Single Head Welding Machine for UPVC Window and Door

=== Base Info ===

=== Description ===

Basic Info.

Model NO. DHJ-100 PVC Windows and Doors Machine PVC Windows Profile Machine PVC Profile Machine PVC Machine PVC Single Head Welder Machine UPVC Single Head Welding Machine Transport Package in wooden cases Specification ISO9001/2000 Trademark SUNNY Origin China HS Code 847780000 Production Capacity 10 Sets Per Month

Product Description

                      PVC Windows Machine, UPVC Window Welding Machine (SHZ4 -120X4500)

1. Description:
This machine is used for PVC door and window welding processing. The four heads can work at the same time, and it enables a one-step welding for rectangle window pane. It adopted PLC, It features high reliability and wide processing range. It is efficient and suitable for batch production. The operation is very easy. The rectangle window frame can be welded at one step. It is very efficient.

2. Technical Parameter:
Air pressure: 0.5-0.8MPa
Air consumption: 200L/min
Input power source: 380V 50Hz
Total power: 7.0KW
Welding range: 300x300-1800x3000mm
Welding profile height: 20-120mm
Welding profile width: 120mm

3. Payment: Telex Transfer (T/T), 30% be paid after confirming the order and the rest 70% is effected while delivering the goods.
Package: Each PC in wooden cases.
Port of Loading: Qingdao, China
Delivery Time: During 20 days after we receive your first payment.

4.Contact information
Mobile:0086- 15098968538

5.Other welding machine we have
