GS1600-LS no-dig machine pipe crossing

Zhejiang Weigang Technology Co., Ltd. / 2022-06-23

GS1600-LS no-dig machine pipe crossing

=== Base Info ===

=== Description ===

Basic Info.

Model NO. GS1600-LS Bit Type Drag Bit Drilling Way Rotary Type Track Engine Power 316 kW Max. Torque 78000 NM Max. Mud Pump Flow 800 L/min Transport Package Nude Packing Specification 11600*3100*3550 mm Trademark Goodeng Origin China HS Code 843041 Production Capacity 2000/Year

Product Description

GS1600-LS no-dig  machine pipe crossing
ItemParameterItemParameter
Rig Weight(kg)

28300Size L×W×H(mm)11600x3100x3550
Max. Push & Pull force(KN)1700Max. Torque(N*m)78000
Max. Push & Pull speed(m/min)45Max. Rotation Speed
(r/min)
105
Engine Power(KW)316Max. Mud Pump Flow
(L/min)
800
Caterpillar Walking Speed(Km/h)3-5Max. Mud Pump Pressure
(Mpa)
10
Entry Drill Angle(°)8-22Max. Climbing Gradient
(°)
18
Max Aperture Diameter(mm)Ф1500Max. Drilling Length(m)1500

GS1600-LS no-dig  machine pipe crossing1.Rotary manipulator
2.Rotatable cab and heating and cooling air conditioner
3.The power head rotation has dual-proportional speed regulation function
4.Power head push-pull with three-gear speed regulation function
5.Caterpillar wire control walking, two speed adjustable
6.Thrust&pullback force is 1700kN
7.Equipped with mud pump with maximum flow L/min 800
8.Main girder adopts four bar linkage luffing structure

GS1600-LS no-dig  machine pipe crossingGS1600-LS no-dig  machine pipe crossingGS1600-LS no-dig  machine pipe crossingGS1600-LS no-dig  machine pipe crossing

1. What about the warranty time?

    A:12 months after shipment or 2000 working hours,whichever occurs first.

2. What about the delivery time?

    A:20 days after receiving the deposit.

3.What kind terms of payment can be accepted?

    A: On T/T term, 30% down payment is required in advance, and 70% balance shall be before shipment, or against the copy of original BL for old client.

       On L/C term, 100% irrevocable L/C without "soft clause" can be accepted.

4.What logistics ways we can work for shipment?

    A: We can ship machine by sea and road.

 5. What about the after-sales service?

    A: We have office and professional after-sales service team in many countries. After you receiving the new machine, we will provide you one engineering training installation and debugging service for 3-5days. If there are some problems, our after-sales service team will arrive the project site in shortest time.
