- Warranty:1
- Process:Mild Processing
=== Base Info ===
- Model NO.:ST
- Certification:CE, ISO9001
- Automatic Grade:Automatic
- Application:Milk
- Customized:Customized
- Material:SUS304 or SUS316L 2b Sheet
- Volume:500L-100, 000L
- Transport Package:Wooden Case
- Specification:GMP
- Trademark:UNIMACH
- Origin:China
- Production Capacity:200sets,Year
- Package size per unit product:1.00cm * 0.70cm * 1.20cm
- Gross weight per unit product:1000.000kg
=== Description ===
Basic Info.
Model NO.
ST
Certification
CE, ISO9001
Automatic Grade
Automatic
Application
Milk
Customized
Customized
Material
SUS304 or SUS316L 2b Sheet
Volume
500L-100, 000L
Transport Package
Wooden Case
Specification
GMP
Trademark
UNIMACH
Origin
China
Production Capacity
200sets/Year
Packaging & Delivery
Package size per unit product
1.00cm * 0.70cm * 1.20cm
Gross weight per unit product
1000.000kg
Product Description
Specifications
Stainless steel tank:
1. Material: SUS304 or SUS316L 2B sheet;
2. Volume 500L-100, 000L
3. ABB or SEW motor avaiable
The description of this stainless steel tank:
Use: Widely used in milk, juice, beverage and other food industries,
Pharmaceutical factory for storage of liquid product.
Material:
(1) all material used is high quality SUS304-2B stainless steel or SUS316L Stainless steel;
(2) internal layer thickness is 3mm;
(3) external layer thickness is 2mm;
(4) dimple jacket thickness is 1.5mm;
Structure: Cylindrical shape, conical top cover, angle of the top to cylinder is 15 degree, with skirt Base; With PU(Polyurethane) as heat insulation; With cooling dimple pad at tank wall and Base.
Other standard attachments:
Manhole, breath valve, CIP spraying balls, lifting hooks, glass tube level indicator, digital Show themometer, product inlet and outlet.
External surface is 2B, weld ground and clean by chemical, internal Polish to mirrow or 180 mesh, this is according to client detail requirements. Mixer can be made with supporter at bottom or just hanging without supporter.
Standard sizes are 500L-100, 000L.
We can design the exact structure according to client detail requirements.
Model | Effective volume (L) | Internal diameter (mm) | Total height(H) (mm) | PU Insulation (δ)(mm) | Jacket (δ) (mm) | In/outlet D (mm) |
ST-0.5 | 500 | 800 | 2140 | 50 | 1.5 | φ38 |
ST-1 | 1000 | 1050 | 2380 | 50 | 1.5 | φ38 |
ST-1.5 | 1500 | 1180 | 2550 | 50 | 1.5 | φ38 |
ST-2 | 2000 | 1340 | 2760 | 50 | 1.5 | φ38 |
ST-2.5 | 2500 | 1420 | 2940 | 50 | 1.5 | φ38 |
ST-3 | 3000 | 1540 | 3050 | 50 | 1.5 | φ38 |
ST-4 | 4000 | 1650 | 3200 | 50 | 1.5 | φ38 |
ST-5 | 5000 | 1780 | 3250 | 50 | 1.5 | φ38 |
ST-6 | 6000 | 1900 | 3350 | 50 | 1.5 | φ38 |
ST-8 | 8000 | 2100 | 3800 | 60 | 1.5 | φ65 |
ST-10 | 10000 | 2300 | 4050 | 60 | 1.5 | φ65 |
ST-12 | 12000 | 2520 | 4450 | 60 | 1.5 | φ65 |
