Hyva Fe Type Alpha Series 3 Stages 70544230 Front End Cylinder (with single eye)

• Certification：CE, ISO9001
• Pressure：Medium Pressure
• Work Temperature：Low Temperature
• Acting Way：Single Acting
• Working Method：Straight Trip
• Adjusted Form：Regulated Type

=== Base Info ===

• Model NO.：70544230
• Structure：Piston Type
• Material：Alloy Steel
• Sku：70544230
• Tipping Weight：43-59ton
• Transport Package：Plywood Case
• Specification：Weight: 142kg
• Trademark：ROCA
• Origin：Fujian, China
• HS Code：8412210000
• Production Capacity：1000000

=== Description ===
Hyva FE Series Telescopic Cylinder Part No.Number of stagesTipping weightLargest Moving Stage DiameterTotal StrokeRetracted length70544230343-59ton129mm3880mm1600mm71534180333-59ton129mm3460mm1449mm71534220332-56ton129mm3880mm1609mm70546474540-56ton169mm5830mm1529mm70547530557-79ton191mm6230mm1532mm71537490549-84ton191mm6180mm1527mm71538582560-84ton214mm7130mm1722mm70548576649-74ton214mm7000mm1517mm
Company introduction
Xiamen Roca is a comprehensive manufacturing enterprise engaged in hydraulic cylinders, excavator attachment, metal casting, hydraulic components with certification approval to meet custom or OEM requirements.

ROCA owns factories that offer customers effective-cost products with quality assurance. With its professional and experienced R&D team, ROCA Hydraulic devotes itself to research and development to optimize products applied in construction, mining, waster management, forestry, agriculture, etc.



 Hydraulic cylinders are the most effective and efficient method of pushing, pulling, lifting, and lowering. Nowadays hydraulic cylinders play an essential role in daily application and industry:
√ Mining
√ Earthmoving & Construction
√ Agriculture &Forestry
√Waste Management & Material Handing
√Ship crane & offshoreSelect the right cylinders for an application is critical in obtaining maximum performance and reliability. ROCA team takes all your concerns into consideration to suit your hydraulic cylinder requirements. Together, we work out the best design solution for your application.
