30W 60W 80W Jpt Mopa 2.5D Fiber Laser Marking Machine Engraving on Metal

Wenzhou Longwan Haibing Welton Machinery Fittings Factory / 2022-06-23

After-sales Service：2 Years
Warranty：2 Years
Laser Visibility：Visible
Cooling System：Air Cooling
Technical Class：Pulse Laser
Type：Optical Fiber Laser Marking Machine

=== Base Info ===

Model NO.：MT-FP60
Laser Pulse Frequency：20-80kHz
Beam Quality：<1.4m2
Peak Laser Power：5W,10W,20W,30W
Marking Speed：<8000mm,S
Marking Depth：<=0.5mm
Repetition Precision：±0.01mm
Min.Line Width：0.02mm
Min.Character：0.2mm
Cooling Mode：Air Cooling
Graphic Formats Supported：Plt, Dst, Ai, Dxf, BMP, JPG, CAD, CDR, Dwg
Company Type：OEM
Transport Package：Standard Export Wooden Box
Specification：58kg
Trademark：mactron
Origin：Guangdong Dongguan
HS Code：8456110090
Production Capacity：200set,Month

=== Description ===
Overview Product Description

75X75/110X110/200X200/300X300

Laser Power

20W

30W

50W

Laser Repetition Frequency

25KHz-400KHz

Wavelength

1065±10nm

Beam Quality

<2M2

Min Line Width

0.01mm

Min Character

0.15mm

Marking Speed

≤10000mm/s

Marking Depth

≤0.5mm

Repeat Precision

±0.002mm

Power Supply

220V(±10%)/50Hz/4A

Gross Power

<500W

Laser Module Life

100000h

Cooling Style

Air Cooling

System Composition

Control System ,Industrial Computer,Working Table

Working Environment

Clean and Dust Free

Operating Temperature

10ºC-35ºC

Humidity

5% to 75% (Free of Condensed Water)

Power

AC220V, 50HZ, 10Amp Stable Voltage

Warranty

12 Months

Dimension(cm)

131x53x68

Weight(kg)

120

Detailed Photos

30W 60W 80W Jpt Mopa 2.5D Fiber Laser Marking Machine Engraving on Metal

Packaging & Shipping

Custonmized Optional

Other Products

4.RELATED PRODUCTS
Certifications

Company Profile

FAQ

7.FAQ

Q: How to Install the machine?
A: After received our machine, customers do not need to install it and can use it directly.

Q: How to operate the machine? is training necessary?
A: The machine is mainly controlled by software. It's very easy, not complicated. Before shipment, we will make a simple operation manual with pictures and provide user manual of software. Generally speaking, an operator, who is not familiar with fiber laser printing machines before can still operate it very well. According to customers' requests, we can send our technician to customer' plant for machine training or customers can come to our plant for machine training if needed.

Q: In case machine exists the problem, how to do after-sales service?
A: We provide two years machine warranty. During the two-year warranty, in case of machine exists the problem, we will provide parts required with free of charge by express. But as for the parts damaged artificially, it does not fall on our warranty list. After the warranty, we still provide a lifetime service.

Q: What's the package?
A: We have 3 layers package. For the outside, we adopt plywood case. In the middle, the machine is covered by foam, to protect the machine from shaking. For the inside layer, the machine is covered by the waterproof plastic bag.

Q: What's delivery time?
A: Generally speaking, lead time is 5-7 working days after receiving the payment.

Q: Can we add a protection cover?
A: Yes, we can add a protection cover if you need. We can customize the design as customers' requests.

Q: What're consumables for fiber laser marking machines?
A: It does not have consumables. It's very economical and cost-effective.
