500kg/Hour Small Milk Making Machines

• Process：Thermal Processing
• Power Source：Electric
• Certification：CE, ISO9001
• Automatic Grade：Automatic
• Application：Milk, Milk Powder, Cheese
• Customized：Customized

=== Base Info ===

• Model NO.：GYV-6000
• Name：Milk Production Line
• Capacity：500kg,H
• Color：Silver
• Function：Milk Processing
• Transport Package：Milk Production Line Wooden Boxes
• Specification：2*3*12m
• Trademark：genyond
• Origin：Shanghai
• HS Code：8419899090
• Production Capacity：5000

=== Description ===

Basic Info.

Model NO. GYV-6000 Name Milk Production Line Capacity 500kg/H Color Silver Function Milk Processing Transport Package Milk Production Line Wooden Boxes Specification 2*3*12m Trademark genyond Origin Shanghai HS Code 8419899090 Production Capacity 5000

Product Description

 dairy milk production line/uht milk production line /turnkey milk production line

 According to customer requirements and yield to customize a variety of fresh milk, pasteurized milk, reduced milk, peanut milk, students milk equipment advanced technology to provide plant planning, equipment installation and commissioning training to handle full set of turn key project, a full set of fresh milk production line mainly has: milk collection system, allocation system, net milk and standardization system, homogenization, degasification system, system and sterilization, filling the system etc.

Fully Production Line
Provide installation and commission service
Capacity from 500L to 20,000L per hour
Bottles,sachet(bags),carton box and cup package for customer choose.

With a production that can be stored for long periods without spoiling and with no need for refrigeration, there are many advantages for both the producer, the retailer and the consumer. This includes expensive products such as cream, desserts and sauces.



Equipment introduction:
This production line is used for the production of pasteurized milk,yogurt,lactobacillus drinks,dairy drinks.The complete production line including milk collection system/power reduction system,water treatment system,sugar melting and blending system,filter,degas,homogenization & sterilization,temperature holding,fermentation,CIP washing,filling,coding,packing.
Optional configuration
Material:caw milk/goats'milk/yak milk/powder



UHT Milk Processing Plant

The processing line produce several types of market milk products, i.e. whole milk, skimmilk and standardised milk of various fat contents.



This milk production line raw milk can be fresh milk or powder milk, the procedure method can be pasteurization or HTST pasteurizer or UHT processing.



Pasteurized milk is milk which has been heat-treated to kill pathogens which cause disease. Not all pathogens are removed during the pasteurization process, so pasteurized milk is not 100% sterile, but many people consider it to be safer to drink than raw milk which has not been pasteurized at all. The bulk of the milk sold in commercial grocery stores is pasteurized, and much of it is also homogenized to prevent the cream from separating.

First the milk is preheated and standardised by in line milk fat standardisation system. The purpose of standardisation is to give the milk a defined, guaranteed fat content. Common values are 1.5% for low fat milk and 3% for regular grade milk, fat contents as low as 0.1 and 0.5 % is skim milk.

Then the standardised milk is homogenised. The purpose of homogenisation is to disintegrate or finely distribute the fat globules in the milk in order to reduce creaming. Homogenisation may be total or partial. Partial homogenisation is a more economical solution, because a smaller homogeniser can be used.

The milk, now is pumped to the heating section of the milk heat exchanger where it is pasteurised. The necessary holding time is provided by a separate holding tube. The pasteurisation temperature is recorded continuously. Pump is a booster pump which increases the pressure of the product to a level at which the pasteurised product cannot be contaminated by untreated milk or by the cooling medium if a leak occur in the plate heat exchanger. If the pasteurisation temperature should drop, this is sensed by a temperature transmitter. A signal activates flow diversion valve and the milk flows back to the balance tank. After pasteurisation the milk continues to a cooling section in the heat exchanger, where it is regeneratively cooled by the incoming untreated cold milk, and then to the cooling section where it is cooled with ice water. The cold milk is then pumped to the filling machines.

Temperature and pasteurisation holding time are very important factors which must be specified precisely in relation to the quality of the milk and its shelf life requirements. The pasteurisation temperature is usually 72 - 75C for 15 - 20 sec. A common requirement is that the heat treatment must guarantee the destruction of unwanted microorganisms and of all pathogenic bacteria without the product being damaged.



Advantages
* Opportunity to realize products with customized recipes.
* Opportunity to produce more than one product with the same processing line.
* Very short holding times at pasteurizing temperature.
* Accurate dosing of mixing and additional aromas.
* High quality of the final product keeping an elevated nutritional value.
* Wide customization of the final product.
* Extended shelf life of the product.
* Maximum yield, minimum production waste.
* Highest energy savings thanks to the most advanced technologies.
* Complete line supervision system through monitoring of every process phase.
* Recording, visualization and printing of all daily production data.



Raw material	liquid cow milk, goat milk, camel milk
Capacity	from 10 tons/d up to 500 tons/d
Products	- Pasteurised skimmilk  - Pasteurised whole milk  - Pasteurised milk with varied fat content  - Pasteurised flavor milk  - Pasteurised milk in varied package:  Gable top carton; glass bottle; plastic pouch; paper pouch; etc.
