Perfect Performance P6.25 Outdoor Rental LED Screen for Celebration Stage

• Tube Chip Color：Full Color
• IP Rating：IP65
• Pixel Pitch：6.25mm
• Pixel Configuration：1R, 1G, 1B
• Display Function：Video Display
• Average Power Consumption：300W , m²

=== Base Info ===

• Model NO.：P3.91, P4.81, P6.25
• Pixel Density：25600 Pixels,Sqm
• Scanning Mode：1,6
• Display Type：LED Video Display
• Application：Stage Performance
• Certification：CE, RoHS, CCC
• Delivery Time：20working Days
• Warranty：2years
• Brightness：>6500nits
• Refresh Rate：>1500Hz
• Color：Full Color
• OEM：Yes
• Weight：14kg,PC
• Material：Die-Casting Aluinum
• Transport Package：Flight Case
• Specification：CE, ROHS, ISO9001
• Trademark：BST
• Origin：Shenzhen, China
• HS Code：8528591090
• Production Capacity：1000sqm,Month

=== Description ===

Model No.

BST-OR-6

Pixel Pitch

6.25mm

Module Size

250mm×250 mm

Module Resolution(Pixel)

40dots×40dots

Pixel Density

25600dots/m2

LED Type

SMD3535

Pixel Configuration

1R1G1B

Wavelength (R.G.B)

R:625±2nm G:525±2nm B:470±2nm

Drive Mode

1/6 scan

Cabinet Size

500×1000×70mm

Cabinet Resolution

80dots×160dots

Brightness

≥6500 cd/m2

Contrast

≥ 4000:1

Viewing Angle

140°(Horizontal )/140°(Vertical )

Best Viewing Distance

6m-35m

Grey Scale

10bits/1024levels

Color Capability

16777216

Color Temperature

5000-9300K

Maximum Power Consumption

600W/m2

Average Power Consumption

300W/m2

Working Voltage

AC 220V/110V s±15% 50-60 HZ

Frame Frequency

60-85 HZ

Refresh Frequency

240 - 1000HZ

Brightness Correction

Pixel, Module, Cabinet Correction

Operating Temperature

Static:-40°C ~+85°C Working:-20~+65°C

Operating Humidity

10-90% RH

LED Lifespan

100,000 hours

MTBF

≥50,000 hours

Computer Operation System

Win 98/ Win XP/ Win 2000/WIN7/WIN8

Video Signal Input

RF,S-Video, RGB,RGBHV,YUV,YC,VGA, DVI, HDMI, SDI,HD-SDI ,Composite

Video Signal Output

RF, S-Video, GB, RGBHV, YUV, YC etc.

Graphics Card

DVI Graphics Card

Control Distance

UTP CAT5E:100m Multi-mode Fiber:500m Single-mode Fiber:10km

Control System

LED studio 10.0

Software

LINSN / Nova/ DB-STAR

Waterproof Level

IP65

Installation

Wall mount, hung and stand structure

Out of Control Rate

0.02 %

Module Size (W*H)

250mm*250mm

Pixel Configuration

1R1G1B

Pixel Pitch

6.25mm

     Resolution (W*H)

40dots*40 dots

Pixel Density

25600 dots/sqm

LED Type

SMD

3. Outdoor LED Display Cabinet

Cabinet Size (W*H)

500mm*1000mm

Module Qty

8 pcs

  Cabinet Resolution (W*H)

80 dots*160 dots

Cabinet Pixel

12800

Weight

14kg/ Cabinet

Area

0.5sqm

Average Power Consumption

300w/sqm

Max Consumption

600W/m2

Why choose BST?

1. BST is a professional manufacturer of LED display screens over 8 years. We have strong R&D to ensure high end products with user-friendly design .
2. The prices are very competitive due to our large-scale procurement of raw material.   We can help you to win more orders if you are distributors.End users will also be satisfied with our quality and price.
3. We have CE, FCC and Rohs certificates. Our products are exported over 85 countries .We have rich experience in handling all possible problems when you import goods from China .
4. We have a wide variety of products for you to choose from .All products are strictly tested before release to market and we test every LED screen 72 hours before delivery.
5. Our sales are well trained to offer professional advice on your specific projects. Processional engineers are on standby, can offer guidance, on site technical support as requested.
6. We offer 2-3 years warranty and life time maintenance .Even when warranty time expires , we only charge material costs
