Eceng Brand Pet Blow Molding Machine

=== Base Info ===

=== Description ===
                          ItemQ6000Bottle type specificationCavity4Theory output5500-6500Max.volume2LBottle mouth maximum overall diameter28-38mmBottle biggest diameter65mmBottle maximum height330mmPower specificationsLight tube quantity32Light tube power2KWMaximum heating power64KWAll electric machine installation67KWActual consumption45KWAir pressure specificationWork pressure7-9kg/cm2Low-pressure gas consumption1600L/minBlow bottle pressure25-35kg/cm2Higher -pressure gas consumption4800Ltr/minForzen water specificationWork pressure5-6 kg/cm2Temperature range10Consumption8000kcal/hrForzen water flow88L/minMachine specificationSize of the machine4.5*1.5*1.9(m)Weight of the machine6ton

Technology Advantage
l.   Special design,high rigid compound die structure
2.  Wide adaptability, suitable for every type mould thickness
3.  Adjust convenience
4.  No mould rolling out
5.  More energy conservation,no need much air supply
6.  High burnish principal axis, with very precise polishing, light action and low noise.
7. Short mould stroke,quick action
8.  All ZG45 casting, with long timing process,very small transformation,can meet your precise request 100%
9.  Hig dead-weigh, ensure the steady during the opeartion


Transportation:
   It is located in the beautiful port city of Zhangjiagang with convenient traffic; it's about 150 km away from Shanghai.
Products:
   PVC/HDPE/PP-R pipe extrusion line, PVC & WPC profile extruding line and plastic sheet production lines with the relative auxiliary machine, PE film/ PET bottles recycling line and pelletizing lines.
Market:
   Our products have been exported to Middle East, Southeast Asia, South America and Europe etc. We received the universal confirmation and trust from our customers except of the precious experience.
Idea:
   Abide by the logos of "Sincerity, Development, innovation, Win-Win" constantly, we are honorable to cooperate with friends at home and abroad by providing the high quality products, technology and service!
