High Speed HDPE/LDPE Rotary Head Film Blowing Machine

Nanyang Yukang Photonics Co., Ltd. / 2022-07-04

High Speed HDPE/LDPE Rotary Head Film Blowing Machine

=== Base Info ===

=== Description ===

Basic Info.

Model NO. SJ- Computerized Computerized Machine Weight 1.5t Certification CE, ISO9001:2008 Output 25-55kg/Hr Rotary Die Head Optional Embossing Optional Die Head 2 Free Transport Package Film Package Specification SGS Trademark YUNBANG Origin China HS Code 84778000 Production Capacity 20 Sets/Month

Product Description

Main Technical Variables:
Model

55-6580100
Screw
 Diameter
55mm65mm80mm100mm
Screw
Ratio
L/D28:1L/D28:1L/D28:1L/D28:1
Screw
 Speed
10-100r/min10-100r/min10-100r/min10-100r/min
Main
Output
50kg/h70kg/h86kg/h140kg/h
Power of
Main Motor
15KW22KW30KW45KW
Specification of Die Head¢100-¢150mmv120-¢220mm¢150-¢300mm¢500mm
Rotational Mode of Machine Headconstantly revolveconstantly revolve
Single-sided Thickness of Film0.01-0.10mm0.01-0.10mm0.01-0.10mm0.01-0.10mm
Max.Folding Width of Film800mm1200mm1500mm2000mm
Electric Total Capacity26Kw42Kw56Kw880Kw
Weight of Mashine2300kg3800kg4600kg6000kg
Overall Dimensions(mm)6000x2000x40006800x2400x48007000x2700x55008000x3200x7600
Q&A:

1. How long will your engineer reach our factory?
Within one week after machine arrival your factory.

2. How many days will you finish installing?
We will finish installation and training within 15days.

3. What should we charge for your engineer?
You should charge for the cost of our engineer's visa, air tickets, hotel, food, and also their salary 100USD one day per person.

4. How long is your machine's warranty period?
All our machine have one year guarantee, starting from finished installation.

5. How could we do after one year warranty period?
We also can do service for you, but you need pay salary for my technician 80USD/day.

6. How could we do if the parts broken within warranty?
We would express the free replacement parts during the warranty date.

7. Does your engineer understand English?
Our engineers understand a little English. All of our engineer have more than five years machine installation experience. In addition, they can use body language to communicate with customer.

8. Can you help us find any engineer in our location?
Of course, we will check and inform you as soon as possible.
