Mono-Layer Plastic Sheet Extruder

=== Base Info ===

=== Description ===
Overview

Product Description

We adopt advanced international technology and make considerable innovations on design, manufacturing and accessories for LZ series plastics sheet extruder. The machine is mainly used to produce plastic sheet of PP, PS and PE. Then the sheet can be taken to produce such as disposable cups, jelly cups, plastic packing containers, file and so on.

Hard gear, Strong torque, low noiseWaster Rewinding systemScrew material : 38 crMoAL
Nitrogen treatment: 0.4 - 0.7mmMoving with electromotion control systemScrew with air cooling systemRoller Hard chromium plating 0.08-0.18mm
Hardness: HRC58-62 Surface roughness: ≥Ra5 Heating zones of the screwDouble post gantry traction Rewinding systemUninterrupted hydraulic screen changer system4 Heating zones of the die headEnergy-saving Die head with
plating & polishingAuto Material Feeding systemSynchronous 45°Three roller control systemOmron Temp. Controller PID Adjusting
Memory & Antijam Digital Temp. ControlFull frequency conversion control (Delta)Schneider Electric

Product Parameters

MODELLC-800BLC-1000BLC-1200BWIDTH OF DIE HEAD800mm1000mm1200mmMATERIALPP.PS.PEPP.PS.PEPP.PS.PEWIDTH OF SHEET750mm900mm1000mmTHREE ROLLER SIZE350*800mm*3350*1000mm*3350*1200mm*3THICKNESS OF SHEETPP.PE:0.3-2.5mm
PS:0.15-2mmPP.PE:0.3-2.5mm
PS:0.15-2mmPP.PE:0.3-2.5mm
PS:0.15-2mmSCREW SIZE110 1:32110 1:32120 1:30TOTAL POWER90kw100kw120kwWORKING POWER55kw60kw72kwSPEED15-20m/min15-30m/min15-50/minCAPACITY180kg/h220kg/h300kg/hDIMENSION12*1.6*2.2m12*1.8*2.5m11.5*1.9*2.5mWEIGHT5800kg6200kg6800kg
