High Precision Industrial Soy Bean Protein Production Machine

• Processing Material：Animal Raw Materials, Forest Products, Special Agricultural Products, Garden Products, Agronomic Products, Natural Ingredients
• Application：Pet Food, Chocolate, Ice Cream, Vegetable, Fruit, Dairy, Beverage
• Customized：Customized
• Certification：CE, ISO9001
• Power Source：Electric
• Automatic Grade：Automatic

=== Base Info ===

• Model NO.：KS-65,70,85,95
• Voltages：220V,50Hz 380V,50Hz
• Weight：1500kg
• Warranty：1 Year
• Materials：Stainless Steel
• Motor：Siemens,LG,Chinese Brand
• Extruder：Double Screw Extruder and Single Screw Extruder
• Transport Package：Wooden Case
• Specification：26000*25000*3000mm
• Trademark：Keysong
• Origin：Shandong China
• HS Code：8438800000
• Production Capacity：50et,Month

=== Description ===

Basic Info.

Model NO. KS-65/70/85/95 Voltages 220V/50Hz 380V/50Hz Weight 1500kg Warranty 1 Year Materials Stainless Steel Motor Siemens,LG,Chinese Brand Extruder Double Screw Extruder and Single Screw Extruder Transport Package Wooden Case Specification 26000*25000*3000mm Trademark Keysong Origin Shandong China HS Code 8438800000 Production Capacity 50et/Month

Product Description

High precision industrial soy bean protein production machine

Brief introductions of protein soya meat making machines:
   After cooking fibre soy protein meat,it tastes like real-meat,so it is also called artificial meat.It uses wheaten gluten,islated soy protein etc as its raw material to make protein meat which is good water-absorbed,oil-keeing charamters.It is kind of addictive material for meat food,such as sourage,dumpling etc.Its nutritional element is higher than real-meat ,popular with all over the world.
     soya Nugget processing line is developed and manufactured on base of our experience combined with the advanced machines from foreign countries. This line takes soybean meal and peanut meal as main raw materials. After milling, mixing, extruding and cutting, the meal becomes layer fiber structure. The finished products have high nutrition; look and taste like meat; easy to absorbing oil, water and taste; without cholesterol and animal fat, so it is widely used in meat products industry, fast food production, deepfreeze food production, and all kinds of vegetarian snacks and food.
a. Raw Materials:
This Production line adopts defatted soya flour with oil content below 1%,soybean meal, peanut meal etc as raw matyerials
b. Products:
This line can be used to produce soya nuggets, TVP/TSP, soya chunks by adjusting the molds from extruder;meanwhile it can produce cereal, snacks by adjusting the screws from extruder

c. Capacity:
150kg/h, 240kg/h, 300kg/h.
 d. Flow chart:
Mixing system---Extrusion system----Conveying system----Drying system (Frying System) --Packing system
e. Voltage:
In China: Three phases: 380V/50Hz, Single phase: 220V/50Hz. We can make it according to customers' Local voltage according to different countries.

f. Machines Materials
All the machines are made by stainless steel, this line is with reasonable design and with high automation; the screws are made by alloy steel, with building block system structure and self-cleaning function

g. Technical Parameters

Model	Installed Capacity	Actual Consumption	Main Power	Throughput	Dimension
KS65	34kw	28kw	22kw	120-150kg/h	2400*1200*1800
KS70	42kw	30kw	30kw	160-200kg/h	2600*1200*1800
KS85	92kw	75kw	75kw	400-500kg/h	4500*1600*2000
KS90	135kw	91kw	75kw	600-900kg/h	4500*2000*2000
KS100	55kw	30kw	38kw	80-100kg/h	3200*1500*2000

 Features Of Extruder:
a. The screws are made by alloy steel (38CrMoAL) and special craft by nitriding process, The HRC hardness is around 60---62, it has good self-cleaning ability and does not need to discharge or clean the barrel and screw, when roasting or replacing of materials.
b. The extrusion barrel is constructed of carbon steel, is made by #45 steel, stainless steel coating.
c. The gearbox has automatic lubrication function, with extends gear life.
d. Cutting knife fixed in the die head seat, rotary cutting by V-belt drive.
e. SIEMENS(CHINA) brands electronic parts used in the controller box, make sure the extrusion process perfect.
f. Main Motor from SIEMENS(CHINA), ensure its powerful extrusion and excellent performance.

Our most snacks food producktion line
1.Corn flakes and cereal production line
2.Textured/Fibre soy protein production line
3.Onion ring/burgles 2d&3d snacks pellet production line
4.Artificial nutrition rice production line
5.Corn puffed snacks food production line
6.Biodegradable filled material production line
7.Nutritional baby powder production line
8.Modified starch production line
9.Corn chips/crispy dorito chips production line
10.Cheetos/Kurkure production line
11.Caramel popcorn production line
12.Core-filling puffed snacks food production line
13.Bread crumbs production line
14.Pet food production line
Package and shipping:
     Every machine is packed with great care and tough material. It is packed with cling films first and then film bags. At last, it is packed with wooden case which is reinforced with the iron bar on the top and bottomWith this kind machine, all our laser machine can protect well during long trip by sea or by train.We can transport machine by boat or by training, according to your requirement.

Our Service:
1. Free consultation service before, during, and after sales;
2. Free project planning and design services;
3. Free installation and commissioning of equipment until everything is functional;
4. Free management of equipments' long distance shipping;
5. Free training of equipment maintenance and operating personally;
6. Free new production techniques and formulas;
7. Provide 1 year complete warrantee and life-time maintenance service;
8. Engineers available to service machinery overseas.
9. Provide technical exchanging.
