Highly Safe Style 20W 30W 50W Enclosed Mini Fiber Laser Metal Engraver for Marking

Taizhou Huangyan Lipeng Machinery Mould Factory / 2022-06-23

After-sales Service：Online Service
Warranty：2 Years
Laser Visibility：Invisible
Applicable Material：Metal
Cooling System：Air Cooling
Technical Class：Pulse Laser

=== Base Info ===

Model NO.：LSM30W
Laser Wavelength：Fiber Laser
Laser Classification：Solid Laser
Type：Optical Fiber Laser Marking Machine
Marking Method：Scanning Marking
Fiber Laser：Raycus
Comtrol System：Jcz
Operation System：Microsoft Windows 7. 8. 10 System
Power Supply：220V,60Hz,8A(110V,60Hz,15A Can Choose)
Transport Package：Wood Boxes
Specification：working size: 110*110mm
Trademark：Lansen
Origin：China
HS Code：8456110090

=== Description ===

Graphic format supported

BMP,JPG,JPEG,GIF,TGA,PNG,TIF,TIFF

AI, PLT,DXF,DST,SVG,JPC,NC,G,BOT,GBR

Working area

110mm*110 mm(Standard)

can choose 50*50 150*150 175*175 200*200 (mm)

If use rotary device, the max support 150x150mm field lens.

Marking depth

<1mm

Marking speed

<5000mm/s

Min. line width

0.05mm

Repeatability accuracy

0.003mm

Power Machine

300-600W

Operation temperature

0~40°C

Operation system

Microsoft Windows system

Worktable size

380x265mm

Machine size

840mm*460mm*820mm

Grosse weight

92kg

Features:

Fiber laser, Basic model, high speed galvo scanner; IPG laser and Chinese Brand laser for option.
Maintenance Free, save equipment and worker cost;
Imported Galvonometer, Higher precision,faster speed;
Higher photoelectric conversion efficiency, Low power consumption;
Red light preview, more accurate and reduce positioning time;
Laptop with Powerful marking software;
User friendly software interface, easy operation;
Set and deal different layers graphic separately;
Support PLT,PCX,AL,DXF, BMP,JPG formats file;
Compatible AutoCAD,CorelDraw,Photoshop etc software, Automatic serialization,date coding letter, symbol, pattern, figure, image, bar code, 2D code auto arrangement and amendment.

Machine details:

Applications:

Aplicable Industries:
1. Electrical Engineering and Electrical part and component
2. Mobile (Cover, battery, keyboard, Phone Case)
3. Jewelry(Ring, pedeant, bracelet),eyeglass,clocks and craft
4. Building materials,PVC pipe
5. Car motor car spare part, Instrument and meters and cutting tool
6. plastic case,aviation and aerospace,
7. product,hardware fitting and accessory,sanitary appliance
8. food and beverage ,Medicine package and medical instrument,solar Pv industry
Applicable Materials:
1.Many type of metals: Gold,Silver,Stainless Steel,Copper,Aluminum,chrome Brass,etc
2.Alloy and metal oxides: Anodized Aluminum
3.Some non-metallic materials & Special surface treatment:
silicon wafer, Poly,urethane, ceramics, plastic, rubber, epoxy resin, PVC, PC, ABS, Coating film etc.
Highly Safe Style 20W 30W 50W Enclosed Mini Fiber Laser Metal Engraver for Marking

Warranty:

24 Months for Machine
Detailed manual and video to guide the user how to use the machine and maintenance, also supply the specs settings for the speed and power to engrave or cut on various material.
Lifely and fast technical guide and solution within 24hours by email and web camera.
