182mm Laser Welded Reinforced Concrete Core Drill with Super Quality/Diamond Tool

• Type：Core Drill
• Usage：Masonry Drilling, Reinforced Conrete Drilling
• Manufacturing Technology：Laser Welding
• Segment Height：10mm
• Application：Dry Drilling Concrete, Reinforced Concrete
• Installing Equipment：Hand-Held Drillers

=== Base Info ===

• Model NO.：CDCD
• Transport Package：Carone, Case, Pallet
• Specification：182x10x450mm
• Trademark：COREDIAM
• Origin：China
• HS Code：82071910
• Production Capacity：2000 Pieces Per Month

=== Description ===

Basic Info.

Model NO. CDCD Transport Package Carone, Case, Pallet Specification 182x10x450mm Trademark COREDIAM Origin China HS Code 82071910 Production Capacity 2000 Pieces Per Month

Product Description

1. Laser welded dry core bit introduction
This type of core drill is dry core drill, it is laser welded, the diameter is 182mm, the adaptor is M16. It can be widely used in dry drilling concrete, reinforced concrete, masonry with superior efficiency.



2. Features
- Manufacturer technology: Laser welding
- Suitable: dry drilling concrete, reinforced concrete, masonry with superior efficiency.
- Advantage: good segment sharpness, achieving fast drilling, without segment burnt.
- Different grade to choose.

3. Specification

Item No.	Diameter	Segment  Height	Arbor	Effective Length
CDCD03215010	32mm	10mm	M16	150mm
CDCD03815010	38mm	10mm	M16	150mm
CDCD04215010	42mm	10mm	M16	150mm
CDCD05215010	52mm	10mm	M16	150mm
CDCD06815010	68mm	10mm	M16	150mm
CDCD08515010	85mm	10mm	M16	150mm
CDCD10215010	102mm	10mm	M16	150mm
CDCD10715010	107mm	10mm	M16	150mm
CDCD11715010	117mm	10mm	M16	150mm
CDCD12715010	127mm	10mm	M16	150mm
CDCD15215010	152mm	10mm	M16	150mm
CDCD16215010	162mm	10mm	M16	150mm
CDCD18215010	182mm	10mm	M16	150mm
CDCD20015010	200mm	10mm	M16	150mm

4.Delivery time
2 weeks for samples after order confirmed.
3 weeks for batch order after payment confirmed.

5. Packing and delivery


6.Corediam service
We accept customized lengths and segments for wet core drills.
Also, we help to design the total solution of core drilling projects.

7.Corediam testing process


8. Types of equipment

9. Corediam sales network
