Blowing machine
Dimension | mm | 1600*600*1610mm | Weight | kg | 500 |
Bottle volume (max) | ml | 2000 |
Bottle volume (min) | ml | 50 |
Bottle Neck Diameter (max) | mm | 40 |
Bottle Neck Diameter (min) | mm | 18 |
Body Diameter (max) | mm | 125 |
Body Height( max) | mm | 420 |
Number of Cavities | mold | 2 |
Production output | pcs/h | 600BPH |
Clamping force | T | 5.7(56KN) |
Mold thickness | mm | 200(max) |
Mold width | mm | 360x390 |
Space between Tie-bars | mm | 120-220 |
Diameter of Tie-bars | mm | 63 |
Scope of Tie-bars | mm | 405 |
Mold stroke | mm | 160 |
Stretching stroke (max) | mm | 420 |
Working pressure | Mpa | 0.8-1.0Mpa |
Blowing pressure | Mpa | 2.0-3.0Mpa |
Power | V/KW | 1KW |
Weight | Kg | 500 |
Pre-heater | Dimension | mm | 1870*630*1450mm |
Weight | kg | 260 |
Power | V/KW | 14KW |
Item | Name | Brand name |
1 | Cylinder for stretching unit | FESTO |
2 | Pneumatic par for clamping unit | FESTO |
3 | Sealing cylinder | FESTO |
4 | Blowing Solenoid Valves | FESTO |
5 | Sealing solenoid valve | FESTO |
6 | Clamping Solenoid valve | AIRTAC |
7 | Stretching Solenoid valve | FESTO |
8 | PLC controller | TIANJING |
9 | Breaker | DELIXI |
10 | AC contactor | DELIXI |
11 | inverter | DELTA |
