Large Output Capacity Dehydrating Drying Machine

• Type：Dryer
• Voltage：380V
• Power：1.5KW
• Customized：Customized
• Condition：New
• After-Sales Service Provided：Online Support, Video Technical Support

=== Base Info ===

• Model NO.：SL
• Warranty：One Year
• Advantage：Low Consumption High Efficiency
• Certification：SGS ISO
• Usage：Reduce Material′s Moisture
• Fuel：Coal, Diesel, Natural Gas, Air Heat Pumps
• Function：Food Vegetable Fruit Dehydrator
• Transport Package：Woode Case
• Specification：4000*1600*2500mm
• Trademark：SL
• Origin：China
• Production Capacity：200set,Month

=== Description ===

Basic Info.

Model NO. SL Warranty One Year Advantage Low Consumption High Efficiency Certification SGS ISO Usage Reduce Material′s Moisture Fuel Coal, Diesel, Natural Gas, Air Heat Pumps Function Food Vegetable Fruit Dehydrator Transport Package Woode Case Specification 4000*1600*2500mm Trademark SL Origin China Production Capacity 200set/Month

Product Description

Box Dry Machine

Product description of the dry machine

1. Box dryer is also a kind of food dryer that has been widely used in recent years. The box dryer is a closed drying box with hot air circulating in the box.

2. It adopts the forced air circulation of the fan to reduce the temperature difference between the upper and lower sides of the dryer. The hot air directly contacts the material without additional heat loss.

3. The air in the furnace and the corresponding container do not generate heat, so the thermal efficiency is extremely high.

4. In addition, the machine contains a temperature sensor, which can automatically sense the temperature in the box and keep the temperature in the box at a constant temperature.

Machine application of the dry machine:


1. FRUITS

Red dates, walnuts, dried apple, mangos, peaches, raisins, plums, dried dragon fruit, watermelon seeds, pumpkin seed, strawberries, cherries,

pineapple, persimmons, apricots, litchi, etc.

2. SEAFOOD AND MEAT

Bacon, beef, mutton, chicken, pork, sauce duck, preserved meat, shrimps, fish, cuttlefish, squid, sardines, tilapia, seaweed, octopus, etc.

3. FLOWER AND TEA

Rose, lily, honeysuckle, jasmine, lotus, okra, peony, camellia, cauliflower, tea, etc.

4. FOOD AND VEGETABLE

Rice flour, noodles, bean curd, corn, soybeans, wheat, lentils, sweet potato, yams, taro, garlic, turmeric, agaric, long bean, cucumber, pepper, etc.

5. HERB AND SPICE

Pueraria, ginseng, Ganoderma, cordyceps, wolfberry, Isatis root, pericardium citrus reticulate, star anise, incense sticks, mosquito coils, etc.

6. INDUSTRIAL

Rosewood, oak, fir, red pine, beech, Coal rods, charcoal, etc.







Main technical parameters of the dry machine

Model	Size(L*W*H)(mm)	Drying car number	Capacity(kg/times)
SL-2	4000*1600*2500	2	600
SL-4	6000*1600*2500	4	1200
SL-6	7200*2300*2500	6	1800
SL-8	8800*2300*2500	8	2400
SL-10	10000*2300*2500	10	3000
SL-12	10500*3300*2500	12	3600
SL-14	11000*3300*2500	14	4200
SL-16	11500*3300*2500	16	4800
SL-18	12500*3300*2500	18	5400
SL-20	13500*3300*2500	20	6000
SL-22	14500*3300*2500	22	6600
S-24	15500*3300*2800	24	7200

Customer case of the dry machine

Customers using the dryer scene.



Zhengzhou Shuliy Machinery Co., Ltd was found in 2000. Our company specializes mainly in produce, dry machinery. We not only provide customers with cost-effective products but also provide first-class service support and solutions. Shuliy has passed SGS, ISO, and other certifications. Our products have been exported to countries and regions such as Arabia, India, Russia, Central Asia, Africa, and Mongolia. A perfect after-sales service system allows you to worry-free.



FAQ:


Q1: What are the heating methods?

A1: Oil heating, electric heating, air heating, hot air heating

Q2: What are the advantages of machines?

A2: Fast-drying speed, continuous production, no pollution, and high evaporation intensity. Most important, the dried products bear the good capacity

Q3: How about the price?

A3: We are a professional manufacturer and be able to provide you with the lowest price than the market one. We will give you the best quotation.

Q4: What if the machine is damaged?

A4: One year warranty and all-round after-sales service. After this deadline, we shall charge at a low cost to keep after-sales service.
