving the factory does not need to be removed; it is only necessary to wipe off the outside cylindrical surface and bore, if the grease is not compatible with the preservative, it is necessary to wash and carefully dry the bearing. -Bearings should be installed in a dry, dust-free room away from metal working or other machines producing swarf and dust. Q6 - How to stock and maintenance my bearings right? A - Do not store bearings directly on concrete floors, where water can condense and collect on the bearing; -Store the bearings on a pallet or shelf, in an area where the bearings will not be subjected to high humidity or sudden and severe temperature changes that may result in condensation forming; -Always put oiled paper or, if not available, plastic sheets between rollers and cup races of tapered roller bearings.
Basic Load Rating (KN)Mass d D B C Co kg 23120 23120 K 23120 W33 100 165 52 326 490 4.39 23122 23122 K 23122 W33 110 180 56 382 596 5.72 23124 23124 K 23124 W33 120 200 62 468 726 8.01 23126 23126 K 23126 W33 130 210 64 512 798 8.75 23128 23128 K 23128 W33 140 225 68 546 876 10.7 23130 23130 K 23130 W33 150 250 80 716 1150 16.2 23132 23132 K 23132 W33 160 270 86 841 1370 20.8 23134 23134 K 23134 W33 170 280 88 887 1490 22.2 23136 23136 K 23136 W33 180 300 96 999 1650 28 23138 23138 K 23138 W33 190 320 104 1170 1960 34.9 23140 23140 K 23140 W33 200 340 112 1370 2310 43.1 23144 23144 K 23144 W33 220 370 120 1500 2570 54.1 23148 23148 K 23148 W33 240 400 128 1680 3060 66.3 23152 23152 K 23152 W33 260 440 144 2140 3660 92.1 23156 23156 K 23156 W33 280 460 146 2240 3950 98.1 23160 23160 K 23160 W33 300 500 160 2750 4720 129
About Us
Our specialized manufacturer of Spherical Roller Bearing & Cylindrical Roller Bearing, LUAN Rolling Bearing Co., Ltd was
established in 1970 and is accredited by the Chinese Ministry of Machine Building.
We invested in two additional specialized bearing factories, which allow us to provide our clients with top of the line products such
as Needle Roller Bearings, Cam Follower Bearings, Thrust Bearings, Spherical Plain Bearings, Rod Ends Bearings, Ball
Joint Bearings, Tapered Roller Bearings,Wheel Hub Bearings and Non-Standard Bearings.
Q1 - What is our advantages?
