Outdoor Waterproof Rental Stage LED Display Screen P3.91

• Tube Chip Color：Full Color
• Display Function：Video Display, Image & Text Display, Text Display, Market Display
• Pixel Pitch：3.91mm
• Pixel Configuration：1R,1G,1B
• Pixel Density：65536
• Scanning Mode：1,16 Scan

=== Base Info ===

• Model NO.：rental outdoor p3.91
• System Operating Platform：WIN XP
• Display Type：LED Video Display
• Application：Stage Performance, Advertising, Shopping Guide
• IP Rating：IP65
• Certification：CE, RoHS
• Module Resolution：64*64
• Brightness：Above 5000CD,Sqm
• Gray Scale：16 Bit
• Viewing Angle：120 Degree
• Transport Package：Carton, Wooden Carton, Flight Case
• Specification：250x250mm
• Trademark：Seekstarled
• Origin：China
• HS Code：8528591090
• Production Capacity：1000 Sqm,Month

=== Description ===
Rental Full Color LED DisplayProduct Item Indoor P2.976Indoor P3.91Indoor P4.81Outdoor P3.91Outdoor P4.81Pixel Pitch 2.976mm3.91mm4.81mm3.91mm4.81mmLED Type LED RGB 3in1RGB 3in1RGB 3in1RGB 3in1RGB 3in1LED Life LED 100,000 hours100,000 hours100,000 hours100,000 hours100,000 hoursConfiguration SMD1515SMD2121SMD2121SMD 1921SMD 2727Module Size 250 x 250250 x 250250 x 250250 x 250250 x 250Module Resolution 84*8464*6452*5264*6452*52Pixels Density (dots)11289665536432646553643264Brightness (cd/sqm) 800-1000cd/sqm800-1000cd/sqm800-1000cd/sqm≥5000 cd/sqm≥4000 cd/sqmViewing Distance ≥9m≥9m4-40m≥8m≥8mViewing Angle 120°/120°120°/120°120°/120°120°/120°120°/120°Refresh Rate ≥1920HZ≥1920HZ≥1920HZ≥1920HZ≥1920HZGray Scale 16bit. Red, Green and Blue  each 16K16bit. Red, Green and Blue  each 16K16bit. Red, Green and Blue  each 16K16bit. Red, Green and Blue  each 16K16bit. Red, Green and Blue  each 16KColor Temperature 3200K-9300K adjustable3200K-9300K adjustable3200K-9300K adjustable3200K-9300K adjustable3200K-9300K adjustableScan Mode 1/28 scan1/16 scan1/13 scan1/16 scan1/9 scanCabinet Material die-casting aluminumdie-casting aluminumdie-casting aluminumdie-casting aluminumdie-casting aluminumCabinet Size (mm) 500x500 / 500x1000500x500 / 500x1000500x500 / 500x1000500x500 / 500x1000500x500 / 500x1000Cabinet Weight(kg) 8kg / 14kg8kg / 14kg8kg / 14kg8kg / 14kg8kg / 14kgMax Consumption (W/sqm)700700780680680Ave Consumption (W/sqm) 260260270270270Supply Voltage AC220V/50HZ; AC110V/60HZAC220V/50HZ; AC110V/60HZAC220V/50HZ; AC110V/60HZAC220V/50HZ; AC110V/60HZAC220V/50HZ; AC110V/60HZStorage Temperature -20ºC~+60ºC-20ºC~+60ºC-20ºC~+60ºC-20ºC~+60ºC-20ºC~+60ºCWorking Temperature -20ºC~+50ºC-20ºC~+50ºC-20ºC~+50ºC-20ºC~+50ºC-20ºC~+50ºCOperating Humidity 10%-80%10%-80%10%-80%10%-80%10%-80%IP Rating IP20IP20IP20IP65IP65Display Capacity Text, Graph and VideoText, Graph and VideoText, Graph and VideoText, Graph and VideoText, Graph and VideoControl System LINSN,Nova-star Colorlight (adjustable)LINSN,Nova-star Colorlight (adjustable)LINSN,Nova-star Colorlight (adjustable)LINSN,Nova-star Colorlight (adjustable)LINSN,Nova-star Colorlight (adjustable)Control Mode Synchronous Control ModeSynchronous Control ModeSynchronous Control ModeSynchronous Control ModeSynchronous Control Mode
Features:
1.  Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows. It is extremely easy to calculate the area of LED screen because it is consist of 500*500mm/500mm*1000mm cabinet. Jointed correctly, being installed & dismounted by one person without tool.

2.  Nice appearance and simple structures. The appearance is very elegant, it looks very high end. Quality is very stable

3.  Humanized operating interface with breakdown indicator lights, easy to maintain.

4.  High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image. 16 bit color, refresh rate over 1920HZ/S so the video or images on the LED screen are very vivid and fresh. People who see it will get shocked by this amazing viewing experience.

5.   The side locks is spring locks, this is unique among all die-casting aluminum cabinets, especially popular in European market and North American market.

6.  Due to the light weight and low power consumption, it can reduces the labor cost,operating cost and transportation cost

7.  The same cabinet size can be compatible with different pixel pitches such as P3.91, P4.81 .If you want to update the product, you only need to change the module
