The Latest Multifunctional Full Automatic Meal Worm Sorting Machine

• Transport Package：Wood Package
• Specification：1400x1290x750mm
• Trademark：sUBIt
• Origin：China

=== Base Info ===

• Model NO.：SBT-H8A
• HS Code：8518400001
• Production Capacity：5000,Year

=== Description ===

Basic Info.

Model NO. SBT-H8A HS Code 8518400001 Production Capacity 5000/Year

Product Description

Why did we develop&creat mealworm selecting machine? what functions & advantages did this machine provide?

There are four growing period for tenebrio molitor:insects, spawn, larvae and pupae,the larvae is mainly used as feed.However during the breeding,you may see many ingredients in box like above image:Larvae (different size), pupa (different size), weak worm, dead worm, shedding of skin, leftover feed and dung etc,if don't clean the sundries timely,the foul smell from them will disturb larvaes'growing,at the same time larvaes will also hurt even eat the weak worm and pupae,cause unnecessary losses.







For traditional hand picking,it's hard to clean the dead worm and pupae,need spend a lot of manpower on all procedure,which is low efficiency and big spending.In this condition,to cater farmers need,now we have professional tenebrio molitor multifunctional separator which is all-in-one machine,can process to sieve dung and dead worm,blow dead skin,separate big/small worm at the same time,helping solve your problems fast and in high efficient.







Machinery specification:



Product Introduction:

Machine Dimensions: L1500*H1350*W1000

Material: Painted cold rolled steel

Power: 560W

Voltage: 220V 50HZ

Weight: 260kg





Efficiency for handling the mealworm: 400kg/hour, equivalent to the efficiency of about 12 workers.

Scope of application: Sieving the sand of the mealworm and the superworm, removing impurities and dead skins, separating the live worms and pupa and dead worms, big worms and small warms, pupa and the adult, pupa and the dead worms.



Function:

Our machine is dust-free, and will select and separate the sand, the worm skin, leftover feed, impurities, big/small worms, pupa, dead worms and inactive worms from respective exits!

a.This machine can separate dung,dead skin,impurities, pupa, dead worm, big worm and small worm from respective exit.

b.It takes only 9 seconds to select out the worm in the whole procedure.

c.The machine will be absorbing dust in the whole screening process, to prevent dust spread everywhere and harm the health of the operator.( Dust inhalation for a long time will cause various diseases, such as  rhinitis, pneumonia, bronchitis, pneumoconiosis, lung cancer and so on. Therefore,use of the machine is good for sanitation and health!).











Machine working video display at below interlink:



https://subit-tech.en.made-in-china.com

https://subit-tech.en.made-in-china.com

 https://subit-tech.en.made-in-china.com





Advantages:
1. Fully automatic,just need one person to operate whole procedures;

2. All-in-one machine,gather functions of sieve dung,dead worm,blow dead skin,separate big/small worm;

3.The stronger the vitality, the cleaner the screening,separation rate nearly 100%;
4. Collect frass and inset skin in hermetic bag with less dust;
5. Medium-speed  & Small amplitude sieve,make less influence on insect than hand picked.
6. The machine equip with wheels,easy to move.
7. High efficiency, 421kg per one hour for superworms, 396.5kg per one hour for yellow mealworms.

8. Safe and good for operator's healthy, 70DB sound.


Exporting packing:
