Two Outlets 50-110mm PVC Pipe Production Line with Sjsz80/156 Extruder for 50 63 75 90 110 ...

Maanshan Songlin Doctor Blade & Saw Manufacture Co., Ltd. / 2022-07-04

Two Outlets 50-110mm PVC Pipe Production Line with Sjsz80/156 Extruder for 50 63 75 90 110 ...

=== Base Info ===

=== Description ===

Basic Info.

Model NO. SJSZ-80/156 Customized Customized Condition New After-sales Service 1year Since Arrive Destination Port Motor Siemens Brand Inverter ABB/Delta/Ls Contactor Schneider/Siemens Brand Temperature Controller Omron/FUJI/Rkc Brand Transport Package Film, Container Trademark BEIERMAN Origin China HS Code 84778000 Production Capacity 20sets Per Month

Product Description

Detail description:
PVC pipe production line
, we can supply different machines for diameter from 16mm to 800mm .

For different diameter range pipe,will be equipped with corresponding different production lines.
we can supply PVC pipe production lines for diameter:
16mm,20mm,25mm,32mm,40mm,50mm,63mm,
75mm,90mm,110mm,125mm,160mm,200mm,250mm,280mm,315mm,355mm,400mm,
450mm,500mm,550mm,630mm,710mm,800mm.

50-110mm two cavity PVC pipe production line with SJSZ80/156 conical twin screw extruder as main extruder,
equip with GF series auxiliary machinery, specially designed for PVC pipe(UPVC,CPVC share machines), is mainly used in the area of agricultural water supply system, architectural water supply system, pavement of cables, etc .

The line is conical twin screw extruder equipped with double single-control stainless steel vacuum spraying calibration, it avoids waste condition when one tube is adjusted and the other one is affected. The auto single-control double hauling off machine ane cutting machine are combined with the front double calibration technology to make operation more flexible.

Pipe Diameter range: 50mm,63mm,75mm,90mm,110mm,  Two Pipe Outlets.

Major parts of High quality 50-110mm two cavity PVC pipe production line with SJSZ80/156 as main extruder :

the 50-110mm complete 2 cavity PVC pipe production line will include:
1,DTC-600 screw conveyor;
2,SRL-Z300/600 PVC powder hot/cold mixer unit;
3,ZJF300 spring conveyor;
4,SJSZ80/156 conical twin screw extruder;
5,mould for 50-110mm diameter, two cavity
6,vacuum forming tank,two cavity,separated design
7,haul off machine,two cavity
8,cutting machine, two cavity
9, stacker(or belling machine,up to customer's choice)
Two Outlets 50-110mm PVC Pipe Production Line with Sjsz80/156 Extruder for 50 63 75 90 110 Tube MakingTwo Outlets 50-110mm PVC Pipe Production Line with Sjsz80/156 Extruder for 50 63 75 90 110 Tube MakingTwo Outlets 50-110mm PVC Pipe Production Line with Sjsz80/156 Extruder for 50 63 75 90 110 Tube MakingTwo Outlets 50-110mm PVC Pipe Production Line with Sjsz80/156 Extruder for 50 63 75 90 110 Tube Making
Two Outlets 50-110mm PVC Pipe Production Line with Sjsz80/156 Extruder for 50 63 75 90 110 Tube Making

Packaging and shipping:
Two Outlets 50-110mm PVC Pipe Production Line with Sjsz80/156 Extruder for 50 63 75 90 110 Tube Making

Company introduction:

- BEIERMAN MACHINERY was established by three skilled technician/engineer/sales for plastic extruding line, plastic recycling lines producing, sale and services.

- We have 3000 square meters working house for machines making, there are 40 workers for machines producing and a 5 engineers service team for the machines running test, installation, workers training and machines repairmen.

- we have already get CE certificate for our machines and factory, which ensured the high quality level of all machines we are producing

- we will attend several home and abroad plastic machines industry fairs to show the customers our quality, machines and services.

- there will be 1-2 new produced machines will be showed to the customers every year.

- we already established cooperation with the customers from Middle East, Southeast Asia and south America countries.Two Outlets 50-110mm PVC Pipe Production Line with Sjsz80/156 Extruder for 50 63 75 90 110 Tube Making

Two Outlets 50-110mm PVC Pipe Production Line with Sjsz80/156 Extruder for 50 63 75 90 110 Tube Making


Pre-sales services:

we will take customers to visit our factory and check the machines quality from airport/bus station/train stations

- we will re-designed the machines according to customer's different raw material formulations: driving motors power, electric power model, wall thickness of barrel, control method

After-sales services:

we will offer electric diagram, installation diagram, usage manual

- we will offer the customers online introduction to solve the machines problems/send engineers for customers machines installation, running test, workers training, machines repairmen services.

- we will offer customers spare parts at cost prices all life long of the machines.

Exhibition:
Two Outlets 50-110mm PVC Pipe Production Line with Sjsz80/156 Extruder for 50 63 75 90 110 Tube Making
Two Outlets 50-110mm PVC Pipe Production Line with Sjsz80/156 Extruder for 50 63 75 90 110 Tube Making
Two Outlets 50-110mm PVC Pipe Production Line with Sjsz80/156 Extruder for 50 63 75 90 110 Tube Making

FAQ:


Two Outlets 50-110mm PVC Pipe Production Line with Sjsz80/156 Extruder for 50 63 75 90 110 Tube Making
